Pakedge Device & Software RK-1 Quick Start Manual page 5

You will find a description of the interfaces on the back of the RK-1 in
Interface Type
Reset Button N/A
USB 1 - 2 USB-A
WAN 1 - 2 RJ-45
LAN (Ports 1-5) RJ-45
Console RJ-45
AC Power input AC
Power Switch N/A
Table 2: Interface Explanation (From Left to Right)
Speed Protocol
N/A N/A
5Gbps USB 3.0
10/100/1000
Ethernet
Mbps
10/100/1000
Ethernet
Mbps
115200 Console
N/A N/A
N/A N/A
5
Description
Hold Reset Button for 10 seconds to
factory default the settings
USB port used for file sharing
WAN port used for the Internet
connection from the ISP
5-port switch connections on the
internal network
Console port for maintenance use
Power Input
On/Off Power Switch
Table 2.
