8W - 80 - 14 8W-80 CONNECTOR PIN-OUTS
C130 (GAS) (IN PDC) - (HEADLAMP AND DASH
SIDE)
CAV CIRCUIT
1 V35 20LG/RD
2 V32 20YL/RD
3 A14 16RD/WT
4 A142 14DG/OR
5 -
6 A93 12RD/BK
7 K118 20PK/YL
8 L1 18VT/BK
9 -
10 -
11 V40 22WT/PK
12 L10 18BR/LG
13 D1 20VT/BR
14 K51 20DB/YL
15 C13 22DB/OR
16 D20 20DG
17 D2 20WT/BK
18 K4 22BK/LB
19 C90 22LG/WT
20 D21 20PK/DB
21 C3 22DB/BK
22 V37 22RD/LG
23 K226 20DB/WT
24 V36 18TN/RD
25 Y128 18DG/GY (8.0L)
26 T41 22BK/WT
27 K31 20BR/WT
28 F18 20LG/BK
29 K30 22PK (A/T)
30 A341 20DG/YL (CALIFORNIA)
31 T16 18RD
32 -
33 G7 20WT/OR
34 T6 22OR/WT (A/T)
35 T125 18DB (A/T)
36 K106 18WT/DG
37 K107 18OR
38 Y193 18WT/LG
39 Z12 18BK/TN
40 -
41 K145 20DG/PK
42 K52 18PK/WT
43 A141 20DG/WT (EXCEPT CALIFORNIA)
BR/BE
