Volvo 31330986 Installation Instructions Manual

Volvo 31330986 Installation Instructions Manual

Parking assistance, rear
Hide thumbs

Advertisement

Quick Links

Download this manual
Installation instructions, accessories
Volvo Car Corporation Gothenburg, Sweden
Instruction No
Instruction No
Version
Version
31201126
31201126
1.4
1.4
© Volvo Car Corporation
Part. No.
Part. No.
31330986
31330986
Parking assistance, rear
Parking assistance, rear
Parking assistance, rear- 31201126 - V1.4
Page 1 / 40

Advertisement

loading
Need help?

Need help?

Do you have a question about the 31330986 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Volvo 31330986

Summary of Contents for Volvo 31330986

  • Page 1 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Instruction No Instruction No Version Version Part. No. Part. No. 31201126 31201126 31330986 31330986 Parking assistance, rear Parking assistance, rear © Volvo Car Corporation Parking assistance, rear- 31201126 - V1.4 Page 1 / 40...
  • Page 2 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Equipment IMG-275777 A0000162 IMG-297074 IMG-297076 IMG-246925 IMG-239981 IMG-247306 IMG-239664 A0000177 A0000214 M0000232 IMG-297079 © Volvo Car Corporation Parking assistance, rear- 31201126 - V1.4 Page 2 / 40...
  • Page 3 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden IMG-297080 © Volvo Car Corporation Parking assistance, rear- 31201126 - V1.4 Page 3 / 40...
  • Page 4 Certain steps in the instructions are only presented in the form of images. Explanatory text is also given for more complicated steps. In the event of any problems with the instructions or the accessory, contact your local Volvo dealer. IMG-352596 © Volvo Car Corporation Parking assistance, rear- 31201126 - V1.4...
  • Page 5 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Clean the sensors. Use: Isopropanol Allow to dry. IMG-344142 Carefully mat the surface down. Use: Glasspaper, grade P1000 IMG-344141 Clean the sensors again. Use: Isopropanol Allow to dry. Avoid contact with the cleaned surfaces.
  • Page 6 Caution! Protect the connections' contact surfaces against paint. Paint the sensors in the same colour code as the vehicle. use Volvo Touch-up paint. (Only use base coat.) Use: Volvo 2-K Varnish. P/N: 31335447 Note! Also read the instructions on the spray can.
  • Page 7 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden IMG-292804 Fold the carpet to one side. IMG-292806 © Volvo Car Corporation Parking assistance, rear- 31201126 - V1.4 Page 7 / 40...
  • Page 8 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Unhook the clip. Unplug the connector. IMG-292823 Unhook the clip. Unplug the connector. IMG-292825 IMG-292826 © Volvo Car Corporation Parking assistance, rear- 31201126 - V1.4 Page 8 / 40...
  • Page 9 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Applies to cars with the Four-C system IMG-292827 Applies to all models IMG-292829 © Volvo Car Corporation Parking assistance, rear- 31201126 - V1.4 Page 9 / 40...
  • Page 10 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden IMG-292830 CD panel removal. Release the hooks using a screwdriver. Note! One side at a time. Press the panel out. IMG-292863 IMG-292883 © Volvo Car Corporation Parking assistance, rear- 31201126 - V1.4...
  • Page 11 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden IMG-293126 IMG-292884 IMG-293003 © Volvo Car Corporation Parking assistance, rear- 31201126 - V1.4 Page 11 / 40...
  • Page 12 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Note! The screws may be difficult to access. IMG-293004 IMG-293005 Applies to cars with an automatic transmission IMG-293006 © Volvo Car Corporation Parking assistance, rear- 31201126 - V1.4 Page 12 / 40...
  • Page 13 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Applies to cars with an automatic transmission Release the shift-lock function. Move the gear selector to position "D". IMG-293007 Applies to all models IMG-293008 © Volvo Car Corporation Parking assistance, rear- 31201126 - V1.4...
  • Page 14 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden IMG-293009 IMG-293010 IMG-293011 © Volvo Car Corporation Parking assistance, rear- 31201126 - V1.4 Page 14 / 40...
  • Page 15 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden IMG-297123 IMG-297143 IMG-297165 © Volvo Car Corporation Parking assistance, rear- 31201126 - V1.4 Page 15 / 40...
  • Page 16 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden IMG-297166 Reinstall the disconnected components in reverse order. IMG-308123 © Volvo Car Corporation Parking assistance, rear- 31201126 - V1.4 Page 16 / 40...
  • Page 17 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden IMG-281469 Remove the side cushion by first pulling it backwards at the upper edge until the hook (1) releases. Then pull the side cushion inwards slightly until the hook (2) releases, and upwards until the locating pin (3) disengages from the mounting at the rear edge.
  • Page 18 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Remove the headlining panel by first pulling the rear edge downward so that the four clips release. Then unhook the front edge. IMG-281472 Remove the smaller headlining panel by pulling it laterally so that the two hooks release.
  • Page 19 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Use: 9995919 Hook. Insert into the holes on the upper edge of the cover. Turn the tool and pull off the cover. Remove the loading eyelet screws. Tightening torque M8 screws: 24 Nm (17.7 lbf.ft).
  • Page 20 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden IMG-285529 Slacken off the two screws in the sill panel. IMG-281484 Remove the sill panel by pulling it straight up so that the six clips release. IMG-281523 © Volvo Car Corporation Parking assistance, rear- 31201126 - V1.4...

