- Page 1 USER MANUAL MODEL 1173R IP Network Camera Extender Part# 07M1173-UM SALES OFFICE Doc# 03333U2-003 (301) 975-1000 Rev. A TECHNICAL SUPPORT Revised 5/21/08 (301) 975-1007 An ISO-9001Certified Company...
-
Page 2: Table Of Contents
A.3 Line Rate and Distance .............. 17 A.4 Surge Suppressor ............... 17 A.5 LED Status Indicators ..............17 A.6 Power Supply ................17 A.7 Temperature Range ..............17 A.8 Humidity ..................17 A.9 Dimensions ................. 17 Model 1173R Series Factory Replacement Parts and Accessories........18... - Page 3 Model 1173R Series Interface Pin Assignment...... 19 C.1 10/100Base-T Interface .............. 19 RJ-45 ..................19 C.2 Line Interface ................19 RJ-45 ..................19 Terminal Block................19 Distance Chart, Based on 24 AWG (0.5 MM) ......20...
-
Page 4: Warranty Information
1.0 WARRANTY INFORMATION Patton Electronics warrants all Model 1173R components to be free from defects, and will—at our option—repair or replace the product should it fail within one year from the first date of the shipment. This warranty is limited to defects in workmanship or materials, and does not cover customer damage, abuse or unauthorized modification. -
Page 5: Radio And Tv Interference (Fcc Part 15)
1.2 RADIO AND TV INTERFERENCE (FCC PART 15) This equipment generates and uses radio frequency energy, and if not installed and used properly—that is, in strict accordance with the manu- facturer's instructions—may cause interference to radio and television reception. This equipment has been tested and found to comply with the limits for a Class A computing device in accordance with the specifica- tions in Subpart B of Part 15 of FCC rules, which are designed to provide reasonable protection from such interference in a commercial installa-... -
Page 6: Safety When Working With Electricity
PSTN. It is intended only for connection to customer premise equipment. WARNING When the 1173R is mounted, it shall be secured in such a way as to withstand a vertical shear force of 50N or 14 WARNING... -
Page 7: General Information
Operating in pairs, one Model 1173R is configured as the (L) LAN unit located at one end of the LAN extension and the other Model 1173R is configured as the (C) Camera unit at the other end. The Model 1173R is configured as a L or C via the switch on the rear panel. -
Page 8: Installation
CAUTION perature, flammability, and mechanical serviceability. To install the 1173R Camera Extender, do the following: 1. Connect the line interface between the units (refer to section 3.1, “Connecting the Twisted-Pair Line Interface” on page 9) Note See Figure 2 for the standalone unit’s rear panel arrangements. -
Page 9: Connecting The Twisted-Pair Line Interface
Follow the steps below to connect the Model 1173R interfaces. Note The Model 1173R units work in pairs. One of the units must be configured as a (L) LAN unit, and the other unit must be config- ured as a (C) Camera unit. The link is always initiated by the C unit. - Page 10 19 (0.9mm) and 26 AWG (0.4mm). Leased circuits that run through signal equalization equipment are not acceptable. 2. The Model 1173R is equipped with either an RJ-45 or a terminal block interface jack that can be used on the interface. These interfaces are a two-wire interface.
-
Page 11: Connecting The 10/100Base-T Ethernet Interface
An external AC or DC power supply is available separately. This connec- tion is made via the barrel jack on the rear panel of the Model 1173R. No configuration is necessary for the power supply (See Appendix B for domestic and international power supply and cord options). -
Page 12: Configuration
4.0 CONFIGURATION The Model 1173R has eight DIP switches for configuring the unit for a wide variety of applications. This section describes switch locations and explains the different configurations. 4.1 CONFIGURING THE HARDWARE DIP SWITCHES Using a small flat-tip screwdriver, remove the protective cover located on the underside of the Model 1173R (see Figure 6). -
Page 13: Configuring Dip Switch S2
Switch toggle Push toggle up for ON position Push toggle down for 1 2 3 4 5 6 7 8 OFF position Figure 7. DIP switch orientation 4.2 CONFIGURING DIP SWITCH S2 DIP switch S2 is where you configure the line rate, Ethernet, and Ether- net Shutdown. -
Page 14: Switch S2-1: Reserved
Switch S2-1: Reserved Switch S2-1 should always be in the OFF position. Table 2: Ethernet Auto Sense Selection Chart S2-1 Setting Reserved Reserved Switches S2-2 and S2-3: Data Rate Use switches S2-1, S2-2 and S2-3 to configure the line rates. Table 3: Rates Selection Chart S2-2 S2-3... -
Page 15: Operation
Switch S2-7: Ethernet Shutdown Use switch S2-7 to enable or disable Ethernet Shutdown. When Ethernet Shutdown is enabled, the 1173R will disable the Ethernet interface when there is no link detected. When Ethernet Shutdown is disabled, the Ethernet interface will always be enabled. -
Page 16: Front Panel Led Status Monitors
5.2 FRONT PANEL LED STATUS MONITORS The Model 1173R features three front panel LEDs that monitor power, the Ethernet signals, and the connection. Figure 8 shows the front panel location of each LED. Table 7 on page 16 describes the LED functions. -
Page 17: Specifications
APPENDIX A SPECIFICATIONS A.1 LAN CONNECTION • Shielded RJ-45, 10/100Base-T, IEEE 802.3 Ethernet • Line Connection: RJ-45 or Terminal Block A.2 TRANSMISSION LINE Two-wire unconditioned twisted pair. A.3 LINE RATE AND DISTANCE • Distance: 6,000 ft (1.8 km) at 1 Mbps upstream/4 Mbps downstream Note Distances depend on selected line rate and line conditions. -
Page 18: Model 1173R Series Factory Replacement Parts And Accessories
APPENDIX B MODEL 1173R SERIES FACTORY REPLACEMENT PARTS AND ACCESSORIES Patton Model # Description Base Models 1173R/EUI IP Network Camera Extender; -10 to 70°C; UI 1173R/C/EUI IP Network Camera Extender; -10 to 70°C; conformal coated (humidity 85% condensing from -10 to +35°C); UI 1173R/EUI-2PK IP Network Camera Extender Kit;... -
Page 19: Model 1173R Series Interface Pin Assignment
• Pins 4, 5, 7, 8: no connection C.2 LINE INTERFACE RJ-45 • Pin 4: RING • Pin 5: TIP • Pins 1, 2, 3, 6, 7, 8: no connection Terminal Block RING Figure 1. Model 1173R (Terminal Block) twisted pair line interface.. -
Page 20: Distance Chart, Based On 24 Awg (0.5 Mm)
APPENDIX D DISTANCE CHART, BASED ON 24 AWG (0.5 MM) Throughput Distance in feet Line Rate (DS/US) at Max Distance (km) (DS/US) 50 Mbps/2 Mbps 2,000 (0.61 km) 48/2 16 Mbps/2 Mbps 4,000 (1.22 km) 15/2 4 Mbps/1 Mbps 6,000 (1.82 km) 3.75/1 Note The actual distance and link performance may vary depending...
