- Page 1 PAKEDGEDEVICE&SOFTWARE INC. K60D UTM Manual PRECONFIGURED AUDIO/VIDEO BRIDGING ROUTER USER MANUAL VERSION 1.1...
- Page 2 FCC Declaration of Conformity Pakedge Device & Software, Inc., 3847 Breakwater Avenue, Hayward, CA, declares under sole responsibility that the R60Dcomply with 47 CFR Parts 2 and 15 of the FCC Rules as a Class B digital device. These devices comply with Part 15 of FCC Rules. Operation of the devices is subject to the following two conditions: (1) These devices may not cause harmful interference, and (2) these devices must accept any interference that may cause undesired operation.
-
Page 3: Table Of Contents
CONTENTS Introduction ............................3 Customer Service and Technical Support ..................... 4 UTM Activation............................ 5 Web Filtering ............................5 Changing User Password........................10 Application Control ..........................11 AntiVirus ............................14 Disabling UTM for A Vlan ........................15 Appendix A: FAQs ..........................17 Appendix B: Specifications ......................... -
Page 4: Introduction
NOTE: This manual is intended to be a supplement to the full K60D manual. If you require assistance with any setup beyond the UTM features, please refer to the full K60D manual which is available on the dealer portal. -
Page 5: Customer Service And Technical Support
CUSTOMER SERVICE AND T ECHNICAL SUPPORT Pakedge Device & Software, Inc. is committed to providing you with exceptional support on all of our products. If you wish to speak with one of our representatives, you may contact us at: Customer Service Email: customerservice@pakedge.com Phone: (650)385-8701 Technical Support... -
Page 6: Utm Activation
UTM ACTIVATION In order to use the UTM features, your K60D must be registered and have a UTM license applied to it. If your K60D is not registered, you may register it on the Pakedge dealer portal. Note: It can take up to 24 hours for the registration to take effect. - Page 7 2. If you purchased the UTM configuration on the K60D there will be a default Pakedge profile, which is preconfigured for you. Make sure this profile is selected. If you did not purchase the UTM configuration you can simply use the default profile and configure it to your needs.
- Page 8 5. Right click on a subcategory and you will see a small menu. You can use this menu to allow or block this subcategory on the network. As an example, right click Explicit Violence and click Allow. 6. The Explicit Violence subcategory is now labeled with a green check mark. This indicates that the websites that match this subcategory are now allowed on the network.
- Page 9 7. You can allow or deny an entire category, which will cause of the subcategories underneath it to be allowed or denied. For example, right click the Potentially Liable category. Click Allow. 8. The entire category is now allowed on the network. 9.
- Page 10 10. The following table summarizes the categories that each user has access to by default: User Category Admin Alternative Beliefs, Abortion, Adult Materials, Advocacy Organizations, Gambling, Extremist Groups, Nudity and Risque, Pornography, Tasteless, Weapons, Homosexuality, Marijuana, Sex Education, Alcohol, Tobacco Teen Swimsuits, Sports Hunting and War Games, Downloads, File Sharing, Streaming Media, P2P...
-
Page 11: Changing User Password
14. By default, Web Filtering will be enabled in the default policies with the UTM configuration. You can scroll to the right to confirm this. With the web filtering profile configured and enabled, the router will begin to filter web sites. CHANGIN G USER PASSWORD You can change the password to the default Admin or Teen user account. -
Page 12: Application Control
1. Navigate to Security Profiles->Application Control->Application Sensors. 2. If you purchased the UTM configuration on the K60D there will be a default Pakedge profile, which is preconfigured for you. Make sure this profile is selected at the upper right hand corner. - Page 13 3. You can block applications by categories. For example, double click on the application policy that blocks P2P and social media. This policy is available on the default Pakedge UTM configuration. 4. Under this policy, the P2P and Social Media options will be checked. 5.
- Page 14 7. Scroll down to the bottom of the page. You will notice that the Action is set to Block, meaning that any applications that match this policy will be blocked. 8. Click OK to apply the changes. 9. Once you have finished making changes to the application profile, you must ensure that the application control is enabled in the policy section.
-
Page 15: Antivirus
ANTIVIRUS Antivirus will allow you to provide network wide antivirus for all devices. This will provide an extra layer of security on your network. Note: It is recommended that you still install antivirus software on any computers on the network. The antivirus feature on the router is intended to provide an extra layer of security. -
Page 16: Disabling Utm For A Vlan
3. The Antivirus feature will be enabled in the policy section by default. With the Antivirus profile configured and enabled, the router will begin to inspect data. DISABLING UTM FOR A VLAN You can disable UTM for any of the preconfigured VLANs. To disable UTM for a VLAN take the following steps. - Page 17 3. Deselect all of the options under Security Profiles. Click OK. UTM has now been disabled on VLAN2.
-
Page 18: Appendix A: Faqs
APPENDIX A: FAQS 1- What is the difference between the standard FortiGate 60D and the preconfigured Pakedge version (R60D)? The preconfigured Pakedge version comes with a separate login screen. This login screen is limited to a basic set of options to get the network up and running. This allows the powerful Fortigate router/security appliance to be installed in any home without expert help. -
Page 19: Appendix B: Specifications
APPENDIX B: SPECIFIC ATIONS R60D ROUTER Interfaces: 10/100/1000 Internal Switch Interfaces (Copper, RJ-45): 10/100/1000 WAN Interfaces (Copper, RJ-45): 10/100/1000 DMZ Interfaces (Copper, RJ-45): USB Interfaces: 2 (1 Type-A, 1 Type-B) Internal Storage 8 GB System Performance: Firewall Throughput (1518 byte UDP packets) 1.5Gbps Firewall Throughput (512 byte UDP packets) 1.5Gbps... - Page 20 Environment: Power Required 100-240 VAC, 50-60 Hz, 1.5 Amp Max Power Consumption (AVG/MAX) 11.7/14 W Heat Dissipation 40 BTU/h Operating Temperature 32 – 104° F (0 – 40° C) Storage Temperature -13 – 158° F (-25 – 70° C) Humidity 5%-90% non-condensing NETWORKING FEATURES MECHANICAL...
-
Page 21: Appendix C: Limited Warranty
APPENDIX C: LIMIT ED WARRANTY Congratulations on your purchase of a Pakedge Device & Software product! We believe Pakedge designs and manufacture the finest home networking products on the market. With proper installation, setup, and care, you should enjoy many years of unparalleled performance. Please read this consumer protection plan carefully and retain it with your other important documents. - Page 22 out of or in connection with the purchase, use or performance of the product, even if Pakedge has been advised of the possibility of such damages. CAUTION: DAMAGE RESULTING DIRECTLY OR INDIRECTLY FROM IMPROPER INSTALLATION OR SETUP IS SPECIFICALLY EXCLUDED FROM COVERAGE UNDER THIS WARRRANTY. IT IS IMPERATIVE THAT INSTALLATION AND SETUP WORK BE PERFORMED ONLY BY AN AUTHORIZED PAKEDGE DEALER TO PROTECT YOUR RIGHTS UNDER THIS WARRANTY.
- Page 23 For additional information about this warranty, visit our website: Pakedge Device & Software,inc. 3847 Breakwater Avenue Hayward, CA 94545 Email:support@pakedge.com Phone: (650) 385-8703 www.pakedge.com...