  • Page 21: Remove The Screw

    Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Remove the screw. Remove the side panel by detaching and angling out the upper edge. IMG-281543 IMG-297185 IMG-297204 © Volvo Car Corporation Parking assistance, rear- 31201126 - V1.4 Page 21 / 40...
  • Page 22 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Also carried out on the other side. IMG-297503 Note! This procedure is easier carried out by two people. IMG-297504 © Volvo Car Corporation Parking assistance, rear- 31201126 - V1.4 Page 22 / 40...
  • Page 23 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Note! This procedure is easier carried out by two people. Caution! Place the bumper cover on a suitable surface. IMG-297523 The cable harness will not be used again. IMG-297524 IMG-297525 © Volvo Car Corporation Parking assistance, rear- 31201126 - V1.4...
  • Page 24 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Locate the two markings at the upper edge of the bumper cover. IMG-331351 Mark the centre, use a scriber. IMG-331357 Ø 3 mm (7/64") Ø 10 mm (25/64") IMG-331349 © Volvo Car Corporation Parking assistance, rear- 31201126 - V1.4...
  • Page 25 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Use: 9997234 Hole tool Caution! Place the hole tool's support sleeve on the inside, and the cutting part on the outside of the bumper casing. IMG-331354 Locate the two markings at the lower edge of the bumper cover.
  • Page 26 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Mark the centre, use a scriber. IMG-331358 Extend the marking's vertical line using a scriber. This is to be used as a reference line for punching holes. IMG-331359 Illustration A Ø 3 mm (7/64") Ø...
  • Page 27 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden IMG-331348 Use: 9997367 Hole tool Ensure that the markings, 1 and 2, are opposite each other when making holes. Caution! Place the hole tool's support sleeve on the inside, and the cutting part on the outside of the bumper casing.
  • Page 28 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Applies to the right-hand side Ensure that the marking on the hole tool (RH) and the marking that was made on the bumper cover are opposite each other. Note! Ensure that the support sleeve does not turn when the screw is tightened.
  • Page 29 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Clean using isopropanol. IMG-297555 IMG-331353 © Volvo Car Corporation Parking assistance, rear- 31201126 - V1.4 Page 29 / 40...
  • Page 30 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Apply a thin and even layer of activator. Allow to dry for at least 10 minutes. Use: 8637076 Activator. IMG-297557 Apply a thin and even layer of activator. Allow to dry for at least 10 minutes.
  • Page 31 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden IMG-308086 IMG-297563 IMG-297564 © Volvo Car Corporation Parking assistance, rear- 31201126 - V1.4 Page 31 / 40...
  • Page 32 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Locate the taped connector and connect it to the control module. IMG-297565 IMG-297561 © Volvo Car Corporation Parking assistance, rear- 31201126 - V1.4 Page 32 / 40...
  • Page 33 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden The cable harness will not be used again. IMG-297562 IMG-297566 IMG-297567 © Volvo Car Corporation Parking assistance, rear- 31201126 - V1.4 Page 33 / 40...
  • Page 34 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Apply two pieces of tape. Remove the protective film from the tape. IMG-297568 Apply a thin and even layer of adhesive. The adhesive must be above the tape level. Use: 9512950 Adhesive gun, 1161730 Mixing pipe and 9511027 Adhesive.
  • Page 35 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden IMG-297571 Press the holder towards the casing, but only at the places where there is tape. IMG-297572 © Volvo Car Corporation Parking assistance, rear- 31201126 - V1.4 Page 35 / 40...
  • Page 36 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Hold the cradle securely when removing the centering tool. Repeat the method steps on the other cradle. IMG-297573 Apply two pieces of tape. Remove the protective film from the tape. IMG-297574 Apply a thin and even layer of adhesive. The adhesive must be above the tape level.
  • Page 37 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Repeat the method steps on the other cradle. IMG-297576 IMG-297577 IMG-297578 © Volvo Car Corporation Parking assistance, rear- 31201126 - V1.4 Page 37 / 40...
  • Page 38 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden IMG-297579 IMG-297583 © Volvo Car Corporation Parking assistance, rear- 31201126 - V1.4 Page 38 / 40...
  • Page 39 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Note! Connect the painted sensors in the middle. IMG-297585 IMG-297603 Reinstall the detached components in reverse order. IMG-297604 © Volvo Car Corporation Parking assistance, rear- 31201126 - V1.4 Page 39 / 40...
  • Page 40 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Download the software for the accessory's function following the service information in VIDA. IMG-242268 © Volvo Car Corporation Parking assistance, rear- 31201126 - V1.4 Page 40 / 40...
