Summary of Contents for ITC TA-H4 PRECISION SERIES
- Page 1 PROFESSIONAL POWER AMPLIFIERS OWNER'S MANUAL OWNER'S MANUAL POWER PROTECT TA-H4 SIGNAL 2-CHANNEL AMPLIFIER PEAK TA-H4/TA-H6/TA-H8/TA-H10/TA-H12 PRECISION SERIES...
-
Page 2: Table Of Contents
5. Make sure that the unit is always well ventilated and never exposed to direct sunlight. 6. Do not use sprays to clean the unit as they have a detrimental effect on the unit and Could ignite ITC denly. -
Page 3: Description
DESCRIPTION DESCRIPTION: Thank you very much for choosing an ITC PRECISION SERIES amplifier. We are sure it will give you many years of satisfying performance. ITC power amplifiers of the PRECISION SERIES meet the stringent requirements of tough to- uring applications. They are protected against over-temperature, overload, shorted outputs, radio frequency interference and DC faults. -
Page 4: Features
FEATURES Features: 1. Two-channel amplifier will stop 2 * 200 @ 2 /4 /8 , 2 * 300 @ 2 /4 /8, 2*400@2R/4R/8R, 2*500@2R/4R/8R, 2*600@2R/4R/8R output 2. Balanced input 3. Output level indicating 4. With automatic voltage limited output signal function 5. -
Page 5: Front Panel
FRONT PANEL Front: 6 5 4 PROTECT SIGNAL POWER PEAK 1. Level Control Calibrated detented potentiometers to alterthe total gain of the power amplifier. In orderto avoid disto- rtion in mixing consoles upstream, these controls should normally be positioned between 0 dB and -1.5dB. -
Page 6: Back Panel
BACK PANEL Back: (BRIDGE IN) BRIDGE TRS TIP XLR PIN2 OUTPUTS INPUTS PIN OUT PIN OUT 1 2 3 4 CH1:1+1- CH2:1+1- CH2:2+2- BRIDGE:1+2- TRS TIP XLR PIN2 1.Power cord The power cord connects hear. Only ~220-240V 50/60Hz voltage is acceptable. 2.Power amplifier output XLR-type connectors SPEAKON output connectors are provided for the power amplifier channels 1 and 2. -
Page 7: Connections
CONNECTIONS POWER AMPLIFIER INPUT CONNECTORS: XLR connectors(male)are provided for Looping the signal to other power amplifiers.These are wir- ed parallel to the XLR input connectors in each channel. The inputs of the power amplifier are electronically balanced and wired according to IEC 268.lsolation transfomers can be retrofitled in order to avoid hum interference in larger sound reinforcement systems. - Page 8 CONNECTIONS Connections: MIXER AMPLIFIER T5AL250V T5AL250V MUTE EMC INPUT LINE INPUT AUX1 AUX2 NO.1 OUTPUT COM 4-16 70V 100V ~220V 50Hz MIC2 MIC3 MIC2 MIC3 AMPLIFIER SPEAKER 2--OUTPUTS--1 LINE 10 LINE 9 LINE 8 LINE 7 MIC INPUTS MIC/LINE INPUTS PRIORITY CHIME NO.1...
-
Page 9: Specifications
SPECIFICATIONS Rate Power Output TA-H4 TA-H8 TA-H12 TA-H6 TA-H10 (20Hz-20KHz/THD 0.1%) Into 8 Ohmsx2 200W 300W 400W 500W 600W Into 4 Ohmsx2 300W 450W 600W 750W 900W 900W 1200W 1500W 1800W 600W Into 8 Ohmsx2 bridged Into 4 Ohmsx2 bridged 800W 1100W 1600W... -
Page 10: Dimensional
DIMENSIONAL K e e p t h e u n i t ’s a l l s i d e s o v e r 1 0 c m a w a y f r o m o b j e c t s t h a t m a y o b s t r u c t a i r f l o w t o p r e v e n t t h e u n i t ’... - Page 11 PROFESSIONAL POWER AMPLIFIERS PRECISION SERIES Version V0.3...
