Comfort Flame Sonoma18LZN Installation And Operation Instruction Manual

Vented natural gas logs decorative appliance

Advertisement

Quick Links

WELCOME HOME TO WARMTH
P900579-00
P/N 900579-00 Rev. N/C 12/2015
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future reference.
This appliance may be installed in an aftermarket permanently located, manufactured (mobile) home, where not
prohibited by local codes. This appliance is only for use with the type of gas indicated on the rating plate. This
appliance is not convertible for use with other gases.
WARNING: This appliance is for installation only in
a solid-fuel burning masonry or UL127 factory-built
fireplace, constructed of noncombustible material
and connected to a working flue. (See page 6 for
minimum flue opening.)
These logs are approved by the manufacturer for installation in listed indoor and outdoor solid fuel burning
fireplaces.
WARNING: FIRE OR EXPLOSION HAZARD
Failure to follow safety warnings exactly could result in serious injury, death, or property damage.
— Do not store or use gasoline or other flammable vapors and liquids in the vicinity of this or any other
appliance.
— WHAT TO DO IF YOU SMELL GAS:
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use any phone in your building.
• Leave the building immediately.
• Immediately call your gas supplier from a neighbor's phone. Follow the gas supplier's instructions.
• If you cannot reach your gas supplier, call the fire department.
— Installation and service must be performed by a qualified installer, service agency or the gas supplier.
TM
PFS
®
US
Report No. F09-168
Installation and Operation Instructions
Comfort Flame™ Vented Natural Gas Logs
Decorative Appliance
Sonoma18LZN
Sonoma24LZN
WARNING: This is a gas-fired appliance. It uses
air (oxygen) from the room in which it is installed.
Provisions for adequate combustion and ventilation
air must be provided. Refer to the National Fual
Gas Codes, ANSI Z233.1/NFPA 54, Section 5.3 for
Combustion and Ventilation.
Models

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Sonoma18LZN and is the answer not in the manual?

Questions and answers

Summary of Contents for Comfort Flame Sonoma18LZN

  • Page 1 Installation and Operation Instructions Comfort Flame™ Vented Natural Gas Logs Decorative Appliance WELCOME HOME TO WARMTH Models ® P900579-00 Sonoma18LZN Report No. F09-168 P/N 900579-00 Rev. N/C 12/2015 Sonoma24LZN INSTALLER: Leave this manual with the appliance. CONSUMER: Retain this manual for future reference.
  • Page 2: Table Of Contents

    Thank you for your purchase. We appreciate your TABLE OF CONTENTS business! Safety ..................... 2 Please carefully read and follow all instructions in this manual. Pay Local Codes ................... 4 special attention to all warnings and safety information. Unpacking ..................4 Following these safety, care, and operation instructions will help Product Identification ..............
  • Page 3 SAFETY Continued Carefully supervise young children when they are in DANGER: Carbon monoxide poisoning may lead the room with appliance. to death! Carbon Monoxide Poisoning: Early signs of carbon monoxide poi- You must operate this appliance with a fireplace screen soning resemble the flu, with headaches, dizziness or nausea.
  • Page 4: Local Codes

    SAFETY Continued PRODUCT IDENTIFICATION 9. Do not use a blower insert, heat exchanger insert or other acces- Hearth Kit Model: _________________ sory not approved for use with this log set. Serial Number: ___________________ 10. This installation and provisions for combustion and ventilation air Log Set Model: __________________ must conform to the National Fuel Gas Code, ANSI Z233.1/NFPA 54, Air for Combustion and Ventilation.
  • Page 5: Installation

    Btu/Hr Input Btu/Hr Input Minimum Vent MODEL to the burner pan. The data plates contain important Natural Gas Propane/LP Gas Opening warranty information. Sonoma18LZN 55,000 45,000 8" dia. 18" Multi-Side WARNING: Before installing in a solid fuel burn- Sonoma24LZN 65,000 55,000 8"...
  • Page 6 INSTALLATION Continued Equipment Shutoff Valve INSTALLING DAMPER CLAMP With 1/8" NPT Tap* Secure the damper stop clamp provided to the leading edge of the damper as shown in Figure 3. If for any reason this clamp doesn't work on your fireplace, another suitable clamp or permanent stop Approved must be installed or the damper blade must be cut or removed.
  • Page 7 INSTALLATION Continued Pressure Testing Gas Supply Piping System 6. Press right and left side burners onto burner connection fittings. Burner porting should face downward (see Figure 6). Test Pressures In Excess Of 1/2 PSIG (3.5 kPa) 1. Disconnect appliance with its appliance main gas valve (control Burner Connection valve) and equipment shutoff valve from gas supply piping system.
  • Page 8 INSTALLATION Continued OPTIONAL GA9050A-1 (F0235) ON/OFF SAFETY VALVE/PILOT KIT 10. Install thermocouple, pilot and ignitor onto valve cover as shown ASSEMBLY in Figure 11. Use the provided screws. 11. Push control rod extension onto “D” shaped control rod through For additional convenience and safety or for propane/LP conversion, center hole in cover.
  • Page 9 INSTALLATION Continued Propane/LP Gas Conversion Changing Pilot Orifice To convert to propane/LP gas, burner inlet fitting and pilot orifice must The pilot is provided with a natural gas orifice installed. For propane/ be replaced. The propane/LP burner inlet fitting is supplied with orifice LP gas you must remove natural gas orifice and replace it with a installed for a 24"...
  • Page 10 INSTALLATION Continued ADDING PAN MATERIAL 1. Open bags of ash bed material (vermiculite) and spread it evenly across burner pan to the top. You may overflow front and sides of pan to cover the entire pan and connecting hardware. Do not cover GA9050A-1 (F0235) or GA9150A (F0237) valve.
  • Page 11: Operation

