Comfort Flame Aurora35DEN Installation And Operation Instructions Manual

Aurora direct-vent gas fireplaces

Advertisement

Quick Links

WELCOME HOME TO WARMTH
P/N 900475-00 Rev. NC 08/2015
Ce manuel est disponible en francais, simplement
en faire la demande. Numéro de la pièce 900475-01.
P900475-00
INSTALLER: Leave this manual with the appliance.
CONSUMER: Retain this manual for future
reference.
This appliance may be installed in an aftermarket permanently located, manufactured home (USA only)
or mobile home, where not prohibited by local codes. This appliance is only for use with the type of gas
indicated on the rating plate. This appliance is not convertible for use with other gases, unless a certified kit
is used.
Cet appareil peut installé dans une maison préfabriquée (mobile) déjà installée à demeure, si les réglements
locaux le permettent. Ce appareil doit être utilisé uniquement avec le type de gaz indiqué sure la plaque
signalétique. Cet appareil ne peut être converti à d'autres gaz, sauf si une trousse de conversion est utilsée.
WARNING:
FIRE OR EXPLOSION HAZARD
Failure to follow safety warnings exactly could
result in serious injury, death, or property damage.
- Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any
other appliance.
- WHAT TO DO IF YOU SMELL GAS
• Do not try to light any appliance.
• Do not touch any electrical switch; do not use
any phone in your building.
• Leave the building immediately.
• Immediately call your gas supplier from a neigh-
bor's phone. Follow the gas supplier's instruc-
tions.
• If you cannot reach your gas supplier, call the
fire department.
- Installation and service must be performed by
a qualified installer, service agency or the gas
supplier.
Installation and Operation Instructions
TM
Aurora
Models
PFS
Aurora35DEN
®
C
US
Aurora35DEP
Aurora40DEN
Report No. F13-094
Installateur : Laissez cette notice avec l'appareil.
Consommateur : Conservez cette notice pour
consultation ultérieure.
Direct-Vent Gas Fireplaces
TM
Aurora40DEP
Aurora45DEN
Aurora45DEP
AVERTISSEMENT:
RISQUED'INDENDIE OU D'EXPLOSION
Le non-respect Des avertissements de sécurité
pourrait d'entraîner des blessures graves, la mort
ou des dommages matériels.
- Ne pas entreposer ni utilizer d'essence ni d'autres
vapeurs ou liquides inflammables dans le voisinage
de cet appareil ou de tout autre appareil.
- QUE FAIRE SI VOUS SENTEZ UNE ODEUR DE GAZ:
• Ne pas tenter d'allumer d'appareil.
• Ne touchez à aucan interrupteur. Ne pas vous servir
des téléphones se trouvant dans le bâtiment où
vous trouvez.
• Sortez immédiatement de bâtiment.
• Appelez immédiatement votre fournisseur de
gaz depuis un voisin. Suivez les instructions du
fournisseur.
• Si vous ne pouvez rejoindre le fournisseur de gaz,
appelez le service des incindies.
- L'installation et l'entretien doivent être assurés par
un installateur ou un service d'entretien qualifié
ou par le fournisseur de gaz.
AuroraCD35DEN
AuroraCD40DEP
AuroraCD35DEP
AuroraCD45DEN
AuroraCD40DEN
AuroraCD45DEP

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Aurora35DEN and is the answer not in the manual?

Questions and answers

Summary of Contents for Comfort Flame Aurora35DEN

  • Page 1 Installation and Operation Instructions WELCOME HOME TO WARMTH Aurora Direct-Vent Gas Fireplaces P/N 900475-00 Rev. NC 08/2015 Models Ce manuel est disponible en francais, simplement Aurora35DEN Aurora40DEP AuroraCD35DEN AuroraCD40DEP ® en faire la demande. Numéro de la pièce 900475-01. Aurora35DEP...
  • Page 2: Important Safety Information

