Extech Instruments MN26 User Manual page 3

Function
AC Current
(A AC)
(40 - 400Hz)
(40 - 200Hz for
400µA, 4mA
ranges)
Resistance
Capacitance
Frequency
Duty Cycle
Temp °F
Temp °C
NOTE: Accuracy is stated at 65
NOTE: Temperature range of the temperature probe may be less than the range of the
meter.
Function
V DC, VAC
Ohms, Capacitance, Diode, Frequency,
Continuity
mA DC/AC
10A DC/AC
Range Resolution
400µA 0.1µA
4000µA 1µA
40mA 0.01mA
400mA 0.1mA
10A 0.01A
400Ω 0.1Ω
4kΩ 0.001kΩ
40kΩ 0.01kΩ
400kΩ 0.1kΩ
4MΩ 0.001MΩ
40MΩ 0.01MΩ
4nF 0.001nF
40nF 0.01nF
400nF 0.1nF
4µF 0.001µF
40µF 0.01µF
200µF 0.1µF
9.999Hz 0.001Hz
99.99Hz 0.01Hz
999.9Hz 0.1Hz
9.999kHz 0.001kHz
99.99kHz 0.01kHz
999.9kHz 0.1kHz
9.999MHz 0.001MHz
Sensitivity: 0.8V rms min. @ 20% to 80% duty cycle and <100kHz;
5Vrms min @ 20% to 80% duty cycle and > 100kHz.
0.1 to 99.9% 0.1%
-4 to 1400°F* 1°F
-20 to 760°C* 1°C
o o
F to 83 F (18
Input Limits
Accuracy
±(1.8% reading + 5 digits)
±(3.0% reading + 7 digits)
±(1.2% reading + 4 digits)
±(1.2% reading + 2 digits)
±(2.0% reading + 3 digits)
±(5.0% reading + 10digits)
±(5.0% reading + 7 digits)
±(3.5% reading + 5 digits)
±(5.0% reading + 5 digits)
±(1.5% reading + 5 digits)
±(1.2% reading + 2 digits)
±(1.5% reading + 4 digits)
±(1.2% reading + 2 digits)
Pulse width: 100µs - 100ms
±(3.0% reading + 3 digits)
(probe effect additional)
o o
C to 28 C) and less than 70% RH.
Maximum Input
600V DC/AC
250V DC/AC
400mA DC/AC
10A DC/AC (30sec. max)
3 MN26T V4.0 05/05
