INSTALLATION AND OPERATION INSTRUCTIONS
CONCESSIONAIRE PORTABLE DISPENSERS
IMPORTANT INFORMATION
Complete the enclosed warranty card and mail to the
Perlick Corporation to register the warranty. If the
card is not returned, the warranty period will begin
from the date the equipment is shipped from the
factory.
This manual has been prepared to assist you in the
installation of your Concessionaire Dispenser and to
acquaint you with its operation and maintenance.
We dedicate considerable time to ensure that our
products provide the highest level of customer
satisfaction. If service is required, your dealer can
provide you with a list of qualified service agents. For
your own protection, never return merchandise for
credit without our approval.
We thank you for selecting a Perlick product and
assure you of our continuing interest in your
satisfaction.
WARNING: When lifting, the full weight of the
cabinet must be supported. Lift from the cabinet
base and not from the top. Improper lifting can
result in severe damage to the cabinet.
8300 West Good Hope Road • Milwaukee, WI 53223 • Phone 414-353-7060 • Fax 414-353-7069
Toll Free 800-558-5592 • E-Mail: Perlick@Perlick.com • www.Perlick.com
MODEL NOS.
DC Series
Table of Contents
Specifications.........................................................2
List of Included Parts.............................................3
Tools Required.......................................................3
Plumbing................................................................3
Electrical ................................................................3
Installing Casters ...................................................3
TAPPING
Connecting the Keg Coupler .................................4
Tapping the Keg.....................................................4
Connecting the Regulator......................................5
Adjusting Gas Flow................................................5
Leak Test .......................................................5
2
Gas Cylinder..............................5
2
Gas .................................................5
2
Beer Temperature ..................................................6
CLEANING
Cleaning the Beer Lines ........................................7
Cleaning the Cabinet .............................................7
How to Pour a Perfect Glass of Beer ....................8
Troubleshooting .....................................................9
Beer Facts .............................................................9
REPLACEMENT PARTS ................................10-11
Wiring Diagram....................................................12
Form No. Z2060A
Rev. 12.05.03
Advertisement
Table of Contents
Related Manuals for Perlick DC Series
Summary of Contents for Perlick DC Series
-
Page 1: Table Of Contents
For your own protection, never return merchandise for credit without our approval. We thank you for selecting a Perlick product and assure you of our continuing interest in your satisfaction. WARNING: When lifting, the full weight of the cabinet must be supported. -
Page 2: Specifications
INSULATION Foamed-in-place polyurethane; 2” walls, 1 OPTIONAL ACCESSORIES • Optional Dispensing Heads • Keg Couplers Perlick is committed to continuous improvement. Therefore, we reserve the right to change specifications without prior notice. Form No. Z2060A Rev. 12.05.03 DC2KP DC3KP 2 Keg 3 Keg 72”... -
Page 3: Preparing The Cabinet For Use
HOUSING SCREWS CENTER CASTERS REQUIRED ON DC4KP (4 KEG CONCESSIONAIRE) Perlick is committed to continuous improvement. Therefore, we reserve the right to change specifications without prior notice. Concessionaire Dispensers Plumbing None required. Garden hose connections for dumping liquid wastes. Electrical... -
Page 4: Connecting The Keg Coupler
Tighten clamp with screwdriver. CAUTION: Do not use keg coupler as a handle to lift keg. Perlick is committed to continuous improvement. Therefore, we reserve the right to change specifications without prior notice. Form No. Z2060A Rev. 12.05.03 Concessionaire Dispensers... -
Page 5: Connecting The Regulator
Turn CO hand valve clockwise until seated and close shut-off valve on regulator. Perlick is committed to continuous improvement. Therefore, we reserve the right to change specifications without prior notice. Concessionaire Dispensers Unscrew regulator from cylinder fitting. Replace carbonic washer (Part No. 157F2P), if needed and reattach regulator to filled cylinder. -
Page 6: Temperature
36-41 degrees F. The control is factory set at 38 degrees F. Perlick is committed to continuous improvement. Therefore, we reserve the right to change specifications without prior notice. Form No. Z2060A Rev. 12.05.03 Concessionaire Dispensers At temperatures lower than 30°... -
Page 7: Cleaning The Beer System
The beer faucet may exhibit a white colored substance (yeast build up) if not cleaned on a regular basis. Perlick is committed to continuous improvement. Therefore, we reserve the right to change specifications without prior notice. Concessionaire Dispensers Beer Stone: All beer contains calcium which is present from the grains used in the brewing process. -
Page 8: General Information How To Pour A Perfect Glass Of Beer
Pouring a Perfect Glass of Beer – Perlick is committed to continuous improvement. Therefore, we reserve the right to change specifications without prior notice. Form No. Z2060A Rev. 12.05.03 Concessionaire Dispensers STEP 1 Start with a clean glass. Place the glass at a 45°... -
Page 9: Troubleshooting
Cooler is too cold. leak or defective (sticking) check valve. Sluggish CO regulator. Perlick is committed to continuous improvement. Therefore, we reserve the right to change specifications without prior notice. Concessionaire Dispensers Cloudy Beer: Beer in glass appears hazy, not clear. AUSES Dirty glass. -
Page 10: Replacement Parts
SC BB Fin coil, evaporator Shelf kit, center Three-way air distributor assembly Four-way air distributor assembly Perlick is committed to continuous improvement. Therefore, we reserve the right to change specifications without prior notice. Form No. Z2060A Rev. 12.05.03 Concessionaire Dispensers DC2KP... -
Page 11: Replacement Parts
57F2P ...CO tank washer 1392R ...Red air hose 529 ...Beer hose 2928D ...Twin gauge CO regulator Perlick is committed to continuous improvement. Therefore, we reserve the right to change specifications without prior notice. Concessionaire Dispensers Form No. Z2060A Rev. 12.05.03... -
Page 12: Wiring Diagram
8300 West Good Hope Road • Milwaukee, WI 53223 • Phone 414-353-7060 • Fax 414-353-7069 Toll Free 800-558-5592 • E-Mail: Perlick@Perlick.com • www.Perlick.com Perlick is committed to continuous improvement. Therefore, we reserve the right to change specifications without prior notice. Form No. Z2060A...
