Specifications - Patton electronics ipRocketLink IAD 3086 Specification Sheet

Why use our Model 3086?
The Patton Model 3086 ipRocketLink IAD delivers all the
advanced features needed for secure, reliable, and high speed
data connections. By combining serial access with Ethernet/IP,
the 3086 IAD makes next-generation connectivity simple, easy,
and cost effective.
Available with standard WAN and serial interface such as V.35,
X.21, T1, and E1, the 3086 is a potent NTU for any network con-
nection. In addition, the Model 3086 offers a standard 10/100
full-duplex Ethernet/IP interface with capabilities ready for any
routing task. NAT, DHCP, Firewall, IDS, and Filtering give you
complete control over network services and security. For ulti-
mate flexibility the 3086 allows simultaneous operation of the
serial and Ethernet ports.
The 3086 IAD can be used back-to-back or with the Patton
ForeFront Access Infrastructure System. Additionally, the 3086
IAD can be used with any other G.SHDSL TDM or Packet sys-
tem.

Specifications

D D S S L L G.991.2 ITU G.SHDSL Annex A & Annex B, G.994.1 G.hs.
nx64 data rates over 2-wire full-duplex to 2.3 Mbps, sym-
metrical, TC-PAM encoding. Distances: 32,000 ft (9.8 km)
at 192 kbps to 18,000 ft (5.6 km) at 2.312 Mbps.
D D S S L L C C o o n n n n e e c c t t i i o o n n
Shielded RJ-11F isolation per IEC 950
E E t t h h e e r r n n e e t t C C o o n n n n e e c c t t i i o o n n 10/100Base-T, auto-sensing, full/half-duplex operation,
built-in MDI-X
V.35—M/34F, X.21—DB15F (DCE/DTE), T1—RJ48C,
S S e e r r i i a a l l I I n n t t e e r r f f a a c c e e
E1—RJ48C, and dual BNC
EIA-561 RJ-45 RS-232, VT-100 CLI, TELNET, Embedded
M M a a n n a a g g e e m m e e n n t t WEB/HTTP, SNMP, Logging or SMTP on events: POST,
POST errors, line/DSL, PPP/DHCP, IP MPOA AAL5 &
bridged encapsulation RFC 2684 & RFC 1577 IPoATM.
LLC/VC Mux support.
UNI 3.1, and 4.0 ATM QoS with UBR/CBR/nrt-VBR/rt-
A A T T M M S S u u p p p p o o r r t t VBR and per-VC queuing and shaping. • Peak cell rate
shaping on a per-VCC basis up to 32 active VCCs •
I.610 OAM network management including AIS/RDI,
loop-back and performance monitoring.
F F r r a a m m e e R R e e l l a a y y
Frame Relay over DSL. Encapsulates IP traffic from
( ( K K e e y y e e d d f f e e a a t t u u r r e e ) ) Ethernet port into Frame Relay according to RFC-1490.
Enhanced ILMI 4.0 for auto-configuration of ATM PVCs,
P P r r o o t t o o c c o o l l
IP (RFC 741), TCP (RFC 793), UDP (RFC 768), ICMP
(RFC 950), ARP (RFC 826). IP Router with RIP (RFC
1058), RIPv2 (RFC 2453), OSPF (RFC 2328) Integrated
DHCP Server (RFC 2131). Selectable IP leases and
MAC/IP pairings.
07MD3086-DS5
Patton is a registered trademark, and NetLink is a trademark of Patton Electronics Company in
the United States and other countries.
PE-Inalp Networks Private Ltd
An Associate of
Electronics Co., USA
Old No. 14 and New No.6,
Brahadambal Road,