    Innovative Hearth Products General Information Aurora™ 35/40/45 Direct-Vent Gas Fireplaces 900475-00, 08/2015 SAFETY AND YOUR FIREPLACE See attached color flyer for proper color representation DANGER HOT GLASS WILL CAUSE BURNS. DO NOT TOUCH GLASS UNTIL COOLED. NEVER ALLOW CHILDREN TO TOUCH GLASS. A barrier designed to reduce the risk of burns from the hot viewing glass is pro- vided with this appliance and shall be installed for the protection of children and other at-risk individuals.
  • Page 3 Innovative Hearth Products General Information Aurora™ 35/40/45 Direct-Vent Gas Fireplaces 900475-00, 08/2015 La sécurité et Safety and Your Seguridad y su votre foyer Fireplace chimenea All parts of your ¡Todas las partes de la Toutes les parties de votre IHP fireplace get chimenea IHP se ponen foyer IHP deviennent EXTRÊMEMENT CHAUDES !
  • Page 4: Table Of Contents

    Innovative Hearth Products General Information Aurora™ 35/40/45 Direct-Vent Gas Fireplaces 900475-00, 08/2015 THANk YOU FOR YOUR PURCHASE. WE APPRECIATE YOUR bUSINESS! Please carefully read and follow all instructions in this manual. Pay special attention to all warnings and safety information. Following these safety, care, and operation instructions will help ensure many years of dependable and enjoyable service from your fireplace.
  • Page 5: General Information

    Innovative Hearth Products General Information Aurora™ 35/40/45 Direct-Vent Gas Fireplaces 900475-00, 08/2015 IMPORTANT SAFETY INFORMATION Important Safety Informa- L’information de sûreté Información importante de tion importante seguridad 1. WARNING: Do not operate appliance 1. AVERTISSEMENT. Ne pas utiliser l’appareil 1. ADVERTENCIA: No opere el artefacto con el with the glass front removed, cracked, si le panneau frontal en verre n’est pas en frente de vidrio quitado, agrietado o roto.
  • Page 6: Fireplace Installation, Operation, And Maintenance Notices

    Innovative Hearth Products General Information Aurora™ 35/40/45 Direct-Vent Gas Fireplaces 900475-00, 08/2015 APPLIANCE INSTALLATION, SERVICE, AND MAINTENANCE NOTICES WARNING Improper installation, adjustment, alteration, service or maintenance can cause injury or property damage. Refer to this manual. For assistance or additional information consult a qualified installer, service agency or the gas supplier.
  • Page 7 Innovative Hearth Products General Information Aurora™ 35/40/45 Direct-Vent Gas Fireplaces 900475-00, 08/2015 APPLIANCE OPERATION NOTICES These fireplaces are vented gas appliances. Do not burn wood or other material in these appliances. These appliances are designed to operate on natural gas or propane gas only. The use of other fuels or combinations of fuels will degrade the performance of this system and may be dangerous.
  • Page 8: Packaging

    Innovative Hearth Products General Information Aurora™ 35/40/45 Direct-Vent Gas Fireplaces 900475-00, 08/2015 INSTALLATION PACkAGING All models include The assembled vented gas fireplace heater is packaged with: • Literature Kit (envelope in bottom compartment containing Installation and Operation Instructions (this manual), Hot Glass Safety Flyer, and Safety-In-Operation Warning Labels) •...
  • Page 9: Btu Input

    Innovative Hearth Products General Information Aurora™ 35/40/45 Direct-Vent Gas Fireplaces 900475-00, 08/2015 bTU Input Table 1 - Input Rate (BTU/HR), Gas Valves Natural Gas Propane Gas Models High Rate Low Rate High Rate Low Rate 35” Models 20,000 14,000 19,000 13,000 40”...
  • Page 10: Requirements For The Commonwealth Of Massachusetts

    Innovative Hearth Products Installation Aurora™ 35/40/45 Direct-Vent Gas Fireplaces 900475-00, 08/2015 The appliance and its appliance main gas valve must be disconnected from the gas supply piping system during any pressure testing of that system at test pressures in excess of 1/2 psi (3.5 kPa). The appliance must be isolated from the gas supply piping system by closing its equipment shutoff valve during any pressure testing of the gas supply piping system at test pressures equal to or less than 1/2 psi (3.5 kPa).
  • Page 11 Innovative Hearth Products Installation Aurora™ 35/40/45 Direct-Vent Gas Fireplaces 900475-00, 08/2015 NOTE: Do not use loose, or blown-in insulation in the cavity surrounding the fireplace. If the fireplace is being installed on a cement slab in cold climates, a sheet of plywood or other raised platform can be placed underneath to prevent conduction of cold transferring to the fireplace and into the room.
  • Page 12: Manufactured Home Requirements

