6. If changing the lamp, remove old lamp from lamp socket. Hold the new lamp only by its
ceramic base. Never touch the glass bulb. Insert the new lamp in the lamp socket.
7. Please turn the head in horizontal position. Hinge must be on the upper side of the head.
Turn screws left and remove plastic cover. Loosen head screw and open the lamp cover
8. With the nipple of the lamp facing the back insert one end of the lamp into the socket. Pull
up the spring of the other side of the socket and snap the other end of the lamp into place.
Make sure it fits correctly into the socket.
the lamp in correct position.
Please refer to the diagram to know how to put
6F

4. How To Set The Unit

4.1 Control Panel

Display
To show the various menu and to select functions.
Button
MENU To select the programming functions
DOWN To go backward in the selected functions
UP To go forward in the selected functions
ENTER To confirm the selected functions
On/Off
Turns On/Off the power
Fuse
To replace the fuse
Power
To connect the power plug
DMX input/output
For DMX 512 link, use 5-pin XLR plug cable to link the unit together
7F
