This is a Class A device and is intended for use in a
light industrial (commercial) environment. It is
not intended nor approved for use in a heavy
industrial or residential environment.
Part# 07M2110-UM
Rev. B
Revised 3/5/10
An ISO-9001Certified
Company
USER
MANUAL
MODEL 2110
CopperLink Ethernet Booster
SALES OFFICE
(301) 975-1000
TECHNICAL SUPPORT
(301) 975-1007
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Patton electronics CopperLink Ethernet Booster 2110
Summary of Contents for Patton electronics CopperLink Ethernet Booster 2110
- Page 1 This is a Class A device and is intended for use in a light industrial (commercial) environment. It is not intended nor approved for use in a heavy industrial or residential environment. Part# 07M2110-UM Rev. B Revised 3/5/10 An ISO-9001Certified Company USER MANUAL...
-
Page 2: Table Of Contents
CONTENTS Warranty Information ... 3 Compliance... 3 EMC Compliance:... 3 Safety Compliance: ... 3 PSTN Compliance: ... 3 Radio and TV Interference (FCC Part 15) ... 4 CE Declaration of Conformity ... 4 Authorized European Representative... 4 Service... 5 Safety When Working With Electricity ... 5 General Information... -
Page 3: Warranty Information
1.0 WARRANTY INFORMATION Patton Electronics warrants all Model 2110 components to be free from defects, and will—at our option—repair or replace the product should it fail within one year from the first date of the shipment. This warranty is limited to defects in workmanship or materials, and does not cover customer damage, abuse or unauthorized modification. -
Page 4: Radio And Tv Interference (Fcc Part 15)
1.2 RADIO AND TV INTERFERENCE (FCC PART 15) This equipment generates and uses radio frequency energy, and if not installed and used properly—that is, in strict accordance with the manu- facturer's instructions—may cause interference to radio and television reception. This equipment has been tested and found to comply with the limits for a Class A computing device in accordance with the specifica- tions in Subpart B of Part 15 of FCC rules, which are designed to provide reasonable protection from such interference in a commercial installa-... -
Page 5: Service
1.5 SERVICE All warranty and non-warranty repairs must be returned freight prepaid and insured to Patton Electronics. All returns must have a Return Materi- als Authorization number on the outside of the shipping container. This number may be obtained from Patton Electronics Technical Services at: •... -
Page 6: General Information
2.0 GENERAL INFORMATION Thank you for your purchase of this Patton Electronics product. This product has been thoroughly inspected and tested and is warranted for one year for parts and labor. If any questions or problems arise during installation or use of this product, contact Patton Electronics Technical Support at +1 (301) 975-1007. -
Page 7: Installation
When using a Model 2110, in conjunction with a PoE Switch, the user extends the 802.3af PoE and 10/100 Ethernet an additional 100 meters (328ft). POE-enabled IP Cameras can be placed 200 feet away from the Ethernet switch and can be powered up via PoE by the 2110. (See Appendix A.6 on page 11 for power and distance specifications). -
Page 8: Connecting The Poe And 10/100Base-T Ethernet Interface
Model 2110 (Front and Top) PoE and/or Ethernet Output RJ-45 port PoE and/or Ethernet Input RJ-45 port Figure 2. Model diagram (2110/PSE model shown) 3.1 CONNECTING THE POE AND 10/100BASE-T ETHERNET INTERFACE If used externally, interconnecting cables shall be rated for the proper application with respect to voltage, cur- rent, anticipated temperature, flammability, and CAUTION... -
Page 9: Connecting Power (Eui Models)
The 2110/P, 2110/PSE/EUI-48, and 2110/PSE/EUI inject power on the data pair pins 1/ 2 (POE+) and 3/ 6 (POE-) of the connector labeled “PoE OUT.” The 2110/P accepts POE power on either pin pairs 1/ 2 and 3/ 4, or 4/ 5 and 7/ 8 on the connector labeled “PoE IN.” Note The POE power on the 2110/P is rectified and thus polarity of the power is irrelevant. -
Page 10: Led Status Monitors
4.2 LED STATUS MONITORS The Model 2110 features two top panel LEDs that monitor PoE output and Ethernet activity, and two bottom panel LEDs that monitor power input and Ethernet activity. Figure shows the locations of each LED. Table 1 describes the LED functions. PoE OUT PoE Link* (Top Panel) -
Page 11: Specifications
A.1 ETHERNET CONNECTION • Two Ethernet ports 10/100BaseTX; 802.3af • Auto-Negotiating 10/100 • Supports Flow Control (IEEE803.X) for full duplex operation • Supports back pressure for half duplex operation • Store and forward • Auto MDI-X • 802.3af pass through A.2 LED STATUS INDICATORS •... -
Page 12: Model 2110 Series Factory
REPLACEMENT PARTS AND ACCESSORIES Patton Model # Base Models 2110/P 10/100 Ethernet Booster; 802.3af; 0-50°C 2110/PSE/EUI-48 10/100 Ethernet Booster/PoE Injector; 802.3af; 0-50ºC, 48VDC 2110/EUI 10/100 Ethernet Booster; External 100-240VAC; 0-50°C 07M2110-UM User Manual Power Supplies 08055-2110-I 10/100 Ethernet Injector; External 100-240VAC; 0-50°C 080511-06 12V Adapter, 1.25A 080511-07M...