    Innovative Hearth Products Installation Aurora™ 35/40/45 Direct-Vent Gas Fireplaces 900475-00, 08/2015 MANUFACTURED HOME REQUIREMENTS This appliance may be installed in an aftermarket, permanently located, manufactured home (USA only) or mobile home, where not prohibited by local codes. Cet appareil peut être installé dans une maison préfabriquée (mobile) déjà installée à demeure si les règlements locaux le permettent.
  • Page 13: Vent Termination Clearances

    Innovative Hearth Products Installation Aurora™ 35/40/45 Direct-Vent Gas Fireplaces 900475-00, 08/2015 VENT TERMINATION CLEARANCES These instructions should be used as a guideline and do not supersede local codes in any way. Install venting according to local codes, these instructions, the current National Fuel Gas Code (ANSI z223.1/NFPA 54) in the USA or the current standards of CAN/CGA-b149.1 in Canada.
  • Page 14 Innovative Hearth Products Installation Aurora™ 35/40/45 Direct-Vent Gas Fireplaces 900475-00, 08/2015 Table 7 - Horizontal vent termination clearances for buildings with combustible and noncumbustible exteriors Inside Corner Outside Corner Recessed Location See Table 6 Fixed Balcony with No Side Wall Balcony with Perpendicular Side Wall Openable Fixed Closed...
  • Page 15: Minimum Clearances To Combustibles

    Innovative Hearth Products Installation Aurora™ 35/40/45 Direct-Vent Gas Fireplaces 900475-00, 08/2015 MINIMUM CLEARANCES TO COMbUSTIbLES Fireplace And Vent Clearances The fireplace is approved with zero clearance to combustible materials on all sides (Table 8), with the following exception: The unit may not be recessed (allowance made for mantel legs / side trim in Figure 5). When the unit is installed with one side flush with a wall, the wall on the other side of the unit must not extend beyond the front edge of the unit (Figure 5).
  • Page 16: Wall Finishes / Surrounds / Mantels

    Innovative Hearth Products Installation Aurora™ 35/40/45 Direct-Vent Gas Fireplaces 900475-00, 08/2015 Figure 5 - Combustible Side Clearances Figure 6 - Mantel Height At 6” minimum side wall At 6 in. minimum clearance, a Mantel depth side wall clearance, combustible Top View of Top View of a combustible wall 20 (508)
  • Page 17: Installation Sequence

    Innovative Hearth Products Installation Aurora™ 35/40/45 Direct-Vent Gas Fireplaces 900475-00, 08/2015 INSTALLATION SEQUENCE The typical sequence of installation is outlined below; however, each installation is unique and may result in variations to the steps described. See the pages referenced in the following steps for detailed instructions. Framing 1.
  • Page 18 Innovative Hearth Products Installation Aurora™ 35/40/45 Direct-Vent Gas Fireplaces 900475-00, 08/2015 Table 10 - Fireplace Framing Specifications Framing Model NOTE: Dimension “D” is the construction to be 10-1/2 required framing depth when 35-3/8 36-1/4 38-3/4 23-3/8 2 x 4, or larger. 35”...
  • Page 19: Route The Gas Supply Line To The Fireplace

