Features of your new air conditioner Contents Cool Summer Offer On those hot sweltering summer days and long restless Safety precautions ................. 3 nights, there is no better escape from the heat than the Checking before use ..............10 cool comforts of home. Your new air conditioner brings an Checking the name of the parts .......... -
Page 3: Safety Precautions
If you have any questions, call your nearest contact center or find help and information online at www.samsung.com . Important safety symbols and precautions: Hazards or unsafe practices that may result in severe WARNING personal injury or death. - Page 4 Safety precautions Do not install this appliance near a heater, inflammable material. Do not install this appliance in a humid, oily or dusty location, in a location exposed to direct sunlight and water (rain drops). Do not install this appliance in a location where gas may leak. ...
- Page 5 FOR POWER SUPPLY WARNING When the circuit breaker is damaged, contact your nearest service center. Do not pull or excessively bend the power line. Do not twist or tie the power line. Do not hook the power line over a metal object, place a heavy object on the power line, insert the power line between objects, or push the power line into the space behind the appliance.
- Page 6 Safety precautions Do not touch the circuit breaker with wet hands. This may result in electric shock. Do not turn the air conditioner off with the circuit breaker while it is operating. Turning the air conditioner off and then on again with the circuit breaker may cause a spark and result in electric shock or fire.
- Page 7 FOR USING WARNING Do not place an object near the outdoor unit that allows children to climb onto the machine. This may result in children seriously injuring themselves. Do not use this air conditioner for long periods of time in badly ventilated locations or near infirm people.
- Page 8 Safety precautions Do not stand on top of the appliance or place objects (such as laundry, lighted candles, lighted cigarettes, dishes, chemicals, metal objects, etc.) on the appliance. This may result in electric shock, fire, problems with the product, or injury. Do not operate the appliance with wet hands.
- Page 9 WARNING FOR CLEANING Do not clean the appliance by spraying water directly onto it. Do not use benzene, thinner or alcohol to clean the appliance. This may result in discoloration, deformation, damage, electric shock or fire. Before cleaning or performing maintenance, cut-off the power supply and wait until the fan stops.
-
Page 10: Checking Before Use
Checking before use Operation ranges The table below indicates the temperature and humidity ranges the air conditioner can be operated within. Refer to the table for efficient use. Mode Indoor temperature Outdoor temperature Indoor humidity Cooling 16˚C~32˚C -10˚C~46˚C Relative humidity 80% or less Heating 27˚C or less -15˚C~24˚C... -
Page 11: Checking The Name Of The Parts
Checking the name of the parts Your air conditioner may slightly look di erent from illustration shown above depending on your model. Main parts Humidity Room sensor temperature sensor Air intake Air intake Full HD lter(under the panel) Full HD lter(under the panel) Wi-Fi module Air ow blade (left and right) -
Page 12: Checking The Remote Controller
Checking the remote controller • Point the remote controller towards the remote controller receiver of the indoor unit. • W hen you properly press the button on the remote controller, you will hear beep sound from the indoor unit and a transmit indicator( ) appears on the remote controller display. Remote controller buttons Before using the functions of the remote controller, you should set the current time. (Refer to p.18) Remote controller display Power Turn on/off the air conditioner. Mode Set the SPi function on/off. Set one of the 5 operating modes (see pages 14~16 for instructions). Smart Saver Quiet Less energy usage makes your space Reduce noise generated from an indoor unit cool between the temperature range of during operation. 24°C~30°C. Turbo Air swing Operate in auto fan speed to cool quickly. Activate/Deactivate air flow blade movement automatically up and down. Temp + - Increase/Decrease the temperature by 1˚C. -
Page 13: Remote Controller Display
Remote controller display Operation mode Quiet indicator Turbo indicator indicator Low battery indicator SPi indicator Smart Saver indicator Transmit indicator d'light Cool indicator Air swing indicator F indicator Fan speed indicator Set temperature indicator Auto (Turbo) On Timer indicator Off Timer indicator Medium indicator Time indicator... -
Page 14: Basic Function
Basic function Basic operation is an operation mode that can be selected by pressing the Mode button. Auto In Auto mode, the air conditioner will automatically set the temperature and fan speed depending on the room temperature detected by the room temperature. • I f using a multi system, in Auto operation, the system selects a temperature setting and an appropriate operation mode (COOL or HEAT) based on the room temperature at the start of the operation. - Page 15 Press the button to turn on the air conditioner. Press the button to set the operating mode. • Each time you press the Mode button, the mode will change in order of Auto, Cool, Dry, Fan and Heat. Press the button to set the desired fan speed. Auto (Auto) Cool...
