- Page 1 Leica Rod Eye 140 User Manual Version 1.0 English...
- Page 2 • This Quick Start Guide contains first use directions as well as initial, basic instruc- tions for setting up the product and operating it. • Keep all documentation for future reference! Available Refer to the following resources for all Rod Eye 140 documentation/software: documentation • the Leica Rugby CD • https://myworld.leica-geosystems.com...
-
Page 3: Table Of Contents
Table of Contents In this manual Chapter Page Safety Directions General Definition of Use Limits of Use Responsibilities Electromagnetic Compatibility EMC FCC Statement, Applicable in U.S. Instrument Components Operation Technical Data Care and Transport Transport Storage Rod Eye 140, Table of Contents... -
Page 4: Safety Directions
Important paragraphs which must be adhered to in practice as they enable the product to be used in a technically correct and efficient manner. Definition of Use Intended use • Remote control of product. • Data communication with external appliances. Rod Eye 140, Safety Directions... -
Page 5: Limits Of Use
• To ensure that it is used in accordance with the instructions. • To be familiar with local regulations relating to safety and accident prevention. • To inform Leica Geosystems immediately if the product and the application becomes unsafe. • To ensure that the national laws, regulations and conditions for the operation of e.g. -
Page 6: Fcc Statement, Applicable In U
Precautions: Use only the equipment and accessories recommended by Leica Geosystems. When combined with the product, they meet the strict requirements stipulated by the guide- lines and standards. When using computers or other electronic equipment, pay atten- tion to the information about electromagnetic compatibility provided by the manufac- turer. - Page 7 This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation. 005146_001 Rod Eye 140, Safety Directions...
-
Page 8: Instrument Components
Location to attach the receiver bracket for normal operation. Mounting Hole Offset notch Use to transfer reference marks. The notch is 85 mm (3.35") below to top of the detector. Product label The serial number is located inside the battery compartment. Rod Eye 140, Instrument Components... - Page 9 Strobe rejection The RE 140 Classic is designed to reject and eliminate unwanted signals from strobe lights. Beam finding Passing the RE 140 Classic through the laser beam will cause the sensor to beep twice quickly. Rod Eye 140, Instrument Components...
- Page 10 If the detector is moved out of the detector range, the arrow display display will indicate the direction to move to return to the laser beam. Laser low Alerts the user when the lasers’s batteries are getting low. battery Rod Eye 140, Instrument Components...
-
Page 11: Operation
Operation Menu access and To access the menu of the Rod Eye 140 Classic Receiver, press the Bandwidth button navigation and Audio button simultaneously. • Use the Bandwidth button and Audio button to change parameters. • Use the Power button to scroll through the menu. - Page 12 Audio volume indication - Three levels of volume are displayed: loud, soft, off (no icon). Accuracy indication - Three levels of accuracy are displayed: fine, medium, coarse. Receiver low battery warning - Three levels of battery life are displayed: full, low, empty. Rod Eye 140, Operation...
-
Page 13: Technical Data
• FCC Part 15 (applicable in US) national regulations • Hereby, Leica Geosystems AG, declares that the product Rod Eye 140 is in compli- ance with the essential requirements and other relevant provisions of Directive 1999/5/EC and other applicable European Directives. The declaration of conformity may be consulted at http://www.leica-geosystems.com/ce. -
Page 14: Care And Transport
Always carry the product in its transport container and secure it. Shipping When transporting the product by rail, air or sea, always use the complete original Leica Geosystems packaging, transport container and cardboard box, or its equivalent, to protect against shock and vibration. Shipping, transport... - Page 15 Rod Eye 140, Care and Transport...
- Page 16 International Standards of Quality Management and Quality Systems (ISO standard 9001) and Environmental Management Systems (ISO standard 14001). Ask your local Leica Geosystems dealer/sales representa- tive for more information about our TQM program. Original text Published in Switzerland ©...
