In the interest of safety, the VOH1042 DL should never be installed where it will be visible, directly or indirectly, by the operator of the motor vehicle.
Congratulations on your purchase of the Audiovox VOH1042 DL drop down TV/Video Monitor. VOH1042 DL has been designed to give you and your family many years of video entertainment in the mobile environment. Please read the directions that follow to familiarize yourself with the product and to ensure that you obtain the best results from your equipment.
FRONT PANEL FEATURES – 1. Power Button – (Bright red when system is ON, dim when system is OFF). 2. Channel Up/Down – Changes the TV channel. 3. Auto Program Switch (AP)– Auto Program used to program local channels into TV memory. Press when vehicle is in a new location.
(+ or -) is observed. 3) Slide the cover back until it clicks into position. The Remote Control will operate the VOH1042 DL, Audiovox Televisions and Video Media Players. It is not a universal remote control and will not control equipment from other manufacturers.
Page 7
REMOTE CONTROLLED TV FUNCTIONS 1. POWER ON/OFF Press this button to turn the VOH1042 DL on. The channel number or current video source will be displayed on screen, and the picture will appear in a few seconds. Press the button again to turn the VOH1042 DL off.
Page 8
“GREEN” on the screen, and the erased channels are in “RED”. When skip mode is on, the VOH1042 DL will tune to only the stored channels when using the CHANNEL UP/DOWN buttons.
STORE a channel, press the button until the MANUAL MEMORY XX ADD is displayed on screen. The built-in TURNING THE VOH1042 DL ON AND OFF store each 1 Sliding the screen release lock forward will unlock the screen and it will drop down slightly. (Pivot the...
OPERATION OVERHEAD DOME LIGHTS A three-position slide switch controls the Dome Lights on the VOH1042 DL. Sliding the switch to the ON position will turn the Dome Lights ON. The OFF position will prevent the Dome Lights from turning ON at all times and the auto position will allow the Dome Lights to turn ON and OFF with the vehicle’s interior lighting.
AUX inputs, the VIDEO INPUT 2 will be temporarily bypassed. Once the connections have been made, turn the VOH1042 DL on and press the source button on the VOH1042 DL or the TV/Video button on the remote control until “Video 2” is displayed on the This screen.
OFF will allow for normal radio reception. VIDEO OUTPUT The VOH1042 DL provides a video output for an optional Video monitor(s). This output will provide a video signal that duplicates the signal displayed by the VOH1042 DL to an additional Monitor or Video display.
TYPICAL SYSTEM CONNECTIONS T ’ Accessor Harness 2 PIN IR IR Transmitter LED Connector 4 PIN Power Connector Yellow RCA (Video) White RCA (Audio Left) Red RCA (Audio Right) -12- Antenna Negative Dome Light Switching Lamp Auto Purple/Brown Constant 12V Black/Red Lamp ON Red/Black...
Troubleshooting PROBLEM SOLUTION • Poor TV Reception Perform auto programming of the tuner • Verify antenna condition. • NOTE: Due to the nature of TV signals, direction the vehicle is facing, distance from the transmitter, nearby weather may adversely affect reception.
Page 15
AUDIOVOX ELECTRONICS CORP. (the Company) warrants to the original retail purchaser of this product that should this product or any part thereof, under normal use and conditions, be proven defective in material or workmanship within 36 months from the date of original purchase, such defect(s) will be repaired or replaced with reconditioned product (at the Company's option) without charge for parts and repair labor.