    Innovative Hearth Products Installation Aurora™ 35/40/45 Direct-Vent Gas Fireplaces 900475-00, 08/2015 Prepare the Fireplace Top Spacers 1. The two (2) 4” standoff spacers on top of the fireplace cabinet are shipped flat. Remove the screw adjacent to the detached end (Figure 7). 2.
  • Page 20 Innovative Hearth Products Installation Aurora™ 35/40/45 Direct-Vent Gas Fireplaces 900475-00, 08/2015 Determining Vent Setup in the Combination Venting Unit Combination venting units are shipped with rear venting setup nearly ready for install. If this is the type of vent you require, remove all insulation packing and flue plug block off from rear venting and proceed with fireplace installation.
  • Page 21 Innovative Hearth Products Installation Aurora™ 35/40/45 Direct-Vent Gas Fireplaces 900475-00, 08/2015 Outside preparation of the fireplace for top-vent conversion Rough in the Electrical Supply, if Needed As necessary, rough in the fireplace electrical supply per NEC and local codes. Place the Fireplace in the Framing and Secure NOTE: Nailing flanges, combustible members, and screw heads in areas directly adjacent to the nailing flanges are EXEMPT from the 1/2”...
  • Page 22 Innovative Hearth Products Installation Aurora™ 35/40/45 Direct-Vent Gas Fireplaces 900475-00, 08/2015 Install the Vent Restrictor (if necessary) 1. Use the vent run descriptions in Figure 11 to determine if a vent restrictor is necessary. U-Shaped Vent Restrictor 2. If necessary, assemble the vent restrictor and wing as detailed in Figure 14. U-Shaped Vent Restrictor 3.
  • Page 23 Innovative Hearth Products Installation Aurora™ 35/40/45 Direct-Vent Gas Fireplaces 900475-00, 08/2015 Vent Restrictor with Horizontal Terminations When horizontally terminating a vent system with a vertical vent run up to 4 ft through an exterior wall, no vent restrictor is required. If installing more than 4 ft of vertical venting, install the restrictor (Figure 13), from inside or outside the unit, in the inner fireplace collar.
  • Page 24 Innovative Hearth Products Installation Aurora™ 35/40/45 Direct-Vent Gas Fireplaces 900475-00, 08/2015 Vent section length table Table 14 will assist calculating how many vent sections are needed for the planned vent configuration. When a vent section is engaged with another section, its effective length will be 1-1/2” shorter. Table 14 - Vent Section Length Nominal Section Nominal Section Length...
  • Page 25: Install The Vent System

    Innovative Hearth Products Installation Aurora™ 35/40/45 Direct-Vent Gas Fireplaces 900475-00, 08/2015 Clearance to combustibles Maintain the minimum clearance to combustibles (e.g., framing, attic, ceiling insulation, etc.). For all vertical runs: • 1” (25 mm) from all sides NOTE: Attic insulation shield (H3907, see Page 46) must be installed when blown or loose-fill insulation is used, and is required for all attic installations.
  • Page 26 Innovative Hearth Products Installation Aurora™ 35/40/45 Direct-Vent Gas Fireplaces 900475-00, 08/2015 Vertical (Offset) Installation 1. Analyze the vent route and determine the number of vent sections and elbows required—See Effective Vent Length on Page 24 for more information. Plan the venting so that a joint does not occur in the ceiling or roof joists.
  • Page 27 Innovative Hearth Products Installation Aurora™ 35/40/45 Direct-Vent Gas Fireplaces 900475-00, 08/2015 8. Change vent direction of horizontal/inclined run—Install the SV4.5E45 and SV4.5E90 elbows in the same manner as the straight vent sections. See Vent elbows on Page 23 for more information. 9.
  • Page 28 Innovative Hearth Products Installation Aurora™ 35/40/45 Direct-Vent Gas Fireplaces 900475-00, 08/2015 Vertical Vent Figures/Tables NOTE: Secure Vent rigid vent pipe is shown in the figures; Secure Flex flexible vent pipe may also be used. ® ® NOTE: Rise per foot run ratios are acceptable all the way to level. For best results, maintain the horizontal/inclined run in a straight (no dips), slightly elevated plane of approximately 1/4”...
  • Page 29 Innovative Hearth Products Installation Aurora™ 35/40/45 Direct-Vent Gas Fireplaces 900475-00, 08/2015 Table 17 - Top Vent—Two 90° Elbows Table 18 - Rear Vent—Three Elbows Table 19 - Top Vent—Three Elbows When using Secure Flex , use ® Ceiling firestop/ ceiling firestop/ spacer SV4.5VF spacer SF4.5VF.
  • Page 30 Innovative Hearth Products Installation Aurora™ 35/40/45 Direct-Vent Gas Fireplaces 900475-00, 08/2015 Install the Horizontal Termination Vent System These instructions should be used as a guideline and do not supersede local codes in any way. Install venting according to local codes, these instructions, the current National Fuel Gas Code (ANSI-Z223.1) in the USA or the current standards of CAN/CGA-B149.1 in Canada.
  • Page 31 Innovative Hearth Products Installation Aurora™ 35/40/45 Direct-Vent Gas Fireplaces 900475-00, 08/2015 9. Change vent direction—At transition from or to a horizontal/inclined run, install SV4.5E45 or SV4.5E90 elbows in the same manner as the straight vent sections. The elbows feature a twist section to allow them to be routed about the center axis of their initial collar section to align with the required direction of the next vent run element.
  • Page 32 Innovative Hearth Products Installation Aurora™ 35/40/45 Direct-Vent Gas Fireplaces 900475-00, 08/2015 Figure 26 - Installing the Horizontal Termination To help minimize water infiltration it Typical is recommended that the Firestop/ Termination Spacer (SV4.5HF) be installed on Shown the exterior side of the wall. 10-1/2”...
  • Page 33 Innovative Hearth Products Installation Aurora™ 35/40/45 Direct-Vent Gas Fireplaces 900475-00, 08/2015 Table 20 - Venting Components Required for Various Exterior Wall Thicknesses, when using Typical Termination Kits Vent Components Required Exterior wall Thickness Termination Kit Only 6 to 9-1/4” (152 to 235 mm) Termination Kit and 6”...
  • Page 34 Innovative Hearth Products Installation Aurora™ 35/40/45 Direct-Vent Gas Fireplaces 900475-00, 08/2015 Table 23 - Top Vent—One 90° Elbow, Elbow Connection NOT at Fireplace H Maximum V Minimum feet meters feet meters 1.524 0.305 3.048 0.610 When using Secure Flex, use Firestop/Spacer SF4.5VF.
  • Page 35 Innovative Hearth Products Installation Aurora™ 35/40/45 Direct-Vent Gas Fireplaces 900475-00, 08/2015 Table 26 - Rear Vent—Three 90° Elbows H + H Maximum H Maximum V Minimum feet meters feet meters feet meters Wall firestop/spacer Wall Firestop/Spacer SV4.5HF ** 1.524 0.610 0.305 SV4.5HF** 3.048...
  • Page 36 Innovative Hearth Products Installation Aurora™ 35/40/45 Direct-Vent Gas Fireplaces 900475-00, 08/2015 Vertical or Horizontal Venting Using Secure Flex Kits and Components when Secure Flex kits are used in a rear flue, horizontal termination installation, at least 1 ft of vertical rise is required. ®...
  • Page 37: Complete The Field Wiring

