CONDITION FOR SELF-DIAGNOSTIC SYSTEM OPERATION

FAILED ITEM
MAP sensor 1
CKP sensor
IAC valve/By-pass air screw
adjustment
CMP sensor
CTP switch
Cylinder temp. sensor
IAT sensor
MAP sensor 2
(Sensor hose etc.)
Rectifier & regulator
(Over-charging )
Exhaust manifold temp. sensor
Fuel injector
NOTE 1:
This condition will be caused by IAC valve failure or incorrect by-pass air screw adjustment. If IAC valve is
always closed or by-pass air is too low, the ECM controls the IAC valve duty to increase to maintain the
idling/trolling speed specified.
NOTE 2:
This condition will be caused by disconnected, kinked or clogged MAP sensor hose or clogged inlet maniford.
• No signal (With engine running)
• Receiving an out of range "37 – 860 mmHg (0.20 – 4.53 V)" signal
(With engine running)
• No signal from CKP sensor while receiving 3 signals from CMP sensor
• IAC valve operates at 90% duty or higher when CTP switch is "ON"
[NOTE 1]
• No signal from CMP sensor while receiving 544 signals from CKP sensor
(Corresponded to 16 turns of crankshaft)
• Receiving "ON" signal when engine speed is 2500 r/min or higher and intake
manifold pressure is 300 mmHg or higher
• No signal
• Receiving an out of range "– 46 to +170 °C (0.10 – 4.63 V)" signal
• No signal
• Receiving an out of range "– 46 to +169 °C (0.04 – 4.46 V)" signal
• Receiving unchanging signal regardless engine speed change
[NOTE 2]
• Receiving 16 volts or higher signal
• No signal
• Receiving an out of range "– 46 to +170 °C (0.10 – 4.63 V)" signal
• No signal
ENGINE CONTROL SYSTEM
CONDITION
3-29
