- Page 1 Ponto Plus sound processors Instructions for Use Ponto – The Bone Anchored Hearing System...
-
Page 2: Thank You
We would like to take this opportunity to thank you for selecting a Ponto sound processor. Ponto Plus sound processors are intended to be used to improve the hearing for patients with conductive and mixed hearing losses as well as single-sided deafness. It is designed so that it can be optimized for each individual person. -
Page 3: Table Of Contents
Contents The Ponto bone anchored hearing system Skin hygiene Instrument view Accessories Managing the battery Ponto Streamer Turning it ON and OFF or stand-by Service and repair Connection Common problems and Disconnection their possible solutions Correct position Manufacturer’s warranty Volume control Important information Programs Warnings... -
Page 4: The Ponto Bone Anchored Hearing System
In this way it works independently of the function of the ear canal and middle ear. Ponto Plus is therefore a possible solution to hearing losses where there is a problem in the outer or middle ear preventing sound from reaching the inner ear. - Page 5 Abutment Sound Implant processor...
-
Page 6: Instrument View
7. Hole for safety line 8. Labeling Right or left version: Ponto Plus sound processors are available in a left and a right hand version. Each sound processor is marked with an L (left) or R (right) on the battery door... - Page 7 Picture shows Ponto Plus. Instrument view is identical on Ponto Plus Power. WarnIng The sound processor contains small parts that may be a choking hazard for small children. Batteries can also be harmful if swallowed. Always keep batteries out of reach of small children or people of diminished mental capacity.
-
Page 8: Managing The Battery
It is very important to insert the battery correctly to avoid damaging the battery compartment. Ponto Plus: Only use high quality zinc-air batteries, type 13. Ponto Plus Power: Only use high quality zinc-air batteries, type 675. Tamper-resistant battery door To lock the battery door: Make sure the door is completely closed. - Page 9 When the battery is completely worn out this will be indicated by four consecutive beeps. The battery lifetime depends upon the listening environment. The battery lifetime of Ponto Plus is usually between 80-140 hours and between 80-160 hours for Ponto Plus Power. Battery removal After opening the battery door the battery can be removed.
-
Page 10: Turning It On And Off Or Stand-By
Turning it On and OFF or stand-by Ponto Plus is turned ON by closing the battery door. After a start-up jingle there is a few seconds delay before the sound processor is turned on. The delay is designed to avoid a whistling sound while connecting your sound processor to the abutment. - Page 11 Note: The stand-by feature is optional and may sometimes be disabled during the fitting procedure. Talk to your hearing center if you have questions. Stand-by/Mute – Press and hold until 2 beeps are heard Off...
-
Page 12: Connection
Connection To safely and comfortably connect the sound processor, tilt it slightly and carefully push it onto the abutment. Please note it is important to keep hair out of the way when the sound processor is connected to the abutment. -
Page 13: Disconnection
Disconnection The sound processor is safely and comfortably disconnected by carefully tilting it away from the abutment. -
Page 14: Correct Position
Correct position To get optimum performance from the directional microphone system, the sound processor should be positioned vertically with the microphones at the bottom and the volume control facing backwards. Please note it is important that the sound processor does not touch anything, e.g. the ear, skin or a hat. - Page 15 Microphones Correct position Incorrect position...
-
Page 16: Volume Control
Volume control The volume is increased by turning the volume control upwards and decreased by turning it downwards. When the volume control is turned, beeps can be heard to indicate that the volume is being changed. When the maximum or minimum volume has been reached the beeps will cease. - Page 17 ...
-
Page 18: Programs
Programs With the push button you can put your sound processor in stand-by mode or change listening program. By default your sound processor has one program, your hearing care professional can define more. To change program, simply press and release the push button. The next program will be indicated by a corresponding number of beeps. - Page 19 Program Beeps Description Ask your hearing center for information on programs to fill out this program chart.
-
Page 20: Sound Processor Maintenance
Sound processor maintenance A dry cloth or baby wipe may be used to clean the outside of the sound processor. Special attention should be given to the coupling to remove any dirt or entangled hair. Please note no water or liquids should be used when cleaning your sound processor – is not waterproof. -
Page 21: Skin Hygiene
Only very soft brushes should be used. If you have two implants, you should use two soft brushes – one for each abutment. Soft brushes, like the one pictured, can be purchased from Oticon Medical. Ask your hearing center for more information. - Page 22 Cleaning every few days In addition to the daily cleaning routines the skin should be cleaned more thoroughly to remove debris at least twice a week. During hair washing, debris becomes softer and is more easily removed. The cleaning brush should still be used with care. If you have persistent problems with soreness surrounding the abutment, contact your ear clinic.
