- Page 1 OWNER’S MANUAL 21" & 27" BUFFER THE ANSWER Powered by the EPA/Carb certified Kawasaki 603cc Engine 201 COMMERCE DRIVE • MONTGOMERYVILLE, PA 18936 215-393-4700 • 800-331-1423 • FAX 215-393-4800...
-
Page 2: Important Safety Instructions
PG. 2 THE ANSWER IMPORTANT SAFETY INSTRUCTIONS Always vent an over-full bottle using the tank’s bleed valve, out of doors away from all closed READ and UNDERSTAND all instructions and places and away from any fire or flame producing warnings before operating this machine! device. -
Page 3: Starting The Engine
THE ANSWER PG. 3 D. Connecting the high pressure hose to the WARNING LPG Tank: Make sure the couplers are in line and screwed Do not use “T” handle when attempting to tilt together hand tight. If this is not done properly, back machine for service or cleaning. -
Page 4: Operation
PG. 4 THE ANSWER • Propane tanks should be removed & cleaning the unit, check for possible loose nuts stored in a protected off site area. and bolts. B. Engine maintenance meter III. OPERATION This multi-function meter acts as a preventive Provide and use ear protection during maintenance tool, which benefits you with operation. - Page 5 The pad pressure may be adjusted by moving temperature as follows: the wheels: -20˚C -10˚C 0˚C 10˚C 20˚C 30˚C 40˚C • Forward to reduce weight on the buffer pad SAE40 SAE30 • Backward to increase the weight SAE10W-30/SAE10W-40 This adjustment may be required to adjust to...
- Page 6 PG. 6 THE ANSWER Engine Oil Capacity CAUTION! FH381V 1.5 L (1.6 US qt.) when oil filter is not removed Before removing the oil filter, place a FH500V 1.7 L (1.8 US qt.) when oil filter is removed suitable pan under filter connection. FH541V 1.7 L (1.8 US qt.) when oil filter is removed •...
- Page 7 THE ANSWER PG. 7 KAWASAKI ENGINE MAINTENANCE SCHEDULE INTERVAL MAINTENANCE Daily First 8 hr. Every 25 Hr. Every 50 hr. Every 100 hr. Every 200 hr. Every 300 hr. Check and add engine oil Check for loose or lost nuts and screws Check for fuel and oil leakage Check battery electrolyte level Check or clean air intake screen...
- Page 8 PG. 8 THE ANSWER PARTS LIST FOR 21" BUFFER BODY ASSEMBLY PART # DESCRIPTION PART # PAD RETAINER (CENTER LOK II) 201-LOK PAD DRIVE HUB 011-6-2740 WASHER 011-6-2770 PAD DRIVER 011-7-2175 PAD DRIVER SUPPORT RING 011-6-2750 SPINDLE ASSEMBLY (WITH HUB & BEARINGS)
- Page 9 THE ANSWER PG. 9 PARTS LIST FOR 27" BUFFER BODY ASSEMBLY PART # DESCRIPTION PART # PAD RETAINER (CENTER LOK II) 201-LOK PAD DRIVE HUB 011-6-2740 WASHER 011-6-2770 PAD DRIVER WITH MIGHTY LOK 011-6-2765 PAD DRIVER SUPPORT RING 011-6-2750 SPINDLE ASSEMBLY (WITH HUB & BEARINGS)
- Page 10 PG. 10 THE ANSWER...
- Page 11 THE ANSWER PG. 11 PARTS LIST FOR BUFFER FUEL SYSTEM PART # DESCRIPTION PART # QUICK COUPLER 152-700 LPG HOSE 14" 267-P5561-14 LPG HOSE 20" 267-P5561-0410 FUEL LOK-OUT (VACUUM) 152-300 90˚ FITTING 177-116B04 VACUUM HOSE FITTING 166-62029 1 1/2" NIPPLE...
- Page 12 PG. 12 THE ANSWER KAWASAKI 603cc ENGINE PART # DESCRIPTION PART # Foam Hat Filter 186-271964 Debris Screen 309-18540 Foam Hat Seal 175-7.75*9.25*1 Oil Pressure Switch 152-N3-0082 Oil Filter 309-49065-7007 Oil Drain Valve 312-504-0185 1 / 4 x 1 1 / 4 Key 199-NHNT-SE UND Crank Pulley 011-6-2780...
- Page 13 THE ANSWER PG. 13 NOTES...
- Page 14 PG. 14 THE ANSWER NOTES...
- Page 15 THE ANSWER PG. 15 NOTES...
- Page 16 You have purchased a quality product. Each of its components has been tested and approved for use by Aztec Products, Inc. It is unlikely that you will ever have a warranty claim if you properly maintain your machine.
