Comfort Flame Cumberland32YWS Installation And Operation Instructions Manual

Vent free cumberland series universal firebox system

Advertisement

Quick Links

WELCOME HOME TO WARMTH
P900563-00
P/N 900563-00 Rev. N/C 09/2015
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
WARNING: Carefully review the instructions supplied with the decorative type unvented room heater for
the minimum fireplace size requirement.
Do not install the appliance in this firebox, unless this firebox meets the minimum dimensions required for
the installation.
This appliance may be installed in an aftermarket permanently located, manufactured (mobile) home,
where not prohibited by local codes. This appliance is only for use with the type of gas indicated on the
rating plate. This appliance is not convertible for use with other gases.
WARNING: For use only with a listed, gas-fired unvented decorative room heater not to exceed 40,000
Btu/H.
Do not build a wood fire.
WARNING:
FIRE OR EXPLOSION HAZARD
Failure to follow safety warnings exactly could result in serious injury, death, or property damage.
— Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other
appliance.
— WHAT TO DO IF YOU SMELL GAS:
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any phone in your building.
• Leave the building immediately.
• Immediately call your gas supplier from a neighbor's phone. Follow the gas supplier's instructions.
• If you cannot reach your gas supplier, call the fire department.
— Installation and service must be performed by a qualified installer, service agency or the gas supplier.
TM
PFS
®
US
Report No. F12-020
Installation and Operation Instructions
Comfort Flame™ Vent Free Cumberland Series
Universal Firebox System
Cumberland32YWS
Cumberland32XWS
Cumberland36YWS
Cumberland36XWS
Cumberland42YWS
Cumberland42XWS
Models

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Cumberland32YWS and is the answer not in the manual?

Questions and answers

Summary of Contents for Comfort Flame Cumberland32YWS

  • Page 1 Installation and Operation Instructions Comfort Flame™ Vent Free Cumberland Series WELCOME HOME TO WARMTH Universal Firebox System Models Cumberland32YWS P900563-00 ® Cumberland32XWS P/N 900563-00 Rev. N/C 09/2015 Cumberland36YWS Cumberland36XWS Report No. F12-020 Cumberland42YWS Cumberland42XWS INSTALLER: Leave this manual with the appliance.
  • Page 2: Table Of Contents

    Thank you for your purchase. We appreciate your TABLE OF CONTENTS business! Safety ..................... 2 Please carefully read and follow all instructions in this manual. Pay Local Codes ................... 3 special attention to all warnings and safety information. Requirements for the Commonwealth of Massachusetts....3 Following these safety, care, and operation instructions will help Product Features ................
  • Page 3: Local Codes

    SAFETY Continued State of Massachusetts: The installation must be made by a licensed You must operate this fireplace with the provided plumber or gas fitter in the Commonwealth of Massachusetts. fireplace screen, hood if provided, in place. Make Sellers of unvented propane or natural gas-fired supplemental sure these parts are in place and screens are closed room heaters shall provide to each purchaser a copy of 527 CMR before running firebox.
  • Page 4: Product Features

    PRODUCT FEATURES LOCATING FIREBOX OPERATION PLANNING This firebox is designed for use with approved ANSI Z21.11.2 deco- Plan where you will install the firebox. This will save time and money rative type unvented room heaters. (Physical size limitations apply. later when you install the firebox. Before installation, consider the Refer to minimum firebox requirements supplied with log heater.) It following: requires no outside venting or chimney making installation easy and...
  • Page 5: Product Specifications

    PRODUCT SPECIFICATIONS 32" MODELS " 6" " " Firebox Top View " " 7" " " " 7" " " " Front View " Outside Air Kit Location Electrical " Outlet 24" " " " " " " " " "...
  • Page 6 PRODUCT SPECIFICATIONS Continued 36" MODELS 6" " " 25" Firebox Top View " " 21" 7" " " 43" Front View " Outside Air Kit Location " " " " " " " " " " Electrical " " Outlet Left Side View Right Side View Figure 2 - Product Specifications 36'' Models...
  • Page 7 PRODUCT SPECIFICATIONS Continued 42" MODELS 6" " " " Firebox Top View " 50" 40" 24" " " " " " Front View Outside " Air Kit 40" Location " " " " " " " " " " Electrical "...
  • Page 8: Air For Combustion And Ventilation

    AIR FOR COMBUSTION AND VENTILATION Confined and Unconfined Space WARNING: This heater shall not be installed in a The National Fuel Gas Code, ANSI Z223.1/NFPA 54 defines a confined room or space unless the required volume of indoor space as a space whose volume is less than 50 cubic feet per 1,000 combustion air is provided by the method described Btu per hour (4.8 m per kw) of the aggregate input rating of all ap-...
  • Page 9 AIR FOR COMBUSTION AND VENTILATION Continued Ventilation Air From Outdoors The space in the above example is a confined space because the actual Btu/Hr used is more than the maximum Btu/Hr the space can support. Provide extra fresh air by using ventilation grills or ducts. You must You must provide additional fresh air.
  • Page 10: Installation

    INSTALLATION INSTALLATION CLEARANCES WARNING: A qualified service person must install WARNING: Maintain the minimum clearances. If you firebox. Follow all local codes. can, provide greater clearances from floor, ceiling and adjoining wall. WARNING: Never install the firebox • in a bedroom or bathroom* Carefully follow these instructions.
  • Page 11 INSTALLATION Continued Table 1 CAUTION: Do not allow the vent-free gas log heater Rough Opening Dimensions for to touch or extend beyond the fireplace screen. Built-in Installation Front Width Depth NOTICE: Surface temperatures of adjacent walls and Model (Inside to Inside) Height (Min.) 32"...
  • Page 12: Nailing Flanges

