POLYMORPH System-Exclusive Format

POLYMORPH System-Exclusive Format
Request Data from device
Byte
00
01
02
03
04
05
06
07
08
09
10
11
Dump Data to device
Byte
00
01
02
03
04
05
06
07
08...
xx
Adress Map
Adress
00 00 00 system parameter
01 00 00 temporary common parameter
01 01 00 temporary sound/mix parameter
01 02 00
01 03 00
01 04 00
01 05 00 temporary sequence parameter
01 06 00
01 07 00
01 08 00
01 09 00 reserved
...
01 7F 00 -"-
02 00 00 user sound 1
...
02 7F 00 -"-
03 00 00 sequence 1
...
03 31 00 -"-
03 32 00 reserved
...
03 7F 00 -"-
04 00 00 setup 1 common parameter
04 01 00 -"- part 1 sound -"-
04 02 00 -"- part 2 sound -"-
04 03 00 -"- part 3 sound -"-
04 04 00 -"- part 4 sound -"-
04 05 00 -"- part 1 sequence
04 06 00 -"- part 2 sequence
04 07 00 -"- part 3 sequence
Value Remarks
F0 System Exclusive start command
3F QUASIMIDI id number
dv device number = system channel-1
26 POLYMORPH id number
52 (R)equest data
ah adress high
am adress mid
al adress low
dh data count high (2 bit)
dm data count mid (7 bit)
dl data count low (7 bit)
F7 end of System Exclusive
Value Remarks
F0 System Exclusive start command
3F QUASIMIDI id number
dv device number = system channel-1
26 POLYMORPH id number
44 (D)ump data
ah adress high
am adress mid
al adress low
dt data (7 bit)
F7 end of System Exclusive
Memory section
-"-
-"-
-"-
-"-
-"-
-"-
128
50
(part 1)
(part 2)
(part 3)
(part 4)
(part 1)
(part 2)
(part 3)
(part 4)
58