-
Page 23: Accessories
accessories Safety line The safety line is designed to help you avoid dropping your sound processor during for example physical activity or in other situations where there is a great risk that the device may fall off. To avoid dropping your sound processor attach the safety line to the sound processor and the clip to your clothing. - Page 24 The test rod allows you to listen to the sound processor without connecting it to an abutment. Connect your Ponto Plus to the test rod and press it against your head to listen to the sound processor. This is also useful for demonstrating and testing your Please note your hand must not touch the sound processor for your friends and family.
- Page 25 Push button stickers The stickers provide you with the opportunity to adapt the looks of your sound processor. How to apply and remove the sticker: 1. Remove the application film with the chosen sticker connected to it from its sheet. 2.
-
Page 26: Ponto Streamer
Ponto Streamer The Ponto Streamer allows you to wirelessly connect your Ponto Plus sound processor to different audio sources and transmit the sound from the source to your sound processor. The Ponto Streamer also acts as a remote control for your sound processor. It is worn around the neck and features three buttons for core applications: phone, TV and microphone. - Page 27 Loop facilities are available in many public buildings such as theatres, cinemas, lecture halls, schools and similar locations. The telecoil in the Ponto Streamer picks up the signal from the teleloop and transmits the sound to Ponto Plus.
- Page 28 FM systems are used for example in schools to support hearing-impaired children. The teacher wears an FM trans- mitter which sends signals directly to Ponto Plus via the FM receiver and the Ponto Streamer.
-
Page 29: Service And Repair
Service and repair If your Ponto Plus sound processor does not function properly, contact your hearing center or ear clinic to get it checked: Contact person at hearing center – name and contact information: Contact person at ear clinic – name and contact information:... -
Page 30: Common Problems And Their Possible Solutions
Common problems and their possible solutions Symptom Possible causes no sound Worn-out battery Sound processor is in stand-by (mute) Intermittent Dirt in the coupling or sound inlet or reduced sound Moisture Worn-out battery Whistling noise Sound processor is touching something... - Page 31 Solutions Change battery pg. 8-9 Press push button pg. 10-11 Clean the sound processor pg. 20 Open the battery door and let the sound processor dry out in its case pg. 20 Change battery pg. 8-9 Check that the sound processor is correctly connected and is not touching anything pg.
-
Page 32: Manufacturer's Warranty
Please consult him/her for further information. If you have any comments or suggestions related to the Oticon Medical bone anchored hearing system, please use the e-mail address on the back of the manual to contact us. -
Page 33: Important Information
Important information • It is important to follow the skin hygiene guidelines, please contact your ear clinic if you have questions or concerns. • Always keep your sound processor in its box when it is not being worn so that it is protected from dust and dirt. - Page 34 • To avoid setting off metal detectors when travelling, your sound processor can be removed before passing through the security controls. Waste from electronic equipment must be handled according to local regulations.
-
Page 35: Warnings
• If you drop the sound processor, make sure the shell is not cracked or any parts of the sound processor have broken. If you find something wrong with your sound processor please contact Oticon Medical. • Never dispose of your sound processor, its parts or batteries by burning them. - Page 36 • Portable and mobile RF (radio frequency) communications equipment can affect the performance of your sound processor. • If you need to undergo MRI (Magnetic Resonance Imaging) the sound processor must be disconnected. The implant and the abutment can remain in place. When schedul- ing and visiting the location of your MRI be sure to inform the doctor or technician that you have a bone anchored system (for children and mentally disabled this responsi- bility falls under the care-giver).
- Page 37 Dysfunction in sound processors • The sound processor may stop functioning, for instance if the batteries are worn out. You should be aware of this possibility, in particular when you are in traffic or otherwise dependent on warning sounds. Possible side effects • The otherwise non-allergenic materials used in sound processors may in rare cases cause a skin irritation.
- Page 38 For USa only: Federal law restricts this device to sale by or on the order of a medical practitioner. A prospective user of a bone anchored sound processor should always have a medical evaluation by a licensed physician to ensure that all medically treatable conditions that may affect hearing are identified and treated before a sound processor is purchased.
- Page 39 Office locations: Canada Oticon Medical, LLC Oticon Medical/Oticon Canada Ltd. 580 Howard Avenue 6950 Creditview Rd, Unit 1 Somerset, NJ 08873 Mississauga, Ontario, L5N 0A6 Phone: 1-888-277-8014 Phone: 1-800-263-8700 info@oticonmedicalusa.com info@oticonmedical.ca...
