Website: www.hootoo.com
NORTH AMERICA
E-mail:
support.ca@hootoo.com(Canada)
support@hootoo.com (United States)
Tel:
1-888-456-8468 (Monday-Friday: 9:00 – 17:00 PST)
Address: 2228 Junction Ave, San Jose, CA 95131
EUROPEAN UNION
E-mail:
support.uk@hootoo.com (United Kingdom)
support.de@hootoo.com (Germany)
support.fr@hootoo.com (France)
support.es@hootoo.com (Spain)
support.it@hootoo.com (Italy)
EU Importer: ZBT International Trading GmbH, Lederstr 21a,
22525 Hamburg, Deutschland
ASIA PACIFIC
E-mail: support.jp@hootoo.com (Japan)
IP CAMERA
ADVANCED USER MANUAL
For Windows
Model: HT-IP211HDP
Advertisement
Table of Contents
Related Manuals for Hootoo HT-IP211HDP
Summary of Contents for Hootoo HT-IP211HDP
-
Page 1: For Windows
IP CAMERA ADVANCED USER MANUAL For Windows Model: HT-IP211HDP Website: www.hootoo.com NORTH AMERICA E-mail: support.ca@hootoo.com(Canada) support@hootoo.com (United States) Tel: 1-888-456-8468 (Monday-Friday: 9:00 – 17:00 PST) Address: 2228 Junction Ave, San Jose, CA 95131 EUROPEAN UNION E-mail: support.uk@hootoo.com (United Kingdom) support.de@hootoo.com (Germany) support.fr@hootoo.com (France) -
Page 2: Table Of Contents
3.1.4 lmage color adjustment - - - - - - - - - - - - - - - - - - - - - - - 19 7.1 HooToo Warranty - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 44 3.1.5 Other adjustment - - - - - - - - - - - - - - - - - - - - - - - - - - - - 19... -
Page 3: Overview
Please go through the detailed instructions in the guide to help you setup the camera correctly. If you need any further assistance, please contact Microphone our customer support team or email us at support@hootoo.com. Reset Button 1.3 Package Contents Speaker... -
Page 4: Access The Ip Camera
Installation CD, copy and paste it to your PC. Note: · You can download the IPCSearch software from www.hootoo.com · For FireFox or Chrome browser, in order to view live video, please download and install “VLC media player” first. Find VLC install file in camera CD or download here: http://www.videolan.org/vlc/index.html... - Page 5 5) Select the IP address and double click on it. This will lead you to the 6) Then login with default username and password. login page of the HT-IP211HDP web setting page. Click “Download Username: admin Player” to install camera plug-in for future use:...
- Page 6 7) HTTPS (Hypertext Transfer Protocol over Secure Socket Layer) is a safe 10) For Firefox, you can add the trusted site as the following way: way to access your camera. The data transferred on the Internet will Tools --- Options ---- Advanced --- View Certificates --- Servers be encrypted.
-
Page 7: Using The Vlc Player
Go to Add Exception panel. Note: We recommend selecting “Broadcast Mode” when locating your IP address for more fluent picture Trouble Shoot Enter the camera’s url such as If you fail to find the camera’s IP address or fail to login after clicking the https://192.168.8.129:443 IP address, try the following steps: ·... - Page 8 Sometimes you may need to enter the user name and password again. Click OK and you can see the real-time preview. Figure 2.15 NOTE: If you changed the username or password, you need to restart the camera, or else the new username and password will not take effect when you enter the authentication in the VLC.
-
Page 9: Wireless Mode
“Select” 7) Double click on the new IP address. This will lead you to the login page of the HT-IP211HDP web setting page in your default browser. 8) Use the default username and password “admin” to login... -
Page 10: Surveillance Software Gui
3. Surveillance Software GUI Please setup the camera successfully before moving further. 3.1 Home Page At home page, you can view camera live video, adjust the viewing area, Note: make records, take snapshots, and enable two-way audio, etc. · When you fill in Wi-Fi password, please note that there should be no Note: special characters ( such as “, #, &, +, ;, \, [, |) ·... - Page 11 3.1.2 Snapshot Trouble Shooting: To take a snapshot and save it to your PC, please click the snapshot If you are not able to save the recording path, please clear your IE button (located beside the record button) and then select the file path. browser data and reset the IE browser.
