- Page 1 OPERATION AND INSTALLATION Wall mounted convector » CNS 50 U » CNS 75 U » CNS 100 U » CNS 150 U » CNS 200 U » CNS 250 U » CNS 300 U » CNS 50 UT » CNS 75 UT »...
-
Page 2: Table Of Contents
CONTENTS | SpECial iNfOrmaTiON SpECial iNfOrmaTiON SPECIAL INFORMATION OPERATION General information �����������������������������������������3 Safety instructions ����������������������������������������������� 3 - Keep children under the age of 3 away from Other symbols in this documentation ����������������������� 3 the appliance if constant supervision cannot be Information on the appliance ��������������������������������� 3 guaranteed. -
Page 3: General Information
OpEraTiON General information OpEraTiON Other symbols in this documentation Note General information is identified by the adjacent symbol. f Read these texts carefully. General information The chapters "Special Information" and "Operation" are intended Symbol meaning for both the user and qualified contractors. Material losses (Appliance and consequential losses, environmental pol- The chapter "Installation"... -
Page 4: General Safety Instructions
OpEraTiON appliance description General safety instructions Test symbols Operate the appliance only when fully installed and with all safety See type plate on the right on the exterior of the appliance. equipment fitted. Appliance description WARNING Injury - Keep children under the age of 3 away from the The appliance is a wall mounted electric direct heater. -
Page 5: Cns Ut
OpEraTiON Operation 4.1.3 Frost protection Constant operation "I" f Turn the temperature selector as far to the right as possible. f Move the ON/OFF switch to "I". In this position, the temperature controller switches on the heating The appliance heats with no time limit until the room tempera- element automatically if the room temperature drops below the ture set with the temperature selector is reached. -
Page 6: Limiting The Temperature Selector
OpEraTiON Cleaning, care and maintenance 4.3.3 Operating modes Comfort mode As soon as the selected room temperature is reached, it is con- stantly maintained at this selected temperature through periodic heating. The output of the appliance must correspond at least to the required heat demand of the room. -
Page 7: Installation
iNSTallaTiON Safety iNSTallaTiON Installation Minimum clearances Safety Only a qualified contractor should carry out installation, commis- sioning, maintenance and repair of the appliance. General safety instructions ≥100 ≥100 ≥500 We guarantee trouble-free function and operational reliability only if original accessories and spare parts intended for the appliance are used. -
Page 8: Appliance Installation
iNSTallaTiON Troubleshooting Appliance installation Power supply f Hook the appliance by its slots in the back of the appliance on f Ensure the on-site supply cable has an adequate to all four tabs of the wall mounting bracket simultaneously. cross-section. f Push the appliance to latch it in position. -
Page 9: Specification
Appliance Width 1040 b01 Electrical cable entry Wall mounting Hole spacing bracket 12.2 Data table CNS 50-300 U CNS 50 U CNS 75 U CNS 100 U CNS 150 U CNS 200 U CNS 250 U CNS 300 U 236276 236277... - Page 10 iNSTallaTiON Specification CNS 50-300 UT CNS 50 UT CNS 75 UT CNS 100 UT CNS 125 UT CNS 150 UT CNS 200 UT CNS 250 UT CNS 300 UT 231547 231548 231549 231550 231551 231552 231553 231574 Electrical data Connected load 0.75 1.25 Power supply...
-
Page 11: Environment And Recycling
GUARANTEE | ENVIRONMENT AND RECYCLING Guarantee The guarantee conditions of our German companies do not apply to appliances acquired outside of Germany. In countries where our subsidiaries sell our products a guarantee can only be issued by those subsidiaries. Such guarantee is only grant- ed if the subsidiary has issued its own terms of guarantee. - Page 12 Deutschland Verkauf Tel. 05531 702-110 | Fax 05531 702-95108 | info-center@stiebel-eltron.de STIEBEL ELTRON GmbH & Co. KG Kundendienst Tel. 05531 702-111 | Fax 05531 702-95890 | kundendienst@stiebel-eltron.de Dr.-Stiebel-Straße 33 | 37603 Holzminden Ersatzteilverkauf Tel. 05531 702-120 | Fax 05531 702-95335 | ersatzteile@stiebel-eltron.de Tel.