Nungambakkam High Road
Chennai: 600 034, India
Phone + + 9 9 1 1 4 4 4 4 4 4 5 5 4 4 9 9 0 0 3 3 9 9 5 5 / / 6 6 / / 7 7
Fax + + 9 9 1 1 4 4 4 4 4 4 5 5 4 4 9 9 . . 0 0 3 3 9 9 4 4
Email s s a a l l e e s s @ @ p p a a t t t t o o n n . . c c o o . . i i n n
Web w w w w w w . . p p a a t t t t o o n n . . c c o o . . i i n n
3086 Competitive Positioning
Patton
3086
Line Type
G.SHDSL
ATM Encapsulation
YES
Native PPP/Frame Relay
YES
Bridging/PPPoE/IPoATM
YES
NAT/MultiNAT/DHCP
YES
Statefull Firewall/ACL
YES
V.35/X.21/T1/E1
YES
Status LEDS
ENET Cross-Over Switch
YES
10/100 Ethernet
YES
Built-In Web Mgmt
YES
Tech Support
FREE
Software Upgrades
FREE
Compact Unit
Compact
Best Value
YES
P P r r o o t t o o c c o o l l ( ( c c o o n n t t i i n n u u e e d d ) ) DHCP relay agent (RFC 2132/RFC 1542) with 8 address
pools. DNS Relay. IGMP v1 and v2. IP-in-IP (RFC-2003)
encapsulation, Ethernet Bridging.
NAT/NAPT with integrated application support, MultiNat
with 1:1 mapping, Many:1, Many:Many mapping, NAT
Port/IP redirection and mapping.
S S e e c c u u r r i i t t y y
DoS Detection/protection. Intrusion detection, Logging
of session, blocking and intrusion events and Real-
Time alerts, Password protected system management
with a username/password for console and virtual ter-
minal, Packet filtering firewall for controlled access to
and from LAN/WAN. Support for 255 rules in 32 filter
sets. 16 individual connection profiles. Access list
determining up to 5 hosts/networks which are allowed
to access management system SNMP/HTTP/TELNET
12 LEDs: DSL Link; Sync Serial: TD, RD, CTS, DTR;
I I n n d d i i c c a a t t o o r r s s
LAN: TX, RX, 100M Link; Status: NS, ER, TM.
Internal universal 90–260 VAC input or 48 VDC input.
P P o o w w e e r r S S u u p p p p l l y y
Optional external power available.
FCC Part 15A, CE Mark, EMC Directive 89/336/EEC,
Low-Voltage Directive 73/23/EEC, EN60950, EN55022
C C o o m m p p l l i i a a n n c c e e
(CISPR 22)
Temperature: 32–122°F (0–50°C); Humidity: 5–90%,
E E n n v v i i r r o o n n m m e e n n t t non-condensing
7.3 x 6.6 x 1.62 inch (185 x 168 x 41mm).
D D i i m m e e n n s s i i o o n n s s
Patton-Inalp Networks AG
Meriedweg 7
CH-3172 Niederwangen
Switzerland
Phone + + 4 4 1 1 ( ( 3 3 1 1 ) ) 9 9 8 8 5 5 2 2 5 5 2 2 5 5
Fax + + 4 4 1 1 ( ( 3 3 1 1 ) ) 9 9 8 8 5 5 2 2 5 5 2 2 6 6
E-mail s s a a l l e e s s @ @ i i n n a a l l p p . . c c o o m m
Web w w w w w w . . i i n n a a l l p p . . c c o o m m
Cisco
828
G.SHDSL
Yes
NO
Yes
Yes
Yes
NO
12 10
Yes
NO
NO
$$$
$$$
Large
$$$
Patton Electronics Co.
7622 Rickenbacker Drive
Gaithersburg, Maryland 20879
Phone + + 1 1 3 3 0 0 1 1 9 9 7 7 5 5 1 1 0 0 0 0 0 0
Fax + + 1 1 3 3 0 0 1 1 8 8 6 6 9 9 9 9 2 2 9 9 3 3
E-mail s s a a l l e e s s @ @ p p a a t t t t o o n n . . c c o o m m
Web w w w w w w . . p p a a t t t t o o n n . . c c o o m m
ZyXel
782
G.SHDSL
YES
NO
Yes
Yes
Yes
NO
6
NO
Yes
NO
included
included
Large
$$$
