04 08 00 -"- part 4 sequence
04 09 00 reserved
...
04 7F 00 -"-
05 00 00 setup 2 common parameter
...
43 08 00 setup 64 part 4 sequence
44 00 00 reserved
...
7F 7F 00 -"-
Adress Offsets (low Adress Byte)
System Parameter
Adr. Parameter
00 system channel
01 local
02 extern sync
03 program change input
04 parameter control input
05 program change out
06 parameter control out
07 midi clock out
08 receive start
09 master tune
0A master transpose
0B poti mode
0C poti message
0D output mode
0E setup change input
0F setup change output
10 system exclusive speed
Common Parameter
Adr. Parameter
00..07 setup name
08..0B reserved
0C speed
0D groove
0E setup no.
0F play mode
10 sequencer control channel bit 0..3: channel 0..15 (1..16)
11 realtime transpose lowkey 12..120 (C0..C9)
12 realtime transpose highkey 12..120 (C0..C9)
13 realtime transpose origin
Sound Parameter
(in Setup memory section byte 00..0D are skipped!)
Adr. Parameter
00..07 sound name
08..0B reserved
0C bank no.
0D program no.
0E mix level
0F panorama
10 algorithm
11 osc 1 wave
12 osc coarse tune
13 osc tune
14 osc 1 level
15 osc 2 wave
16 osc 2 coarse tune
17 osc 2 tune
POLYMORPH System-Exclusive Format
Value (Remarks)
0..15 (1..16)
0,1 (OFF,ON)
0,1 (OFF,ON)
0,1 (OFF,ON)
0,1 (OFF,ON)
0,1 (OFF,ON)
0,1 (OFF,ON)
0,1 (OFF,ON)
0,1 (OFF,ON)
0..64..127 (-64..0..+63)
40..64..88 (-24..0..+24)
0..2 (JUMP,SNAP,RELATV)
0,1 (OFF,ON)
0..2 (1*STEREO, 2*STEREO, 4*SINGLE)
0,1 (OFF,ON)
0,1 (OFF,ON)
0..2 (FAST,NORM,SLOW)
Value (Remarks)
0..127 speed bit 1..7 (in BPM)
bit 1..4: groove 0..8 (0%..100%)
bit 0: speed bit 0
1..4 (UNISONO..STACK)
bit 4: variation change (OFF,ON)
12..120 (C0..C9)
Value (Remarks)
0..4 (USER,A..D)
0..127
0..127
0..64..127 (Left..0..Right)
0..7 (sync/12dB,24dB/ser.,par.)
0..127
0..48 (32"..2")
0..127
0..127
0..30
0..48 (32"..2")
0..127
