Santa Fe Freight
Ready-To-Run O-27 Set
Owner's Manual
CAUTI O N—ELECTRI C TOY
NOT RECOMMENDED FOR CHILDREN UNDER EIGHT YEARS OF AGE. AS WITH
ALL ELECTRIC PRODUCTS, PRECAUTIONS SHOULD BE OBSERVED DURING
HANDLI N G AND USE TO REDUCE THE RI S K OF ELECTRI C SHOCK.
TRANSFORMER RATINGS—I N PUT:120 VAC; 60 HZ ONLY.
AC OUTPUT:18 V; 80 VA
Advertisement
Table of Contents
Related Manuals for Lionel Santa Fe Freight O-27
Summary of Contents for Lionel Santa Fe Freight O-27
- Page 1 73-1916-250 5/01 Santa Fe Freight Ready-To-Run O-27 Set Owner’s Manual CAUTI O N—ELECTRI C TOY NOT RECOMMENDED FOR CHILDREN UNDER EIGHT YEARS OF AGE. AS WITH ALL ELECTRIC PRODUCTS, PRECAUTIONS SHOULD BE OBSERVED DURING HANDLI N G AND USE TO REDUCE THE RI S K OF ELECTRI C SHOCK. TRANSFORMER RATINGS—I N PUT:120 VAC;...
-
Page 2: Table Of Contents
Congratulations! ou’re now the proud owner of the Lionel cedures to help your train live a long, Santa Fe Freight set. Everything you healthy life. need to get started is included. You’re If you have any questions after reading already off to a great start by reading this this booklet, contact your nearest Lionel instruction manual. - Page 3 Lionel Service at (when applicable) are correct. 810-949-4100. The parts list below will tell you what’s •...
-
Page 4: Track Layout
Lionel maintenance kit (no. 6-62927), joining the entire track section. which is available from your Lionel If the openings become too open (causing Authorized Value Added Dealer. the track to fit loosely), pinch the rail... -
Page 5: Controller Operations
Controller operations Stripping the wire nce your track is assembled and the stripped back about 1⁄4” to 3⁄8”. To lockon is secure- strip the wires, use a pair ly attached, you of wire strip- can connect the pers or a wires from the sharp knife. -
Page 6: Remote Operating Track Hookup
Controller operations Remote operating track hookup he remote operating track will open cou- 2. The other end of this wire connects to one plers and activate the log dump car. To screw on the uncoupling button. hook it up, just follow these simple instruc- 3. -
Page 7: Train Operation
Move ‘em out! • Get your locomotive moving. Press the DIR button on your Lionel trans- former. This sequences the Lionel 103-1 reverse unit to the next operating state. The 103-1 unit alternates between three states: forward, neutral, and reverse. -
Page 8: Your Locomotive's 103-1 Reverse Unit
Train operations Your locomotive’s 103-1 Reverse unit he reverse unit inside your Lionel loco- the switch is thrown back, the locomotive motive is an electronic device that acts will be “locked” in neutral. If the switch is like the transmission in your car. When you... -
Page 9: Using Your Locomotive's Magnet Coupler
Train operations Using your locomotive’s magnetic coupler he rear of your Lionel locomotive’s ten- field pulls the disc downward, and the der is equipped with an operating mag- knuckle opens. netic knuckle cou- One operating pler, a revolutionary technique favored by... -
Page 10: Coupling
Train operations Coupling fter you have assembled the track, place the mating couplers must be open as shown the locomotive and rolling stock on the below at the left. Now simply push the cars track. Before coupling the cars, make sure toward each other until they lock together. -
Page 11: Maintaining And Servicing Your Set
Maintaining and servicing your set Lubricating your steam locomotive elp your Lionel steam locomotive lead a dust before lubricating, and always lubricate long and productive life on your rail- any locomotive emerging from prolonged road by maintaining it properly. storage. Also, lightly lubricate the steam We recommend you purchase a Lionel locomotive’s side rods after each 10 hours of... -
Page 12: Replacing Your Locomotive Lamps
(see The smoke generator requires the periodic page 9 for location). Move the switch to OFF addition of Lionel smoke fluid in order to and your locomotive will stop smoking. function. Pierce the tube end with a pin,... -
Page 13: Log Dump Car Operation
With the press of reacts to the magnetic a button, the log field generated by the cradle automatically Lionel remote-control tilts, delivering the log track section. See below and load to the tray at the side on page 7 for more information on of the track. -
Page 14: Replacing Your Square Window Caboose Lamp
To remove the lamp, pull it straight up. and roof. The end frames are hinged to the Replace it with Lionel bulb no. 600-8352-311, platform. This allows the end frame to bend available at your local Lionel Authorized downward, away from the body. -
Page 15: Horse Placement
Maintaining and servicing your set Horse placement o place the horses inside of the live- stock car, unscrew the screw at the front of the car and remove the body. Insert the horses in the slots of the tray. Replace the body and the screw. -
Page 16: Lionel Service
Station, together with proof of original purchase Please make sure you have followed all of the will, at the option of Lionel L.L.C., be repaired or above instructions carefully before returning any replaced, without charge for parts or labor. In the merchandise for service.
