Installation and Operating Instructions
Sizes and Specifications, Concessionaire Dispensers
MODEL NOS.
KEG CAPACITY
DIMENSIONS Length Ins. (mm)
CABINET Depth Ins. (mm)
Height Ins. (mm)
NO. OF DISPENSING HEADS
NO. FAUCETS
CONDENSER UNIT H.P.
RUNNING LOAD - AMPS
SHIP WT lbs. (kg)
INTERIOR
EXTERIOR
STORAGE COMPARTMENTS
REFRIGERATION
VENTILATION
ELECTRICAL
PLUMBING
INSULATION
OPTIONAL ACCESSORIES
Form No. Z2060A
Rev. 12.05.03
DC2KP
2 Keg
72" (1829)
24 / " (613)
1
8
34 1 / " (876)
2
1
2
1 /
4
5.9
445 (202)
Fourteen gauge stainless steel sills are reinforced with a 12 gauge angle bracket that extends from one
end of the insulated base to the other. The floor pan is 20 gauge, type 304 stainless steel. The walls and
ceiling are 20 gauge galvanized steel.
The top is 20 gauge stainless steel. Bottom is 20 gauge stainless steel. Doors, front, back and sides are
20 gauge black powder coated steel.
Side compartment houses a four gallon stainless steel drainer overflow tank, two drain valves with garden
hose fittings for cabinet floor drain and overflow tank, and 20 lb. CO
provides storage for cups or other non-refrigerated items.
R-134a capillary tube-type. Aluminum fin and copper tube evaporator coil. Forced air into dispensing head.
Adjustable temperature control. Self-defrosting. Pull-out condensing unit for service and cleaning.
Front ventilated.
115 Volt, 60 Hz., 1 Phase AC. Furnished with three prong, six foot rubber cord.
Contact Perlick for other voltage/frequency requirements.
None required. Condensate evaporates automatically.
Foamed-in-place polyurethane; 2" walls, 1
• Optional Dispensing Heads
• Keg Couplers
Perlick is committed to continuous improvement. Therefore, we reserve the right to change specifications without prior notice.
DC3KP
3 Keg
84" (2134)
24 / " (613)
1
8
34 1 / " (876)
2
1
2
1 /
3
7.5
505 (229)
1 / " top and floor.
2
• Shelf Kit • Faucet Locks
• Regulators
2
DC4KP
4 Keg
96" (2438)
24 / " (613)
1
8
34 1 / " (876)
2
2
2
1 /
3
7.5
545 (247)
drum holder. Front compartment
2
