English; Installation; Package Contents - US Robotics Wireless Ndx ADSL2+ Gateway Quick Installation Manual

Installation

English

Package Contents

! USRobotics Wireless
! 15V DC Power supply
! Ethernet cable
! Telephone cable
Physical Features
Front
The gateway has the following status LEDs:
Symbol Name
Power
WLAN
(Wireless Net-
work)
SecureEasySetup
WAN
(Internet)
ADSL
N
dx ADSL2+ Gateway
! Detachable Antennas
! Installation CD-ROM
! Quick Installation Guide
2 3
1 4
State
Off
Solid
Off
Solid
Flashing
Off
Solid
Blinking
Off
Flashing
Solid
Off
Solid
Flashing
Condition
Not receiving power.
Receiving power.
Wireless connection is disabled.
Wireless connection is enabled.
Sending and receiving data.
SecureEasySetup mode is not ready
on the gateway.
SecureEasySetup mode is ready.
Communicating with
SecureEasySetup devices.
No Internet connection established
or the gateway is in bridge mode.
Sending and receiving data.
Internet connection is established.
No ADSL connection.
ADSL link is achieved.
ADSL link is being established.