    INSTALLATION Continued IMPORTANT: If installing blower accessory, see Wiring Instructions, IMPORTANT: Noncombustible materials such as brick, tile, etc. may page 13. overlap the front facing, but should never cover any necessary open- ings like louvered slots. 3. Carefully set firebox in front of rough opening with back of firebox inside wall opening.
  • Page 13 INSTALLATION Continued INSTALLING OPTIONAL BLOWER ACCESSORY Equipment Shutoff Valves (Install One) NOTICE: The firebox identification label (including model number, serial number, clearances, etc.) is located in the right side screen pocket area on the front of the firebox. See Figure 24, page 20. NOTICE: If a log set is installed in the firebox, discon- nect log set from gas supply and remove from firebox.
  • Page 14 INSTALLATION Continued Accessing Blower Compartment WARNING: If there is a duplex electrical outlet Decide which way you intend to gain access into the bottom rear of installed in the right side of the bottom of the fireplace the firebox to install the blower accessory (Louvered models only). base area (see Figure 14), be sure that the electrical Radiant Models: Accessibility to the bottom, can only be gained through the access panel underneath the bottom front refractory brick...
  • Page 15 INSTALLATION Continued 3. Remove metal lock nut from plastic control shaft by turning lock Variable Fan Switch nut with pliers counter clockwise. Mount speed control box by placing plastic control shaft through hole on lower portion of the Black left or right side of secondary face by sliding control box down through large hole in firebox bottom and up behind firebox side (see Figure 17, page 15).
  • Page 16 INSTALLATION Continued Screen Pocket INSTALLING FIREPLACE HOOD AND SCREEN 1. Attach hood to firebox using screws provided (see Figure 20). 2. Insert each rod through all rings located at top of screen. 3. Insert first rod into rear hole in left side of firebox. Fasten rod to rear hole near center of firebox using #10 x 3/8"...
  • Page 17: Service Hints

    SERVICE HINTS REPLACEMENT PARTS See Pages 20 to 23 for a complete replacement parts list. Use only When Gas Pressure Is Too Low parts supplied from the manufacturer. • pilot will not stay lit Normally, all parts should be ordered through your IHP distributor •...
  • Page 18: Accessories

    ACCESSORIES Purchase these fireplace accessories from your local dealer. If they can not supply these accessories, contact IHP at Comfortflame.US.com for referral information. CAT NO. MODEL DESCRIPTION HOODS H32P 32" VF Fireplace Hood - Platinum (NOT SHOWN) F1049 H36P 36" VF Fireplace Hood - Platinum F1051 H42P 42"...
  • Page 19 ACCESSORIES Continued CABINET MANTEL AND FULL HEARTH BASE For all models. Mantel features clean, classic lines. Complete assembly instructions included. Note: No 42" mantels offered at this time. 32” Corner Cabinet Mantle, Traditional Style, F1142 C32TU Unfinished Oak 32” Corner Cabinet Mantle, Traditional Style, Light Oak F1143 C32TO Stain...
  • Page 20: Parts

    PARTS CATALOG NO. MODEL F2558 Cumberland32YWS F2559 Cumberland32XWS F2560 Cumberland36YWS F2561 Cumberland36XWS F2562 Cumberland42YWS F2563 Cumberland42XWS Comfortflame.US.com 900563-00NC...
  • Page 21 PARTS This list contains replaceable parts used in your firebox. When ordering parts, follow the instructions listed under Replacement Parts on page 18 of this manual. WARNING: Contact an IHP dealer to obtain any of these parts. Never use substitute materials not approved by IHP.
  • Page 22 PARTS CATALOG NO. MODEL F2558 Cumberland32YWS F2559 Cumberland32XWS F2560 Cumberland36YWS F2561 Cumberland36XWS F2562 Cumberland42YWS F2563 Cumberland42XWS Comfortflame.US.com 900563-00NC...
  • Page 23 PARTS This list contains replaceable parts used in your firebox. When ordering parts, follow the instructions listed under Replacement Parts on page 18 of this manual. WARNING: Contact an IHP dealer to obtain any of these parts. Never use substitute materials not approved by IHP.
  • Page 24 NOTES ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ Comfortflame.US.com 900563-00NC...
  • Page 25 NOTES ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ 900563-00NC Comfortflame.US.com...
  • Page 26 NOTES ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ Comfortflame.US.com 900563-00NC...
  • Page 27: Warranty

    THE WARRANTY Innovative Hearth Products ("IHP") 20 Year Limited Warranty warrants your Comfort Flame™ Brand gas fi replace or insert ("Product") to be free from defects in materi- als and workmanship at the time of manufacture. The Product body and fi rebox carry the 20 Year Limited Warranty. Ceramic glass carries the 20 Year Limited Warranty against thermal breakage only.
  • Page 28 WARRANTY KEEP THIS WARRANTY Model Number Serial Number Date Installed Dealer's Name Dealer's Phone Number Keep receipt for warranty verification Innovative Hearth Products reserves the right to make changes at any time, without notice, in design, materials, specifications, prices and also to discontinue colors, styles and products. Consult your local distributor for fireplace code information.