    Innovative Hearth Products Installation Aurora™ 35/40/45 Direct-Vent Gas Fireplaces 900475-00, 08/2015 d. Slide the outer flexible vent over the adaptor collar. Ensure the flexible vent completely engages the adaptor collar 1-3/4” from the end, and that it is free from damage or tears. e.
  • Page 38: Connect The Gas Line

    Innovative Hearth Products Installation Aurora™ 35/40/45 Direct-Vent Gas Fireplaces 900475-00, 08/2015 Figure 31 - Wiring Diagram—Junction Box Figure 30 - Wiring Diagram—Electronic Gas Valves IPI Pilot Green Ground - Green Flame Sensor White Neutral - White Schematic Representation Only Spark Electrode 120 VAC - Black COLOR CODE: Black...
  • Page 39: Verify Proper Fireplace Operation

    Innovative Hearth Products Installation Aurora™ 35/40/45 Direct-Vent Gas Fireplaces 900475-00, 08/2015 NOTE: A sediment trap is recommended in the gas piping within the home to prevent moisture and debris in the line from damaging the valve. NOTE: Secure all joints tightly using appropriate tools and sealing compounds (ensure propane resistant compounds are used in propane applications).
  • Page 40 Innovative Hearth Products Installation Aurora™ 35/40/45 Direct-Vent Gas Fireplaces 900475-00, 08/2015 Figure 33 - Electronic Pilot Igniter Pilot Hood Flame Rod Remote Control System WARNING Fire hazard. Can cause severe injury or death. The receiver causes ignition of the appliance. The appliance can turn on suddenly.
  • Page 41 Innovative Hearth Products Installation Aurora™ 35/40/45 Direct-Vent Gas Fireplaces 900475-00, 08/2015 4. Install the three (3) AAA batteries in the transmitter battery bay, located on the base of the transmitter. 5. Push the ON button. The receiver will beep four (4) times to indicate that the transmitter’s command has been accepted and sets it to the particular code of that transmitter.
  • Page 42: Optional: Install The Firebox Liners

