3-32 ENGINE CONTROL SYSTEM

OIL CHANGE REMINDER SYSTEM

This system informs the operator of the time for replacing EN-
GINE OIL on the basis of the recommended maintenance sched-
ule. When the total motor operating hours have reached the
preprogrammed hours;
• On the tiller handle model, the buzzer will begin a series of
double beeps (3 or 4 times).
• On the remote control model, the "OIL" lamp will flash, and the
buzzer will begin a series of double beeps if the engine is not
running (but ignition swith is ON).
The above mentioned indication will repeat until canceling sys-
tem activation.
NOTE:
This system will activate up to 2100 hour's operation.
INDICATION OF SYSTEM ACTIVATION
Buzzer
Tiller Handle Model
Remote Control Model
NOTE:
On the tiller handle model, the buzzer for system activation will first begin to sound when the engine is
stopped (but ignition switch is ON) after reaching the preprogrammed hours.
OIL lamp
Action
Starting operation
(*1) (*4)
Indication Cancellation
(*2)
Indication Cancellation
(*3)
Indication Cancellation
(*3)
Indication Cancellation
Repeat
*1 : Lapse of initial 20 hour's operation
*2 : Lapse of 80 hour's operation
*3 : Lapse of 100 hour's operation
*4 : When performing cancellation before
system activation
Double beeps (3 or 4 times)
(*4)
(*4)
(*4)
