SmartNode 4940 Getting Started Guide

Table 7. SmartNode Models and their Unique sysObjectID (Continued)

SmartNode Model

SN4941/4E120V

Note

The SysObjectIDs for the SN4940 G.SHDSL models are the same as the

corresponding non-G.SHDSL models listed above.

According to

table

7, an SNMP get request to .iso.org.dod.internet.mgmt.mib-2.system.sysObjectID of a Smart-

Node 4940/1E15V/EUI device reads out a numeric OID of 1.3.6.1.4.1.1768.100.4.16.1, which represents a

SmartNode 4940/1E15V/EUI device. The mapping of the sysObjectID to each of the SmartNode model is

realized with the SmartNode product identification MIB.

IMPORTANT

Identification of the SmartNode devices via SNMP

SysObjectID

.iso.org.dod.internet.private.enterprises.patton.products.sn49xx.20

1.3.6.1.4.1.1768.100.4.16.20

The SNMP agent running in SmartWare is SNMP version 1

(SNMPv1) compliant. SNMP version 2 (SNMPv2) and SNMP

version 3 (SNMPv3) are not currently supported.

B • Specifications
