About this guide
This guide describes the SmartNode 4170 hardware, installation and basic configuration. For detailed software
configuration information refer to the
Audience
This guide is intended for the following users:
•
Operators
•
Installers
•
Maintenance technicians
Structure
This guide contains the following chapters and appendices:
•
Chapter 1
on page 14 provides information about gateway features and capabilities
•
Chapter 2
on page 19 contains an overview describing gateway operation and applications
•
Chapter 3
on page 21 provides quick start hardware installation procedures
•
Chapter 4
on page 26 provides quick-start procedures for configuring the SmartNode gateway
•
Chapter 5
on page 31 contains information on contacting Patton technical support for assistance
•
Appendix A
on page 34 contains compliance and regulatory information for the gateway
•
Appendix B
on page 37 contains specifications for the gateways
•
Appendix C
on page 41 provides cable recommendations
•
Appendix D
on page 45 describes the gateway's ports and pin-outs
•
Appendix E
on page 48 lists the factory configuration settings for SmartNode 4170
•
Appendix F
on page 50 provides license information that describes acceptable usage of the software pro-
vided with the SmartNode 4170
For best results, read the contents of this guide before you install the VoIP Gateway.
Trinity Command Line Reference Guide
and the available
Web
Wizard.