-
Page 16: Adjusting The Air Flow Direction
Adjusting the air fl ow direction Air fl ow can be directed to your desired position. Vertical air fl ow Air fl ow blades move up and down. Press the Air swing Press the button on the remote controller. Air swing indicator will be on the remote controller display and air fl ow blades move ... -
Page 17: Mode
mode Before using good' sleep mode, set the current time.(For setting current time, refer to the page 18.) For a comfortable sleep, the air conditioner will operate it Fall asleep Sound sleep Wake up from mode. When the air conditioner is on and in cool/heat mode 1. -
Page 18: Setting The Current Time
Setting the Current time Before using the functions of the air-conditioner, set the current time. 1. Press 2 F button F indicator appears on the remote controller display. 2. Press Time Set button to set the current time A M or PM indicator will blink and you can set the time by pressing Temp hr. + or – ... - Page 19 3. Press the Set/Cancel button to active it. Setting Off timer On timer indicator stops blinking and reserved time will be displayed for 3 seconds. If you don’t press Set/Cancel button within 10 seconds after selecting the time the ...
-
Page 20: Using The Smart Saver Function
Using the Smart Saver function This function will set the temperature range limit to help you save energy while the air conditioner is operating in Cool mode. Press the Smart Saver button on the remote controller while the air conditioner is Press the operating in Cool mode. -
Page 21: Using The Auto Clean Function
Using the Auto Clean function Auto clean function will prevent mold from growing by eliminating the moisture inside of the indoor unit. Your indoor unit evaporates the moisture inside of the unit. Activate this function to provide you with more clean and healthier air. Press the Auto Clean button. -
Page 22: Using The Quiet Function
Using the Quiet function You can reduce the noise generated from an indoor unit. Press the Quiet button on the remote controller while the air conditioner is operating Press the in Cool/Heat mode. Quiet indicator appears on the remote controller display. ... -
Page 23: Cleaning The Air Conditioner
Cleaning the air conditioner • Make sure the power is turned off and unplugged from the wall socket when cleaning the air conditioner. CAUTION Cleaning the indoor unit Wipe the surface of the unit with a slightly damp micro fiber cloth ... - Page 24 Cleaning the air conditioner Removing the Full HD fi lter Grab the handle and lift it up. Then, pull the Full HD fi lter towards you and slide it down. Full HD fi lter Cleaning the Full HD fi lter Washable foam based Full HD fi lter captures large particles from the air.
-
Page 25: Maintaining The Air Conditioner
Maintaining the air conditioner If the air conditioner will not be used for an extended period of time, dry the air conditioner to maintain it in best condition. 1. Dry the air conditioner thoroughly by operating in Fan mode for 3 to 4 hours and cut-off the power supply. -
Page 26: Troubleshooting
Troubleshooting Refer to the following chart if the air conditioner operates abnormally. This may save time and unnecessary expenses. PROBLEM SOLUTION The air • Check power status and then operate the air conditioner conditioner does again. not work at all. • P lug in or switch on the circuit breaker and then operate the air conditioner again. • C heck if you have set the Off Timer. Operate the air conditioner again by pressing the Power button. -
Page 27: During Operation
PROBLEM SOLUTION Air flow • C heck if you have selected mode. In these adjustment is not modes, and you cannot adjust the air flow direction. working. (If the good’ sleep mode is operating in Heat mode, you can adjust the air flow direction) Fan speed • C heck if you have selected Auto/Dry/Turbo/ adjustment is not /d'light Cool mode. In these mode, fan speed is set to Auto working. and you cannot adjust the fan speed. Remote • Check if your batteries are depleted. controller is not • Make sure nothing is blocking your remote controller working. sensor. • C heck that there are strong lighting apparatus near the air conditioner. Strong light which comes from fluorescent bulbs or neon signs may interrupt the electric waves. - Page 28 Troubleshooting PROBLEM SOLUTION Noise is • D epending on the status of the air conditioner usage, noise generated. can be heard when refrigerant flow movement changes. It is normal. Smoke is • I f may not be a fire but it can be a steam generated by the generated from defrost operation from outdoor heat exchanger during Heat the outdoor unit. mode in winter. Water is dropping • Water may be generated because of the temperature from the outdoor difference. It is normal. unit piping connection. For Smart A/C application connection trouble, refer to the Smart A/C application manual.
- Page 29 Junfrau EU_AR09FSSK&Y@_IB_DB68-03363A_EN.indd 29 2012-11-1 9:42:54...
