■ Screw regulator into stove oven hand
tight. (Fig. 13)
■ Remove protective cap from top of
propane bottle and screw propane
bottle into regulator hand tight.
(Fig. 14)
■ Propane cylinder correctly installed.
(Fig. 15)
■ Never operate stove oven with
propane cylinder in an inverted
position. (Fig. 16)

Leak Check

WARNING
• Perform leak test outdoors.
• Extinguish all open flames.
• NEVER leak test when smoking.
• Do not use the outdoor appliance
until connection has been leak tested
and does not leak.
To Light
EXPLOSION - FIRE HAZARD
• Propane is heavier than air and
can accumulate in low places.
Fig. 13
If you smell gas, leave the area
immediately.
• Always attach or detach propane
source outdoors; never while
appliance is lighted, near flame, pilot
lights, other ignition sources or while
appliance is hot to touch.
• This appliance is very hot during use
and can ignite flammables too close
to the burners. Keep flammables at
least 12 inches from the sides and 48
inches from the top of the appliance.
Keep gasoline and other flammable
liquids and vapors well away
from appliance.
Fig. 14 • The appliance must not be exposed
to flammable vapors or liquids
during lighting.
• Never leave appliance unattended
when hot or in use.
• Keep out of reach of children.
Fig. 15
INSTASTART™
Electronic Ignition Stove oven
■ Set on sturdy, flat surface. For
outdoor use only.
■ Open oven door. Oven door must be
opened during lighting.
■ Push and turn the control knob to
the red ignition setting mark, hold
for 5 seconds until burner lights. If
appliance does not ignite within 5
seconds allow it to air out and repeat
ignite procedure. (Fig. 17)
Fig. 16
Ignition Setting
Ignition Setting
English - 5
DANGER
WARNING
BURN HAZARD
Ignition Setting
Fig. 17
Fig. 19
Fig. 18
