- Page 1 QUICK START GUIDE RE-1/RE-2 Router Enterprise-Class, Audio/Video Router Version 1.0 pakedgedevice&software...
-
Page 2: Table Of Contents
Contents Overview ................................3 Package Contents ............................4 Installing the Router ............................5 Changing the Router Password .........................5 Accessing the Router GUI ..........................5 Connecting to the Internet ..........................5 Changin the LAN IP ............................9 Troubleshooting and Support ......................... 10 pakedgedevice&software... -
Page 3: Overview
Overview The RE-1 and RE-2 are enterprise grade audio/video routers that are designed to minimize installation times through an intuitive GUI. See the Table 1 below for more information. Table 1’s description of the LED’s applies to both the RE-1 and RE-2. -
Page 4: Package Contents
Below you will find a description of the interfaces on the back of the RE-1 and RE-2 in Table Table 2: Interface Explanation (From Left to Right) Interface Type Speed Protocol Description AC Power input Power Input Power Switch On/Off Power Switch... -
Page 5: Installing The Router
Installing the Router 1. If mounting the router in a standard 19” AV rack, attach the rack-mounting brackets that come with the router to the sides. If not rack-mounting, ensure that the router is physically mounted near power and network connections. 2. - Page 6 If you are using a modem that has a router built into it, you may have to configure DMZ settings to allow complete functionality of the RE-1/RE-2. Static IP: To configure the router to a static IP, complete the following steps: 1.
- Page 7 3. Select Static Address for the Protocol. 4. Click on Switch Protocol. 5. Enter the IP address from your ISP. Select the appropriate Subnet Mask from your ISP. You can select custom to enter a custom subnet mask. Then enter your Default Gateway and DNS Server.
- Page 8 PPPoE: To configure the router using a PPPoE connection, you will need to complete the following steps: 1. Hover your mouse towards the top of page to see the menu. Click on Network Zones. 2. Click on Edit under WAN zone. 3.
-
Page 9: Changin The Lan Ip
4. Enter the username that the ISP assigned under the PAP/CHAP username field. Enter the password in the PAP/CHAP password field. Click Apply when finished. The router is now setup for PPPoE. Changing the LAN IP The default IP address of the router is 192.168.1.99. If you need to change the IP address of the router or change the entire network address take the following steps. -
Page 10: Troubleshooting And Support
3. Enter the new IP address you wish to use in the IP Address field. In the following example we change the IP address of the router to 192.168.1.1. 4. Click Apply towards the bottom to finalize the settings. Troubleshooting and Support If you are unable to get the router functional using these steps, you can refer to the full manual on our website or contact the Technical Support Team for assistance.
