Installation instructions, accessories

Volvo Car Corporation Gothenburg, Sweden

Instruction No

Version

31330676

1.4

Part. No.

30758088, 9487266, 30786087, 31359215

Parking assistance, rear

Parking assistance, rear- 31330676 - V1.4

Page 1 / 23

Need help?

Do you have a question about the 30758088 and is the answer not in the manual?

Questions and answers

Summary of Contents for Volvo 30758088

Page 1 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Instruction No Instruction No Version Version Part. No. Part. No. 31330676 31330676 30758088, 9487266, 30786087, 31359215 30758088, 9487266, 30786087, 31359215 Parking assistance, rear Parking assistance, rear © Volvo Car Corporation Parking assistance, rear- 31330676 - V1.4...
Page 2 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Equipment IMG-242205 A0000162 IMG-239981 IMG-273465 IMG-330289 IMG-333288 IMG-333293 IMG-332314 IMG-346081 © Volvo Car Corporation Parking assistance, rear- 31330676 - V1.4 Page 2 / 23...
Page 3 Explanatory text is also given for more complicated steps. In the event of any problems with the instructions or the accessory, contact your local Volvo dealer. Note! During installation, the car and components must maintain a temperature of at least +20° C (68° F).
Page 4 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Carefully mat down the surface. Use Glasspaper, grade P1000. IMG-352601 Clean the sensors again. Use: Isopropanol. Allow to dry. Avoid contact with the cleaned surfaces. IMG-346082 Clean the cradles. Use: Isopropanol. Allow to dry.
Page 5 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Apply a thin and even layer of primer to the cleaned plastic surface. Caution! Not on the centre of the sensor. Use: Bonding primer for plastic. P/N: 31335448. Hint Spray primer into the cap of the can and apply with a brush.
Page 6 Caution! Protect the connections' contact surfaces against paint. Paint the sensors in the same colour code as the vehicle. Use Volvo Touch-up paint (Only use base coat.) Use: Volvo 2-K Varnish. P/N: 31335447 Note! Also read the instructions on the spray can.
Page 7 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Remove the cargo compartment carpet. IMG-273472 Prize off the four external clips at the front edge/bottom edge of the sill trim panel on the tailgate. Pry up one of the corners of the sill trim panel so that the two clips at that end release.
Page 8 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Grasp the upper edge of the right-hand side cushion. Pull the side cushion forward so that the clip on the reverse releases. Slide the side cushion up. Remove the side cushion. J8504708 Remove the screw.
Page 9 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Fold out the anchorage eyelets. Insert a scriber with an angled tip into the holes in the top of the covers (1). Turn the scriber so that the tip engages the reverse of the cover. Pull the covers off.
Page 10 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Remove the end of the bumper cover. Grasp the bumper cover inside the wing liner. Pull carefully until the six catches at the top edge release. Repeat on the other side. J8504526 Remove the bumper cover by pulling it straight backwards.
Page 11 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Drill out the centre of the markings. 1. Ø 3 mm (7/64 ") 2. Ø 10 mm (25/64 ") IMG-346089 Use hole tool part no. 9997345 to make holes in the bumper cover.
Page 12 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Caution! Place the hole tool's support sleeve on the inside, and the cutting part on the outside of the bumper casing. Make the holes in the bumper cover using the hole tool.
Page 13 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Apply a thin and even layer of activator to the cleaned surfaces where the tape is to be attached. Use: 8637076. Allow to dry. IMG-346094 Apply a thin and even layer of activator to the cleaned surfaces where the tape is to be attached.
Page 14 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Applies to cars with the Keyless system Disconnect the cable (1) at both ends and remove it. It will no longer be used. The cable is internally connected to a gray connector below the right tail lamp.
Page 15 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Release the secondary locking by pressing the catch down and pulling the locking straight out. IMG-222068 Caution! Note the location of the cables in the connector. Disconnect all cable lugs from the connector. Use special tool 9512810 or 9512632.
Page 16 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Applies to all models Take the cable harness with the rubber grommet from the kit. Pull in the end with four connectors through the hole in the car and fit the rubber grommet.
Page 17 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Connect: black connector to the control module's upper port. brown connector to the control module's lower port. IMG-346588 Disconnect the existing 6-pin connector from the car's normal cable harness. IMG-346589 © Volvo Car Corporation Parking assistance, rear- 31330676 - V1.4...
Page 18 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Connect the connector to the cable harness for parking assistance. Secure the connectors to the panel edge. Applies to cars with the Keyless system Plug the gray connector into the corresponding gray connector.
Page 19 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Applies to cars with an accessory electronic module (AEM) The car's usual green connector is connected to the cable harness for the AEM. Disconnect this connector. IMG-346591 Connect the removed connector to the taped connector (1) on the cable harness for PAM.
Page 20 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Check which holders are to be placed where before installing. Each holder is marked and has its own specific place. The holders must be positioned as illustrated. A: Right outer B: Right inner...
Page 21 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Caution! The adhesive must not come into contact with the tape or the cradle's protruding ring. The task of the tape is to secure the cradles to the bumper cover until the adhesive has cured after approximately 24 hours.
Page 22 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Press the cable harness into the catches on the 2 middle holders. IMG-273505 Secure the cable harness using butyl tape. IMG-273473 Lift up the bumper cover into position. Plug the sensors' connector into the connector secured below the right-hand tail lamp.
Page 23 Installation instructions, accessories Volvo Car Corporation Gothenburg, Sweden Gather together any excess cables. Clamp the cables securely where they cannot rub or become damaged. Refit the panels and remaining parts removed in reverse order. Download the software for the accessory's function following the service information in VIDA.