    Innovative Hearth Products Installation Aurora™ 35/40/45 Direct-Vent Gas Fireplaces 900475-00, 08/2015 Intermittent/standing pilot mode This fireplace can be switched from intermittent ignition to a standing pilot simply via remote control (Figure 34). To save energy, switch to intermittent mode. To have a standing pilot that will help startup in the winter by warming the flue and the glass, switch to standing pilot.
  • Page 43 Innovative Hearth Products Installation Aurora™ 35/40/45 Direct-Vent Gas Fireplaces 900475-00, 08/2015 If the air shutter opening is closed too far, sooting may develop. Sooting is indicated by black puffs developing at the tips of very long orange flames. Sooting results in black deposits forming on the logs, fireplace inside surfaces, and on exterior surfaces adjacent to the vent termination.
  • Page 44: Install The Hood

    Innovative Hearth Products Installation Aurora™ 35/40/45 Direct-Vent Gas Fireplaces 900475-00, 08/2015 Install the Hood NOTE: All models must have a hood installed prior to operation. 1. Install the hood by sliding it into the slots on the lower edge of the cabinet top. NOTE: To install the non-combustible finish material flush with the top of the hood, the hood must be installed before installing the finish material.
  • Page 45: Attach The Safety-In-Operation Warnings

    Innovative Hearth Products Installation Aurora™ 35/40/45 Direct-Vent Gas Fireplaces 900475-00, 08/2015 INSTALLER INSTRUCTIONS - ATTACHING SAFETY IN OPERATION WARNINGS It is the installer’s responsibility to ensure these warnings are properly affixed during installation. These warning labels are a critical step in informing consumers of safe operation of this appliance. ATTACHING SAFETY IN OPERATION APPOSITION DES MISES EN GARDE RELATIVES COLOCACIóN DE ADVERTENCIAS DE SEGURIDAD...
  • Page 46: Installation Accessories

    Innovative Hearth Products Installation Aurora™ 35/40/45 Direct-Vent Gas Fireplaces 900475-00, 08/2015 INSTALLATION ACCESSORIES Table 30 - Listed Secure Vent Components ® Horizontal Square Termination H1968 SV4.5HT-2 with Firestop/Spacer (H2246), H6183 SV4.5HF5 Firestop Spacer, 5”, rigid and Adaptor (74L61) Vertical Termination Cap, High H2152 SV4.5CGV-1 H6184...
  • Page 47 Innovative Hearth Products Installation Aurora™ 35/40/45 Direct-Vent Gas Fireplaces 900475-00, 08/2015 Table 31 - Listed Secure Flex Components ® Catalog Catalog Model Description Model Description Number Number Vertical Termination for flex (flat to 6/12) with flex adaptor, section of rigid vent, roof support 56L74 SFVT30 18 ft (5.49 m)* compressed flex (see...
  • Page 48: Gas Conversion Kits

    Innovative Hearth Products Installation Aurora™ 35/40/45 Direct-Vent Gas Fireplaces 900475-00, 08/2015 GAS CONVERSION kITS WARNING This conversion kit shall be installed by a qualified service agency in accordance with the manufacturer’s instructions and all applicable codes and requirements of the authority having jurisdiction. If the information in these instructions is not followed exactly, a fire, explosion, or the production of carbon monoxide may result;...
  • Page 49 Innovative Hearth Products Installation Aurora™ 35/40/45 Direct-Vent Gas Fireplaces 900475-00, 08/2015 Installing Gas Conversion kits WARNING The gas supply shall be shut OFF prior to disconnecting the electrical power, before proceeding with the conversion. AVERTISSEMENT Avant d’effecteur la conversion, coupez d’abord l’alimentation en gaz, ensuite, coupez l’alimentation electrique.
  • Page 50 Innovative Hearth Products Installation Aurora™ 35/40/45 Direct-Vent Gas Fireplaces 900475-00, 08/2015 Figure 41 - Pilot Figure 42 - Orifice Clip 12. Use pipe joint compound or Teflon tape on all pipe fittings before installing. ® NOTE: Ensure propane resistant compounds are used in propane applications, do not use pipe joint compounds on flare fittings.
  • Page 51: Operation

