INSTRUCTION MANUAL
8.4"/ 10.4" TFT LCD DIGITAL MONITOR
CM-840D/CM-1040D
Thank you for choosing this product.
Please read this instruction manual carefully before
operating this product.
Printed in KOREA
DIGITAL TFT LCD COLOR MONITOR
POWER
TV/AV
CH
RECALL
SLEEP
MENU
VOL
VOL
MUTE
AUTO
PIC
CH
SETUP
SOUND
1
2
3
4
5
6
7
8
9
0
MODE MENU DOWN
UP
POWER
A.MEMO.
CH.SET
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Camos CM-840D
Summary of Contents for Camos CM-840D
-
Page 1: Instruction Manual
INSTRUCTION MANUAL 8.4"/ 10.4" TFT LCD DIGITAL MONITOR CM-840D/CM-1040D DIGITAL TFT LCD COLOR MONITOR Thank you for choosing this product. Please read this instruction manual carefully before operating this product. POWER TV/AV RECALL SLEEP MENU MUTE AUTO PICTURE SETUP SOUND... -
Page 2: Table Of Contents
Contents 1. Safety Rules Please read the Safety Rules carefully before using this product. Following of the safety rules prevents users from any damage “ ” related with the misuse of this product. It is very important that users follow these safety rules. We state Caution and Warning to clarify any potential for damage “... - Page 3 Do not use in bathtub. Do not pull the plug with wet hands. This may cause electric shock. Do not use unapproved power voltage. Caution This may cause fire or electric shock. Do not use unapproved Cigarette Lighter Adapter. This may cause fire ,electric shock and/or malfunction. Do not put the product in a place where sudden temperature increase occurs such as the vehicle’s dashboard.
- Page 4 Unplug the product and remove cords when moving. --- It may damage cords and cause fire and/or electric shock. The car engine should be running when you use the product in a car. If you find any strange occurrences or malfunction in the product or any foreign Without the engine running, you may have excessive discharge of the car battery.
-
Page 5: Before Use
2. Before Use Precautions (when you use the product in a car) To safely use the product, please read the user’s manual carefully before use. =The driver should not use the product while he/she is driving. =Connect all lines as directed in the product connection map in the manual. =Quality of pictures on screen may vary depending on the radio field strength in different locations. -
Page 6: Special Features Of The Product
4. Terms of part 3. Special Features of the Product Applied high resolution and low reflection DIGITAL TFT LCD (800 x 600) ① MODE AV/S-VIDEO/PC(RGB) selection function. Press the mode DIGITAL TFT LCD COLOR MONITOR button to be appeared source select OSD box and press All electronic control functions the DOWN, UP button or mode button repeatedly th press the menu button or wait 3 second to select highlighted source. -
Page 7: Remote Control
5. Remote Control ① ② ① ⑫ POWER Power ON/OFF Key SOUND Sound selection button ④ ③ TV/AV POWER ② ⑬ DSUB analog, external video, s-video TV/AV The key does not use (only TV MODE) ⑥ ③ ⑭ The key does not use (only TV MODE) ⑤... -
Page 8: Functions
③ SHARPNESS Adjust the sharpness of video image. S-VIDEO ④ COLOR TINT Change the richness of color. ⑤ COLOR TONE Change the tone of color. CM-840D/ 1040D CM-840D/ 1040D ⑥ SYSTEM Change broadcast system NTSC, PAL, AUTO ※ Adjust it with CH ( ▲▼) - Page 9 SETUP(SETUP) SOUND(SOUND) ※ ▶), With (VOL go to SUB MENU. After adjusting in SUB MENU, LANGUAGE ▶ ENGLISH ※ With (VOL ▶), go to SUB MENU. After adjusting in SUB MENU, press MENU to exit. MUTE press MENU to exit. OSD TIME VOLUME TRANSLUCENT...
- Page 10 PC (ANALOG) COLOR PICTURE The tone of color can be changed from red-dish white to bluish white. ※ With (VOL ▶), go to SUB MENU. After adjusting in SUB MENU, BRIGHTNESS The individual color components are also user customizable. press MENU to exit. CONTRAST ※...
- Page 11 Displays present status and volume level. RECALL DISPLAY MODES For the display modes listed below, the screen image has been optimized during manufacture. Selects DYNAMIC, NORMAL, MILD, USER for PICTURE AUTO PIC External DSUB analog, video, s-video TV/AV Horizontal Vertical Pixel Clock Sync Polarity Mode...
-
Page 12: Connections
7. Connections OSD MESSAGE 1. Choose a location where you install the Monitor. OUT OF RANGE ① The screen shows this when signal is out of range Clean the place for the Stand with cleanser and remove the Safeguard tape. And then attach it exactly where you want. 2. -
Page 13: Changing Remote Control Battery
8. Changing Remote Control Battery CM-840D/1040D 1. Slide and open the battery cover. 2. Insert new battery and ensure that the polarities are correct when inserting. (Not Supplied) (Not Supplied) DVDP 3. Slide and close the battery cover. Cigarette Lighter Adaptor... -
Page 14: Specifications
9. Specifications CM-840D(8.4”) SPECIFICATION SPECIFICATION I T E M NTSC I T E M NTSC Horizontal 15.73KHz 15.63KHz Frequency Size 21.336 cm (8.4 Inch) Vertical 60 Hz 50 Hz Display format 480,000Pixels 800(W) x 600(H) Dots Analog RGB 0.7Vp-p Video... - Page 15 CM-1040D(10.4”) SPECIFICATION SPECIFICATION I T E M NTSC I T E M NTSC Horizontal 15.73KHz 15.63KHz Frequency Size 26.416 cm (10.4 Inch) Vertical 60 Hz 50 Hz Display format 480,000 Pixels 800(W) x 600(H) Dots Analog RGB 0.7Vp-p Video Input signal Dot pitch 0.264(W) x 0.264(H) mm Composite VIDEO, S-VIDEO (75 ohm 1Vp-p)
- Page 16 MEMO MEMO...
