  • Page 1 REGULATORY MODEL NUMBER: 03342D4-001 This is a Class A device and is not intended for use in a residential environment. Part# 07M2174-UM Rev. C Revised 11/8/11 An ISO-9001Certified Company USER MANUAL MODEL 2174 CopperLINK™ High Speed Ethernet Extender SALES OFFICE (301) 975-1000 TECHNICAL SUPPORT (301) 975-1007...

  • Page 2: Table Of Contents

    Configuring DIP Switch S1 ... 14 Switch S1-1: Local/Remote Configuration... 15 Switches S1-2 and S1-3: Symmetric/Asymmetric Operation ... 15 Switch S1-5: General Protection (Signal to Noise Ratio) ... 15 Operation... 16 Front Panel LED Status Monitors ... 16 Specifications ... 17 A.1 LAN Connection ...
  • Page 3 RJ-45 ... 19 C.2 CopperLINK Interface ... 19 RJ-45 ... 19 Terminal Block... 19 Line Rate & Reach Chart, Based on 24 AWG (0.5 MM) ... 20...

  • Page 4: Warranty Information

    1.0 WARRANTY INFORMATION Patton Electronics warrants all Model 2174 components to be free from defects, and will—at our option—repair or replace the product should it fail within one year from the first date of the shipment. This warranty is limited to defects in workmanship or materials, and does not cover customer damage, abuse or unauthorized modification.

  • Page 5: Ce Declaration Of Conformity

    tion. The device has been tested and found to comply with the limits for a Class A computing device in accordance with specifications in Subpart B of Part 15 of FCC rules, which are designed to provide reasonable pro- tection from such interference in a commercial installation. However, there is no guarantee that interference will not occur in a particular instal- lation.

  • Page 6: Safety When Working With Electricity

    • Do not open the device when the power cord is con- nected. For systems without a power switch and without an external power adapter, line voltages are present within the device when the power cord is connected.
  • Page 7 In accordance with the requirements of council direc- tive 2002/96/EC on Waste of Electrical and Electronic Equipment (WEEE), ensure that at end-of-life you sepa- rate this product from other waste and scrap and deliver to the WEEE collection system in your country for recy- cling.

  • Page 8: General Information

    (R) Remote unit at the other end. The Model 2174 is config- ured as a L or R via the switch on the bottom of the unit. These units can automatically forward LAN broadcasts, multicasts, and frames across a 2- wire voice-grade twisted-pair or BNC link.

  • Page 9: Installation

    The pair of 2174 models work together to create a transparent extension between two peered Ethernet LANs using twisted pair (2-wire), Cat5+, or 75-ohm BNC. Figure 1 shows a typical point-to-point application. The Interconnecting cables shall be acceptable for external use and shall be rated for the proper applica- tion with respect to voltage, current, anticipated tem- CAUTION perature, flammability, and mechanical serviceability.
  • Page 10 Figure 2. Model 2174 rear panel options...

  • Page 11: Connecting The Line Interface

    3.1 CONNECTING THE LINE INTERFACE The Interconnecting cables shall be acceptable for external use and shall be rated for the proper applica- tion with respect to voltage, current, anticipated tem- CAUTION perature, flammability, and mechanical serviceability. The Model 2174 supports communication between two peer Ethernet LAN sites over a distance of up to 10,000 ft (3 km) over 24 AWG (0.5 mm) twisted-pair wire, Cat5+, or 75-ohm BNC.

  • Page 12: Connecting The Line Interface For Model 2174/Bnc

    Figure 4. Model 2174 (Terminal Block) twisted pair line interface Connecting the Line Interface for Model 2174/BNC To connect the line interface of the Model 2174/BNC, simply use a coax- ial cable with a BNC connector at each end to connect the pair of Model 2174s.

  • Page 13: Connecting Power

    CAUTION perature, flammability, and mechanical serviceability. The Model 2174 does not have a power switch, so it powers up as soon as it is plugged in. An external AC or DC power supply is available separately. This connec- tion is made via the barrel jack on the rear panel of the Model 2174.

  • Page 14: Configuring Dip Switch S1

    4.2 CONFIGURING DIP SWITCH S1 DIP switch S1 is where you configure the CopperLINK line. The following tables describe the configuration for the 2174. Position S1-1 S1-2 S1-3 S1-4 S1-5 S1-6 S1-7 S1-8 Figure 6. DIP switch orientation Table 1: S1 Summary...

  • Page 15: Switch S1-1: Local/Remote Configuration

    Switch S1-1: Local/Remote Configuration Use switch S1-1 to configure the unit as Remote or Local in the Model 2174 pair. Table 2: Local/Remote Unit Configuration S1-1 Switches S1-2 and S1-3: Symmetric/Asymmetric Operation Use switches S1-2 and S1-3 to configure the CopperLink line rate type- and operation.

  • Page 16: Operation

    Once the Model 2174s are properly installed, they should operate trans- parently. No user settings required. This section describes reading the LED status monitors. Before applying power to the Model 2174, please review section 3.3, “Connecting Power” on page 13 to verify that the unit is connected to the appropriate power source.

  • Page 17: Specifications

    APPENDIX A SPECIFICATIONS A.1 LAN CONNECTION • Four RJ-45, 10/100Base-T, IEEE 802.3 Ethernet • CopperLINK Connection: RJ-45 A.2 TRANSMISSION LINE Two-wire unconditioned twisted pair or 75-ohm BNC A.3 COPPERLINK LINE RATE AND COPPERLINK DISTANCE • Line Rate: Up to 200 Mbps asymmetrical •...

  • Page 18: Model 2174 Series Factory

    MODEL 2174 SERIES FACTORY REPLACEMENT PARTS AND ACCESSORIES Patton Model # Base Models 2174/EUI-2PK High Speed CopperLink Ethernet Extender Kit (Local and Remote); RJ45 Line, 100-240VAC 2174/TB/EUI-2PK High Speed CopperLink Ethernet Extender Kit (Local and Remote); Terminal Block Line, 100-240VAC 2174/BNC/EUI-2PK High Speed CopperLink Ethernet Extender Kit (Local and Remote);...

  • Page 19: C.2 Copperlink Interface

    APPENDIX C MODEL 2174 SERIES INTERFACE PIN ASSIGNMENT C.1 10/100BASE-T INTERFACE RJ-45 • Pin 1: TX+ • Pin 2: TX- • Pin 3: RX+ • Pin 6: RX- • Pins 4, 5, 7, 8: no connection C.2 COPPERLINK INTERFACE RJ-45 •...

  • Page 20: Line Rate & Reach Chart, Based On 24 Awg (0.5 Mm)

    LINE RATE & REACH CHART, BASED ON 24 AWG (0.5 MM) Table 6: Line Rate & Reach Chart Using Twisted-Pair (Long Range) Distance in Feet Mode (Long Range) 250 ft 1000 ft 2,000 ft Symmetric 3,000 ft 5,000 ft 10,000 ft 250 ft 1000 ft 2,000 ft...
  • Page 21 Table 7: Line Rate & Reach Chart Using Twisted-Pair (High Speed) Distance in Feet Mode (High Speed) 250 ft 1000 ft 2,000 ft Symmetric 3,000 ft 3,500 ft 250 ft 1000 ft 2,000 ft Asymmetric 3,000 ft 3,500 ft Note The actual distance and link performance may vary depending on the environment and type/gauge of wire used.