    Innovative Hearth Products Operation Aurora™ 35/40/45 Direct-Vent Gas Fireplaces 900475-00, 08/2015 OPERATION WARNING Young children should be carefully supervised when they are in the same room as the appliance. Toddlers, young children and others may be susceptible to accidental contact burns. A physical barrier is recommended if there are at-risk individuals in the house.
  • Page 52 Innovative Hearth Products Operation Aurora™ 35/40/45 Direct-Vent Gas Fireplaces 900475-00, 08/2015 HOMEOWNER’S INSTRUCTIONS - ATTACHING SAFETY IN OPERATION WARNINGS ATTACHING SAFETY IN OPERATION WARN- APPOSITION DES MISES EN GARDE RELATIVES à COLOCACIóN DE ADVERTENCIAS DE SEGURIDAD INGS LA SÉCURITÉ D’UTILISATION EN OPERACIóN Your fireplace has been furnished with safety instruc- Votre foyer a été...
  • Page 53 Innovative Hearth Products Operation Aurora™ 35/40/45 Direct-Vent Gas Fireplaces 900475-00, 08/2015 burn-in Period The first few times this fireplace is operated, there will be an odor from the curing of paint and the burning off of the lubricants used in the manufacturing process. Depending on usage, the burn-in period may take a few hours or a few days.
  • Page 54 Innovative Hearth Products Operation Aurora™ 35/40/45 Direct-Vent Gas Fireplaces 900475-00, 08/2015 Installing the Backup Batteries With a battery backup, electronic fireplaces can automatically switch to battery power. In the event of a power outage, this allows ON/OFF operation (without blower functionality). Install new batteries before every burn season. 1.
  • Page 55 Innovative Hearth Products Operation Aurora™ 35/40/45 Direct-Vent Gas Fireplaces 900475-00, 08/2015 WARNING • Turn OFF all gas and electricity to the appliance before installing the volcanic stone, embers, and logs. • Do NOT install the logs until the appliance has been competely installed, the gas line connected and tested for leaks, and the initial burner operation has been confirmed.
  • Page 56 Innovative Hearth Products Operation Aurora™ 35/40/45 Direct-Vent Gas Fireplaces 900475-00, 08/2015 Installing the Aurora™ Series 35” logs The logs have notches/tabs to assist proper positioning. Upper logs rest on lower logs via notches/tabs. Proper log placement is critical to prevent sooting. Place the logs in the gaps between flame peaks, so they do not impinge the flames.
  • Page 57 Innovative Hearth Products Operation Aurora™ 35/40/45 Direct-Vent Gas Fireplaces 900475-00, 08/2015 Installing the Aurora™ Series 40” and 45” logs The logs have notches/tabs to assist proper positioning. Upper logs rest on lower logs via notches/tabs. Proper log placement is critical to prevent sooting. Place the logs in the gaps between flame peaks, so they do not impinge the flames.
  • Page 58 Innovative Hearth Products Operation Aurora™ 35/40/45 Direct-Vent Gas Fireplaces 900475-00, 08/2015 Installing and removing the glass door WARNING • Do not attempt to substitute the materials used on these doors, or replace cracked or broken glass. • Handle this glass with extreme care! Glass is susceptible to damage—Do not scratch or handle roughly while reinstalling the glass door frame.
  • Page 59 Innovative Hearth Products Operation Aurora™ 35/40/45 Direct-Vent Gas Fireplaces 900475-00, 08/2015 Installing the glass door 1. Visually inspect the gasket on the backside of the glass door. NOTE: The gasket surface must be clean, free of irregularities, and seated firmly. Ensure it is properly located. Make sure the bead is not rolled into the channel at the top of the door, but remains flat against the top of the glass.
  • Page 60: Maintenance

