8.8 Archon to OI 4460 / 4560 with Varian 3400/3600, P/N DY-505870-00

Female
Remote I/O Archon
Desorb
15
Drain
2
Start 5
Purge 18
P&T
14
Ready
1
Attach the "D" connector of the cable to the Archon. Be certain the locking screws secure the
connector to the chassis.
Attach connectors P16 and P23 to the Varian GC (J16 and J23 on the Motherboard) and secure
the grounding clamp to the GC chassis.
Attach the individual wires to the Relay I/O terminal at the rear panel of the OI concentrator.
The remaining cable can be used to start the data system.
Refer to the above schematic for the correct wiring locations and to your GC and Data System
manuals for correct connector locations.
8-12
Pin Outs
Relay I/O
Color OI Function
Terminal
Green 5 Start Purge
Brown 4 Start Purge
Red 7
White 8
6 GC Starat
7 GC Start
Blue 1
Black 2
5 Start
Start
4 Start
P 2 3
P 1 6
R ed
W h ite
B lack
J16-J23
Color Varian
Motherboard
P16
Red 3
Black 4
P23
Green 3
White 1
Red
White
Black
