Certain steps in the instructions are only presented in the form of images. Explanatory text is also given for more complicated steps. In the event of any problems with the instructions or the accessory, contact your local Volvo dealer. Note! This accessory requires software unique to the car. Note! During installation the underlay must be kept at a temperature of at least +15°C (60°F).
Page 6
Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Remove the rear floor hatch. Open the rear floor hatch and pull it straight backwards. Place the floor hatch to one side. Turn the handles on the storage box on the right and left-hand sides.
Page 7
Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Applies to cars with lining mats with four perforations Remove the perforated sections (3) from the lining mat. Applies to cars with lining mats with one perforation Remove the lining mat. Applies to all cars Remove the 4 x nuts (1) in the rear cross member.
Page 8
Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Removing the rear bumper (applies to the XC70) Illustration A Drill out the rivets (1 x per side). Illustration B Detach the screws (5), one on each side, until the mounting releases from the bumper cover.
Page 9
Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Clean the outside of the bumper Install the backing paper evenly distributed over the bumper. Note! The backing paper is used to protect the paint. M8600423 Fold up the catches, 1 x per side Remove the 13 x hooks Remove the foam and the bumper rail from the bumper cover.
Page 10
Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Installing the sensors Applies to the V70 Pre-drill the holes through the centre of the markings (1). Use a Ø3 mm (1/8”) diameter drill bit. Drill from the inside of the bumper cover.
Page 11
Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Enlarge the holes in the bumper cover. Use a Ø31 mm (17/32”) diameter hole cutter (P/N 9814069). M8600666 Clean the inside of the bumper cover using a mild soap solution. Clean around the holes and their inner edges with a cleaning cloth (P/N 9192678).
Page 12
Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Apply a thin layer of activator on the cleaned surfaces. Allow to dry. Remove the yellow protective film from one side of the tape Secure the tape on the sensor holder Carry out the above procedure on the remaining three sensor holders.
Page 13
Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Illustration A Use assembly tools and blind rivets with spacers from a separate kit. Illustration B Attach the skid plate to the bumper cover. Install the four blind rivets. M8601277 M8601278 Connect the cable harness connectors to the sensors.
Page 14
Paint the sensors and holders using the same colour code paint as the car. Use paint recommended by Volvo. Apply a maximum of two coats. When the paint has dried, remove the backing paper.
Page 15
Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Lift the bumper into position Pull the cable harness for the sensors through the hole for the left guide of the bumper and pull in the cable from the inside M8601246 Illustration A applies to the V70 Hint This operation is easier with two people.
Page 16
Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Applies to cars with lining mats with four perforations Install the rubber tabs from the kit over the 4 x installed screws as follows: Align the rubber tabs (1, 4) edge to edge with the lining mat. If...
Page 17
Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Connect the cable harness for the sensors, previously routed, to the control module. D3904975 Clean the vertical panel surface under the member where the control module will be located. Use a mixture of 30% windscreen...
Page 18
Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Installing the switch Installing the switch Remove the cover plug to the 12V socket. M3904985 Carefully remove the switch panel. Use a scriber with an angled point. Pull out one corner of the panel using the scriber. Pull until the hooks release.
Page 19
Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Remove the dummy button and install the new switch (1) in any available position. Reinstall the surround and the cover plug. D8502226 Finishing work Finishing work Reinstall: the battery cover and holder...
