- Page 1 MC-16FX Family MB96300 Series Setup Guide Doc. No. 002-06378 Rev. *A Cypress Semiconductor 198 Champion Court San Jose, CA 95134-1709 Phone (USA): 800.858.1810 Phone (Intnl): +1 408.943.2600 www.cypress.com...
- Page 2 Cypress is not liable, in whole or in part, and you shall and hereby do release Cypress from any claim, damage, or other liability arising from or related to all Unintended Uses of Cypress products.
-
Page 3: Table Of Contents
Hardware Setup ................................7 Setting up the emulator and each board ........................ 7 Jumper settings on the adapter board ........................8 Revision History ................................... 11 Document Revision History ............................11 MC-16FX Family MB96300 Series Setup Guide, Doc. No. 002-06378 Rev. *A... -
Page 4: Setup Procedures
Figure 1-1 shows the flow for the setup procedure for the MB96300 series debug environment. The connections for the emulator and each board, as well as the procedures and descriptions for settings on the adapter board are explained in the following chapters. -
Page 5: Hardware Configuration
2. Hardware Configuration Figure 2-1 shows the configuration of the MB96300 series debug environment. The debug environment consists of a host PC, emulator (MB2198-01), evaluation chip (MB96V300BRB-ES), adapter board (MB2198-500), header board, and target board (user board). The SOFTUNE integrated development environment must be setup on the host PC. (Refer to the SOFTUNE First Step Guide for setup procedures.) Select and use the header board that matches the chip and package... - Page 6 (0.5 mm, 10 10 mm) MB2198-504 LQFP-64 (0.65 mm, 12 12 mm) MB96380 MB2198-16FX- LQFP-120 120P-M21 *The user must also supply a target board (user board), and oscillator clock (crystal oscillator). MC-16FX Family MB96300 Series Setup Guide, Doc. No. 002-06378 Rev. *A...
-
Page 7: Hardware Setup
3. Hardware Setup This chapter explains the setup procedures the MB96300 series debug environment. 3.1 Setting up the emulator and each board Figure 3-1 shows the connections for the emulator and each board. Connect each board shown in Figure 3-1. The included AC adapter must be used to provide power to the emulator. -
Page 8: Jumper Settings On The Adapter Board
*2 If a sub clock is to be used, set the jumper on the adapter board to the CLK side, then connect the sub clock to the IC socket for the crystal oscillator. MC-16FX Family MB96300 Series Setup Guide, Doc. No. 002-06378 Rev. *A... - Page 9 * If a sub clock is to be used, set the jumper on the adapter board to the CLK side, and then connect the sub clock to the IC socket for the crystal oscillator. MC-16FX Family MB96300 Series Setup Guide, Doc. No. 002-06378 Rev. *A...
- Page 10 Connect the capacitor on the adapter to the C pin on the evaluation MCU Refer to the Instruction Manual for the Adapter MB2198-500 for details on settings of the adapter board. MC-16FX Family MB96300 Series Setup Guide, Doc. No. 002-06378 Rev. *A...
-
Page 11: Revision History
MC-16FX Family MB96300 Series Setup Guide Document Number: 002-06378 Revision Issue Date Origin of Description of Change Change 09/11/2008 KHAS Initial release. 05/16/2016 KHAS Migrated Spansion Guide from AN07-00160-1E to Cypress format. MC-16FX Family MB96300 Series Setup Guide, Doc. No. 002-06378 Rev. *A...