    Innovative Hearth Products Operation Aurora™ 35/40/45 Direct-Vent Gas Fireplaces 900475-00, 08/2015 MAINTENANCE Refer to the Maintenance Schedule on Page 62 for maintenance tasks, procedures, frequency, and a listing of by whom the tasks should be performed. Always verify proper fireplace operation after servicing. WARNING Turn OFF gas and electrical power to the fireplace and allow it to cool before cleaning or servicing the appliance.
  • Page 61 Innovative Hearth Products Operation Aurora™ 35/40/45 Direct-Vent Gas Fireplaces 900475-00, 08/2015 Inspecting the glass gasket Visually inspect the gasket on the backside of the glass door. The gasket surface must be clean, free of irregularities, and seated firmly. Cleaning the control compartment Keep the control compartment clean by vacuuming or brushing it out at least twice a year.
  • Page 62 Innovative Hearth Products Operation Aurora™ 35/40/45 Direct-Vent Gas Fireplaces 900475-00, 08/2015 MAINTENTENANCE SCHEDULE See the tables below for detailed information about required maintenance, both regular and annual. Table 36 - Maintenance Performed Annually—Before the Burning Season Maintenance Task Performed by Procedure Inspecting/Cleaning Burner, Logs, and Qualified Service Technician...
  • Page 63: Accessory Components

    Innovative Hearth Products Operation Aurora™ 35/40/45 Direct-Vent Gas Fireplaces 900475-00, 08/2015 ACCESSORY COMPONENTS Touch-Up Paint kits Repair minor scratches and discoloration of the fireplace black painted surfaces with the touch-up paint kits. Table 38 - Touch-Up Paint Kit Catalog No. Description F1881 Firebox interior touch-up paint...
  • Page 64: Lighting Instructions

    Innovative Hearth Products Operation Aurora™ 35/40/45 Direct-Vent Gas Fireplaces 900475-00, 08/2015 LIGHTING INSTRUCTIONS - ENGLISH FOR YOUR SAFETY READ BEFORE OPERATING WARNING: If you do not follow these instructions exactly, a fire or explosion may result causing property damage, personal injury or loss of life.
  • Page 65 Innovative Hearth Products Operation Aurora™ 35/40/45 Direct-Vent Gas Fireplaces 900475-00, 08/2015 LIGHTING INSTRUCTIONS - FRENCH POUR PLUS DE SÉCURITÉ LIRE AVANT DE METTRE EN MARCHE AVERTISSEMENT. Quiconque ne respecte pas à la lettre les instructions dans la présente notice risque de déclencher un incendie ou une explosion entraînant des dommages, des blessures ou la mort.
  • Page 66: Troubleshooting

    Innovative Hearth Products Operation Aurora™ 35/40/45 Direct-Vent Gas Fireplaces 900475-00, 08/2015 TROUbLESHOOTING Before troubleshooting, ensure that the fireplace main line gas shutoff valve and the wall switch are in the ON position. The following troubleshoots the fireplace only to an elementary level. For detailed remote and ignition system troubleshooting, refer to the instructions provided with the remote.
  • Page 67: Replacement Parts

    Innovative Hearth Products Operation Aurora™ 35/40/45 Direct-Vent Gas Fireplaces 900475-00, 08/2015 REPLACEMENT PARTS Table 44 - Installer Replacement Parts 35” Models 40” Models 45” Models Description Catalog Number Catalog Number Catalog Number Touch-Up Paint (Exterior) F1882 F1882 F1882 Blower Assembly 80L84 80L84 80L84...
  • Page 68 Innovative Hearth Products Operation Aurora™ 35/40/45 Direct-Vent Gas Fireplaces 900475-00, 08/2015 Figure 57 - Replacement Parts WARNING Failure to position the parts in accordance with these diagrams or failure to use only parts specifically approved with this appliance may result in property damage or personal injury. AVERTISSEMENT Risque de dommages ou de blessures si les pièces ne sont pas installées conformément à...
  • Page 69: Year Limited Warranty

    THE WARRANTY Innovative Hearth Products ("IHP") 20 Year Limited Warranty warrants your Comfort Flame™ Brand gas fireplace or insert ("Product") to be free from defects in materi- als and workmanship at the time of manufacture. The Product body and firebox carry the 20 Year Limited Warranty. Ceramic glass carries the 20 Year Limited Warranty against thermal breakage only.
  • Page 70 Innovative Hearth Products Installation and Operation Instructions Aurora™ 35/40/45 Direct-Vent Gas Fireplaces 900475-00, 08/2015 Contact an IHP dealer to obtain any of these parts. Please contact IHP for the phone number of your nearest IHP dealer. ComfortFlame.us.com Record the following important information about your fireplace: Fireplace model number Fireplace serial number Date fireplace was Installed...
