Quasimidi POLYMORPH Operating Instructions Manual page 61

56 fx2 typ
57 fx2 level
58 fx2 feedback
59 fx2 delay time
5A fx2 mod. rate
5B fx2 mod. depth
5C eq1 gain
5D eq1 frequency
5E eq2 gain
5F eq2 frequency
60 distortion gain
61 distortion cutoff freq.
62 distortion resonance
63 fx2 feedback filter
Sequence Parameter
Adr. Parameter
00 sequence direction
01 line 1 assign
02 line 2 assign
03 line 3 assign
04 pitch line last step
05 ctrl line 1 last step
06 ctrl line 2 last step
07 ctrl line 3 last step
08..17 pitch steps
18..27 line 1 steps
28..37 line 1 steps
38..47 line 1 steps
(only stored in Setup memory section...)
48 transpose
49 sequence control
4A start trigger source
4B start trig. step/note
4C..53 sequence variations
Identity Request
Byte Value
00 F0
01 7E
02 cc
03 06
04 01
05 F7
Identity Reply
Byte Value
00 F0
01 7E
02 cc
03 06
04 02
05 3F
06 26
07 xx
08 xx
09 xx
10..13 v v v v
14 F7
* note that if cc = 7F the POLYMORPH respond regardless
of what master channel it is on
POLYMORPH System-Exclusive Format
0..5 (FLANGER...PANDELAY)
0..127
0..127
0..126,127 (time depents on typ, synced)
0..127
0..127
0..127
0..127
0..127
0..127
0,1..127 (OFF,1..127)
0..127
0..127
0..127
Value (Remarks)
bit 0..1: forward,backward,random
bit 2: notes forward
FF,0..97 (not assigned, Ctrl.No.)
FF,0..97 (not assigned, Ctrl.No.)
FF,0..97 (not assigned, Ctrl.No.)
0..15
0..15
0..15
0..15
0..48
0..127 (-64..+63)
0..127 (-64..+63)
0..127 (-64..+63)
40..88 (-24..+24)
bit 0..2: resolution (1..1/32)
bit 5: realtime transpose on/off
bit 6: sequence on/off
0,1..4,5..20 (FREE,SEQ1..4,EXT1..16)
0..15
bit 0..6: transpose
bit 7: sequence on/off
Remarks
System Exclusive start command
Common Non-Real-Time message
channel number = system channel-1 *
general information
identity request
end of System Exclusive
Remarks
System Exclusive start command
Common Non-Real-Time message
channel number = sytem channel-1 *
general information
identity reply
QUASIMIDI id
POLYMORPH id
reserved
reserved (Expension Board 1 exists (00=no, 01=yes))
reserved (Expension Board 2 exists (00=no, 01=yes))
Version no. (4 ascii characters, i.e '1.00')
end of System Exclusive
61
