About this guide
This guide describes the SmartNode 4940 hardware, installation and basic configuration. For detailed software
configuration information refer to the SmartWare Software Configuration Guide and the available Configura-
tion Notes.
Audience
This guide is intended for the following users:
•
Operators
•
Installers
•
Maintenance technicians
Structure
This guide contains the following chapters and appendices:
•
Chapter 1
on page 13 provides information about router features and capabilities
•
Chapter 2
on page 20 contains an overview describing router operation and applications
•
Chapter 3
on page 22 provides hardware installation procedures
•
Chapter 4
on page 27 provides quick-start procedures for configuring the SmartNode router
•
Chapter 5
on page 34 contains information on contacting Patton technical support for assistance
•
Appendix A
on page 37 contains compliance information for the router
•
Appendix B
on page 41 contains specifications for the routers
•
Appendix C
on page 47 provides cable recommendations
•
Appendix D
on page 52 describes the router's ports and pin-outs
•
Appendix E
on page 55 lists the factory configuration settings for SmartNode 4940
•
Appendix F
on page 57 provides license information that describes acceptable usage of the software pro-
vided with the SmartNode 4940
For best results, read the contents of this guide before you install the router.
