GV-LPR
Qualified Image Criteria
GeoVision GV-LPR Licence Place Recognition software
Quick Setup Guide
© 2010 GeoVision, Inc. All rights reserved.
2010/11
English
All GeoVision Products are manufactured in Taiwan.
www.cctvireland.ie
Lo-Call 1890 866 900
e-sales@cctvireland.ie
Advertisement
Related Manuals for GeoVision GV-LPR
Summary of Contents for GeoVision GV-LPR
- Page 1 GV-LPR Qualified Image Criteria GeoVision GV-LPR Licence Place Recognition software Quick Setup Guide © 2010 GeoVision, Inc. All rights reserved. 2010/11 English All GeoVision Products are manufactured in Taiwan. www.cctvireland.ie Lo-Call 1890 866 900 e-sales@cctvireland.ie...
- Page 2 To increase the licence plate recognition accuracy, you need to install the LPR camera in the proper way to capture the qualified plate images. When you install the LPR camera, there are certain criteria to meet, including the plate size, the lighting condition and the angle of the camera. In this document, we provide the qualified image examples, and the unqualified image examples, which are generated when the LPR camera is set in an improper way.
- Page 3 The unqualified image examples The plate is the hollow-letter type: Example Try to: Reduce the illumination. The image is unclear: Example Try to: Adjust the focus or the shutter speed of the camera. www.cctvireland.ie Lo-Call 1890 866 900 e-sales@cctvireland.ie...
- Page 4 The image is overexposed: Example Try to: Reduce the illumination, or adjust the angle or the setup direction of the camera. The image is interfered by the headlight: Example Try to: Use the professional LPR camera to avoid the headlight interference. www.cctvireland.ie Lo-Call 1890 866 900 e-sales@cctvireland.ie...
- Page 5 The plate size is too small: Example Try to: Zoom in the camera or reduce the distance between the camera and the vehicle. You should capture and fill the image with a full width of vehicle. The plate size is too big: Example Try to: Zoom out the camera or enlarge the distance between the camera and...
- Page 6 The image contrast is low: Example Try to: Improve the lighting condition. The plate is slanted: Example 8° More than 8° Try to: Adjust the camera setup angle and make sure the angle of deviation in the captured license plate is within eight degrees. www.cctvireland.ie Lo-Call 1890 866 900 e-sales@cctvireland.ie...
- Page 7 The plate is in shadow: Example Try to: Avoid placing the camera where it can be subjected to direct sunlight or reflections. Visible shadow edges in the camera view may degrade the recognition accuracy. www.cctvireland.ie Lo-Call 1890 866 900 e-sales@cctvireland.ie...
- Page 8 LPR Camera Installation Guidelines Camera Installation ● Installing the camera in the front (Recommended): Install the camera in the upper front of the vehicle as shown below. Ensure to install the camera to meet the following conditions. In this way, the height of the captured plate characters would approximately fall between 30 and 35 pixels.
- Page 9 ● Installing the camera on the side: Install the camera in the side front of the vehicle as shown below. To avoid capturing unnecessary contents in the image, the camera should be installed in a higher position to capture the front part of the vehicle only.
- Page 10 Detection Mode You can set up two detection modes in the GV-LPR System: Motion Detection mode and I/O Device mode. In the Motion Detection mode, the GV-LPR System starts recognition when any motion is detected. It is normally used on freeway recognition where the vehicle speed is high. In the I/O Detection mode, the GV-LPR System starts recognition when the input device is triggered.
- Page 11 www.cctvireland.ie Lo-Call 1890 866 900 e-sales@cctvireland.ie...
- Page 12 9F, No. 246, Sec. 1, Neihu Rd., Neihu District, Taipei, Taiwan Tel: +886-2-8797-8376 Fax: +886-2-8797-8335 support@geovision.com.tw http://www.geovision.com.tw www.cctvireland.ie Lo-Call 1890 866 900 e-sales@cctvireland.ie...
