Patton electronics IM 1/F User Manual

G. 703 interface module

Advertisement

G. 703 Interface Module
Part# 07MIM1F-B
SALES OFFICE
Doc# 090071UB
(301) 975-1000
Revised 08/10/99
TECHNICAL SUPPORT
(301) 975-1007
http://www.patton.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IM 1/F and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Patton electronics IM 1/F

  • Page 1 G. 703 Interface Module Part# 07MIM1F-B SALES OFFICE Doc# 090071UB (301) 975-1000 Revised 08/10/99 TECHNICAL SUPPORT (301) 975-1007 http://www.patton.com...
  • Page 2: Radio And Tv Interference

    The Model IM 1/F has been tested and complies with the limits for a Class A computing device in accordance with the specifi-...
  • Page 3: System Description

    • Made in the U.S.A. 2.2 DESCRIPTION The Patton Model IM 1/F Interface Module converts data from a 64K G.703 network into a Transistor-Transistor Logic (TTL) compatible signal that is transported by the PE 1090 or 1092 Modem or a similar 2 or 4 wire short haul modem that has identical pin outs and edge con- nector style (see note, below).
  • Page 4: Operating Mode Selections

    The first G.703 interface is in Network Timed mode. The second is in Modem Timed mode. See Figure 1 above. Timing of Application 2: Network Replacement The first modem uses an internal timing source and supplies the timing for the entire system. The first G.703 recovers the timing and clocks the data into the FIFO.
  • Page 5: Connection To The Twisted Pair Interface

    Not Used Octet Mode Reserved for Factory Once the Model IM 1/F is properly configured, it is ready to install into a PE 1090 or 1092. This section tells you how to properly connect the Model IM 1/F. 4.1 CONNECTION TO THE MODEM’S SERIAL PORT...
  • Page 6: Specifications

    The RJ-45 connector on the Model IM 1/F twisted pair interface is pre-wired according to the signal/pin relationships shown in Figure 5 below. 1 (RX Tip) 2 (RX Ring) 3 (N/C) 4 (TX Ring) 5 (TX Tip) 6 (N/C) 7 (N/C)