    OPERATION FOR YOUR SAFETY CURING READ BEFORE LIGHTING LOGS WARNING: Keep flue open when operating unit. During the 2-3 hour appliance break-in period, you may detect an odor from the appliance as the various paints and compounds used in the manufacturing of this log set cure. This is a normal and tem- WARNING: If you do not follow these instructions porary situation that is not cause for alarm.
  • Page 12: Cleaning And Maintenance

    CLEANING AND MAINTENANCE OPERATION Continued • Keep the area around the log set clean and clear of debris. Thermocouple • Occasionally, you may use a soft bristle brush to clean logs. • Once every year a qualified agency or certified chimney sweep should examine and clean the venting system of the fireplace.
  • Page 13: Troubleshooting

    TROUBLESHOOTING WARNING: Turn off log set and let cool before servicing. Only a qualified service person should service and repair log set. Note: All troubleshooting items are listed in order of operation. OBSERVED PROBLEM POSSIBLE CAUSE REMEDY Log set is smoking/sooting excessively 1.
  • Page 14 TROUBLESHOOTING Continued OBSERVED PROBLEM POSSIBLE CAUSE REMEDY When ignitor button is pressed, there is 1. Gas supply turned off or equipment 1. Turn on gas supply or open equipment spark at pilot but no ignition (GA9050A-1 shutoff valve closed shutoff valve - F0235) Only) 2.
  • Page 15 TROUBLESHOOTING Continued WARNING: If you smell gas • Shut off gas supply. • Do not try to light any appliance. • Do not touch any electrical switch; do not use any phone in your building. • Immediately call your gas supplier from a neighbor’s phone. Follow the gas supplier’s instructions. •...
  • Page 16: Parts

    PARTS CATALOG NO. MODEL F2615 Sonoma18LZN F2616 Sonoma24LZN Comfortflame.US.com 900579-00_NC...
  • Page 17 12 of this manual. WARNING: Contact an IHP dealer to obtain any of these parts. Never use substitute materials not approved by IHP. Use of non-approved parts can result in poor performance and safety hazards. Sonoma18LZN Sonoma24LZN CATALOG NO. DESCRIPTION...
  • Page 18 12 of this manual. WARNING: Contact an IHP dealer to obtain any of these parts. Never use substitute materials not approved by IHP. Use of non-approved parts can result in poor performance and safety hazards. Sonoma18LZN Sonoma24LZN CATALOG NO.
  • Page 19: Accessories

    ACCESSORIES Purchase these fireplace accessories from your local dealer. If they can not supply these accessories, contact IHP at Comfortflame.US.com for referral information. CAT NO. MODEL DESCRIPTION WALL-MOUNT ON/OFF SWITCH For all models. Allows the gas log set to be turned on and off with a wall switch. (Not Shown) GA9150A (F0237) F0245...
  • Page 20 NOTES ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ Comfortflame.US.com 900579-00_NC...
  • Page 21 NOTES ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ 900579-00_NC Comfortflame.US.com...
  • Page 22 NOTES ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ ______________________________________________________ Comfortflame.US.com 900579-00_NC...
  • Page 23: Warranty

    THE WARRANTY Innovative Hearth Products Limited One Year Warranty ("IHP") warrants your Comfort Flame brand Gas Log Set ("Product") to be free from defects in materials and work- manship at the time of manufacture. The logs and grate carry the Limited One Year Warranty. After installation, if covered components manufactured by IHP are found to be defective in materials or workmanship during the Limited One Year Warranty period and while the Product remains at the site of the original installation, IHP will, at its option, repair or replace the covered components.
  • Page 24 Comfortflame.US.com Record the following important information about your fireplace: Appliance model number Appliance serial number Date appliance was Installed Type of gas appliance uses Dealer name P900579-00 Innovative Hearth Products reserves the right to make changes at any time, without notice, in design, materials, specifications, prices and also to discontinue colors, styles and products.
