63602029GB.fm Page 23 Wednesday, October 24, 2007 5:17 PM
Remove the levelling feet by unscrewing.
Remove bottom bracket using an 8 mm socket or spanner.
Remove and replace pin using a 10 mm spanner to undo the
nut and a flat bladed screwdriver to remove the pin. You may
need to push the pin through from the underside to remove
fully.
Remove screw on base and replace on other side.
Remove blanking plates from unused side of the Fridge
Freezer and replace in holes left by the brackets.
Replace doors and brackets in reverse order.
When replacing feet take care to ensure the larger foot is on
the side without the bracket.
Check both doors are aligned horizontally and vertically, and
that the seals are closed on all sides before finally tightening
the bottom hinge
23
