Chapter 1 Product Overview; Technical Specifications - Ruijie Networks RG-AP320-I Series Hardware Installation And Reference Manual

The RG-AP320-I series wireless LAN access point is designed by Ruijie Networks for demanding indoor deployments.
The AP is equipped with Ruijie patented X-sense antennas. It can serve as a Fit AP and operate in conjunction with a
unified wired/wireless switch or a wireless controller; or it can serve as a standalone Fat AP and provide wireless access
for mobile clients.

Technical Specifications

Table 1-1 Technical Specifications of RG-AP320-I
Model
Interfaces
Antennas
Operating
Frequency
Modulation Types
Transmit Power
Transmit Power
Adjustment
Receiver Sensitivity
Status LED
Temperature
Humidity
IP Rating
Power Adapter
PoE
Security Lock
Radio Approvals
EMC Compliance

Chapter 1 Product Overview

RG-AP320-I
One 10/100/1000BASE-T Ethernet PoE port
One Console port
Internal Ruijie X-sense smart antenna arrays (up to 65536 combinations)
802.11b/g/n: 2.4 GHz to 2.4835 GHz
802.11a/n: 5.15 GHz to 5.85 GHz
(Depending on the country in which the AP is installed)
802.11b: BPSK, QPSK, CCK
802.11a/g/n: BPSK, QPSK, 16-QAM, 64-QAM
2.4 GHz (802.11b/g/n): 20 dBm
5G GHz: (802.11a/n): 20 dBm
1 dBm
802.11b: -99 dBm (1 Mbps), -93 dBm (5.5 Mbps) , -90 dBm (11 Mbps)
802.11a/g: -93 dBm (6 Mbps), -85 dBm (24 Mbps), -82 dBm (36 Mbps), -77 dBm (54 Mbps)
802.11n: -92 dBm@MCS0, -74 dBm@MCS7, -92 dBm@MCS8, -73dBm@MCS15
Single LED
Color: red, green, blue and orange
Mode: solid, blinking, breathing and silent (turn off)
Operating: -10 to 55℃ (14 to 131 ℉)
Storage: -40 to 70℃ (-40 to 158 ℉)
Operating: 5% to 95% noncondensing
Storage: 5% to 95% noncondensing
IP41
48 V DC (power adapters are optional parts)
IEEE 802.af/at PoE
Supported
China Radio Transmission Equipment Type Approval Certificate
EN300 328
EN301 893
GB9254
EN301 489
