USER
MANUAL
MODEL 1000RC
Asynchronous Short
Range Modem:
Dual Rack Mount Card
SALES OFFICE
Part# 07M1000RC-B
(301) 975-1000
Doc# 052011UB
TECHNICAL SUPPORT
Revised 4/30/96
(301) 975-1007

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 1000RC and is the answer not in the manual?

Questions and answers

Summary of Contents for Patton electronics 1000RC

  • Page 1: User Manual

    USER MANUAL MODEL 1000RC Asynchronous Short Range Modem: Dual Rack Mount Card SALES OFFICE Part# 07M1000RC-B (301) 975-1000 Doc# 052011UB TECHNICAL SUPPORT Revised 4/30/96 (301) 975-1007...
  • Page 2: Warranty Information

    The Model 1000RC has been tested and found to comply with the limits for a Class A computing device in accordance...
  • Page 3: General Information

    Model 1000RC is available with RJ-11 or RJ-45 rear interface cards. For workgroup and desktop communications, the Model 1000RC also fits in Patton’s 2, 4 and 8 slot Cluster Boxes. The combination of rack mount, Cluster Box and self-powered units provides a completely integrated Model 1000 “networking”...
  • Page 4 Figure 3. Summary of jumper settings, *indicates factory default 3.3 REAR CARD CONFIGURATION The Model 1000RC has two interface card options: the 1Q11 (which comes equipped with two RJ-11 ports and two RJ-45 ports) and the 1Q45 (which comes equipped with four RJ-45 ports). Figure 4 illustrates these two different rear interface options.
  • Page 5: Installation

    DTE as DSR or RI (JB6 & JB7) Because the Model 1000RC uses DSR (but not RI), only position 1&2 is valid when this rear card is used with the Model 1000RC. Position 1&2 causes the terminal (DTE) to see DSR when the Model 1000RC is powered up properly.
  • Page 6: Point-To-Point Twisted Pair Connection

    4.2 INSTALLING THE MODEL 1000RC INTO THE CHASSIS The Model 1000RC is comprised of a front card and a rear card. The two cards meet inside the rack chassis and plug into each other by way of mating 50 pin card edge connectors.
  • Page 7: Operation

    1000RC when its card-edge connector touches the chassis’ mid-plane socket, or when the chassis’ power is turned on. Note: The 1000RC is a “hot swappable” card—it will not be damaged by plugging it in or removing it while the rack is powered up.
  • Page 8: Specifications

    Humidity: Up to 95% non-condensing Dimensions: 0.95”w x 3.1”h x 5.4”l APPENDIX B CABLE RECOMMENDATIONS The Patton Model 1000RC operates at frequencies of 20kHz or less and has been performance tested by Patton technicians using twisted- pair cable with the following characteristics: Wire Gauge...
  • Page 9: Factory Replacement Parts

    APPENDIX C FACTORY REPLACEMENT PARTS The Patton Model 1000RC rack system features interchangeable rear half cards, power cords/fuses for international various operating environments and other user-replaceable parts. Model numbers and descriptions for these parts are listed below: Patton Model # Description 1000RPEM...120/240V Rear Power Entry Module...