-
Page 12: Other Adjustment
Please pick the No. first and then move the camera to the position you · Flip turn the camera image vertically 180 degrees prefer and click Set button. Please set the 8 preset positions through this method. · Mirrors turn the camera image horizontally 180 degrees Once it is finished, to move the camera to your preferred position, please ·... -
Page 13: Network
3.2.1.4 PTZ In this page, you can change image property (flip over or mirror position), assign different cruise position, adjust camera moving speed, set track plan, etc. Please decrease Input Gain and Output Volume if it is noisy and also make sure the camera is not too close to your PC or phone. - Page 14 It is recommended that you use the subnet mask, gateway and DNS server from your locally attached PC. If you don’t know the subnet mask, gateway and DNS server, you can check your computer’s local area connection as follows: Control Panel - Network Connections - Local Area Connections - Choose Support - Details.
- Page 15 What is Port forwarding? If you don’t know the DNS server, you can use the same settings as the Default Gateway. Port forwarding allows for outside connections to access a specific device on your network from anywhere in the world. Every router 3.2.2.2 DDNS automatically blocks any incoming connections for safety purposes.
- Page 16 Send to: You can have up to 3 receiving email addresses simply entering this UID code when you do “Add Camera” on smart phone app or on HooToo IPCamClient software in another Windows PC. From As: test the alert send out email account available or not. (Click “Test”...
-
Page 17: Event
3.2.2.5 FTP FTP server is used to upload camera record clips or snapshots captured by motion detection. Test after all FTP parameters filled in. Server: please fill in your own FTP account’s address. Port: 21 Trouble Shooting: User: your FTP server’s user The camera works at home but cannot be accessed from anywhere else Password: your FTP server’s password outside. -
Page 18: System
To activate motion detection: 1. Click on ‘Enable’ 2. Select red grids by clicking or dragging you mouse 3. The motion detection can be only triggered by areas marked by red square. 4. Adjust the sensibility: Very High / High / Normal / Low 3.2.3.2 Occlusion Detection 3.3 System 3.3.1 User... -
Page 19: Time Setting
Note: If the time shows on the camera is not correct, please pick the Manual Mode and then change the Date and Time manually and also make sure you have picked the correct Time Zone. Note: For the security concern, please change the camera’s password If it still does not work, please clear the browser data to have a try. -
Page 20: Device Info
Note: Please save this config_backup.bin file to a proper path for future use. 3.3.5 System Log Restore: select the backup file and click apply to restore. In this log page, you can search all operation record of this camera. Upgrade: select a new firmware to upgrade, and click “Apply” to continue. N ot e : Pl ease m a k e s u re th e p ow er c on n e c t ion is OK wh ile u pda t i n g the f i rmw a re . -
Page 21: Remote Viewing On A Windows Pc
4. Remote Viewing on a Windows PC 4) Select your camera, click “Play”, and then you can view the live video. 1) Please download the P2P software “IPCamClient” from CD or www.hootoo.com and then install it on a windows PC. 2) Open it, click “Add” Note: You are able to add 9 cameras at most to this software. -
Page 22: How To Set Up The Remote View For The Camera
The other one is used for the P2P software and required when you try to sign in P2P software such as IPCamClient and MyCam Pro. You can change this password from the below page. 5.2 How to set up the remote view for the camera? Since the camera support P2P, you do not need to set up the DDNS connection and port forwarding like the MJPEG camera. -
Page 23: What You Can Do If Camera Could Not Be Searched From All The Software After You Connect It To Router Via Network Cable
For the wireless connection, you are suggested to download IPCSearch for your Windows PC and then open the camera via the browser. http://www.hootoo.com/media/downloads/IPCSearch-Windows PC Search Software.zip Then you will be able to search the Wi-Fi SSID from setting page like the attached picture. -
Page 24: Specification
IR-led YES IR distance 8-10M This HooToo IP Camera is covered with 12 months limited product warranty by Hootoo from the date of its original purchase. If it becomes LENS defective during its warranty period, please contact HooToo or your Lens 3.6MM... -
Page 25: Support Contact
6 month of warranty cover, making a total of 18 months warranty cover from the date of original purchase. · Please do not return the product without contacting HooToo first · We can only provide warranty cover for products sold by HooToo authorized distributor 7.2 Support Contact For any inquiries or comment concerning our products, please contact us via below methods.
