- Page 1 323/324 PLUS Clamp Meter Users Manual December 2015 © 2015 Fluke Corporation. All rights reserved. Specifications are subject to change without notice. All product names are trademarks of their respective companies.
- Page 2 LIMITED WARRANTY AND LIMITATION OF LIABILITY This Fluke product will be free from defects in material and workmanship for two years from the date of purchase. This warranty does not cover fuses, disposable batteries, or damage from accident, neglect, misuse, alteration, contamination, or abnormal conditions of operation or handling.
-
Page 3: Table Of Contents
Table of Contents Title Page Introduction ......................... 1 How to Contact Fluke ....................1 Safety Information ...................... 2 Symbols ........................7 How to Clean the Product ..................9 Specifications ......................10 The Meter ........................15... - Page 4 323/324 PLUS Users Manual...
-
Page 5: Introduction
Introduction The Fluke 323/324 PLUS Clamp Meter (the Product) measures ac and dc voltage, ac current, resistance, and continuity. The 324 PLUS can also measure capacitance, contact temperature, and dc current. Note that the 324 PLUS is shown in all of the illustrations. For temperature measurement, you must use the included K-Type Thermocouple. -
Page 6: Safety Information
Users Manual • Singapore: +65-6799-5566 • Anywhere in the world: +1-425-446-5500 Or, visit Fluke's website at www.fluke.com. To register your product, visit http://register.fluke.com. To see, print, or download the latest manual supplement, visit http://us.fluke.com/usen/support/manuals. Safety Information A Warning identifies conditions and procedures that are dangerous to the user. A Caution identifies conditions and procedures that can cause damage to the Product or the equipment under test. - Page 7 Clamp Meter Safety Information XWWarning To prevent possible electrical shock, fire, or personal injury: • Use the Product only as specified, or the protection supplied by the Product can be compromised. • Use only correct measurement category (CAT), voltage, and amperage rated probes, test leads, and adapters for the measurement.
- Page 8 323/324 PLUS Users Manual • Do not apply more than the rated voltage, between the terminals or between each terminal and earth ground. • Comply with local and national safety codes. Use personal protective equipment (approved rubber gloves, face protection, and flame- resistant clothes) to prevent shock and arc blast injury where hazardous live conductors are exposed.
- Page 9 Clamp Meter Safety Information • Connect the common test lead before the live test lead and remove the live test lead before the common test lead. • Remove all probes, test leads, and accessories before the battery door is opened. •...
- Page 10 323/324 PLUS Users Manual • Remove batteries to prevent battery leakage and damage to the Product if it is not used for an extended period. • Remove batteries to prevent battery leakage and damage to the Product if is to be stored above its operating temperature. •...
-
Page 11: Symbols
Clamp Meter Symbols Symbols Table 1. Symbols Symbol Meaning Symbol Meaning AC (Alternating Current) Earth DC (Direct Current) AC and DC Current Conforms to European Union WARNING. RISK OF DANGER. directives. Consult user documentation. Battery WARNING. - Page 12 323/324 PLUS Users Manual Table 1. Symbols (cont.) Symbol Meaning Symbol Meaning Measurement Category II is applicable to test and MEASUREMENT CATEGORY III is measuring circuits connected applicable to test and measuring directly to utilization points circuits connected to the distribution ...
-
Page 13: How To Clean The Product
Clamp Meter How to Clean the Product Note The Measurement Category (CAT) and voltage rating of combinations of test probes, test probe accessories, current clamp accessories, and the Product is the LOWEST rating of individual components. How to Clean the Product Regularly wipe the case with a damp cloth and weak detergent. -
Page 14: Specifications
323/324 PLUS Users Manual Specifications Maximum voltage between any Terminal and Earth Ground ....600 V Range 323 ............ 400.0 A 324 PLUS .......... (40.00, 400.0) A Batteries ..........2 AAA, NEDA 24A, IEC LR03 Operating Temperature ......-10 °C to +50 °C Storage Temperature ...... - Page 15 Clamp Meter Specifications Weight 323 ............. 265 g 324 PLUS .......... 283 g Safety ............IEC 61010-1, Pollution Degree 2 IEC 61010-2-032: CATIV 300V / CATIII 600V IEC 61010-2-033: CAT IV 300V / CAT III 600V IP Rating ..........IEC 60529: IP30, non-operating Electromagnetic Compatibility (EMC) International IEC 61326-1: Portable, Electromagnetic Environment, IEC 61326-2-2...
- Page 16 323/324 PLUS Users Manual Korea (KCC) Class A Equipment (Industrial Broadcasting & Communication Equipment) Class A: Equipment meets requirements for industrial electromagnetic wave equipment and the seller or user should take notice of it. This equipment is intended for use in business environments and not to be used in homes.
- Page 17 Clamp Meter Specifications DC Current with Jaw (324 PLUS) Range ............. (40.00, 400.0) A Resolution ..........(0.01, 0.1) A Accuracy ..........2.0 % ±5 digits AC Voltage Range ............. 600.0 V Resolution ..........0.1 V Accuracy (45 Hz– 400 Hz) ...... 1.5 % ±5 digits DC Voltage Range ............
- Page 18 323/324 PLUS Users Manual Continuity Beeper 323 ............ ≤70 Ω 324 PLUS .......... ≤30 Ω Capacitance (324 PLUS) Range............(100.0, 1000) μF Resolution ..........(0.1, 1) μF Accuracy ..........1 % ±4 digits Contact Temperature (324 PLUS) Range............-10.0 °C to 400.0 °C Resolution ..........
-
Page 19: The Meter
Clamp Meter The Meter The Meter gtq008.eps... - Page 20 323/324 PLUS Users Manual 324 PLUS gtq001.eps...
- Page 21 Clamp Meter The Meter 2:00 2:00 gtq002.eps...
- Page 22 323/324 PLUS Users Manual 600 V 600 V 300 V 300 V 324 PLUS TRUE RMS CLAMP METER TRUE RMS CLAMP METER 600 V 300 V 600 V 300 V gtq003.eps...
- Page 23 Clamp Meter The Meter 323 V dc - 323 V ac - 324 PLUS V dc & V ac - >30 V 300 V gtq004.eps...
- Page 24 323/324 PLUS Users Manual 600 V 600 V 300 V 300 V TRUE RMS CLAMP METER TRUE RMS CLAMP METER 600 V 600 V 300 V 300 V <70 324 PLUS <30 gtq005.eps...
- Page 25 Clamp Meter The Meter HOLD TRUE RMS CLAMP METER 600 V 300 V > 30 V 20 V AC/DC & ZERO ZERO ZERO ZERO 2 sec AC/DC AC/DC AC/DC gtq006.eps...
- Page 26 323/324 PLUS Users Manual TRUE RMS CLAMP METER 600 V 300 V gtq009.eps...
- Page 27 Clamp Meter The Meter gtq007.eps...
- Page 28 323/324 PLUS Users Manual...
