Meter Description
Meter Front
1. 24‐hour mold radar animation
2. Indoor temperature (°C/°F) and MIN‐
MAX / Dew point temperature
3. Facial Icons for comfort level status
4. MIN‐MAX Button
5. Dew Point Button
6. Relative Humidity % display
7. Warning LED when risk of mold
Meter Back
1. Wall mount
2. Battery compartment
3. Battery compartment latch
4. Alarm Sound ON/OFF switch (Speaker Symbol)
5. Radar Animation ON/OFF switch (Arrow
Symbol)
6. Support stand (remove stand to access Alarm
sound and Radar animation switches)
1
2
3
2
4
3
EXTECH INSTRUMENTS
4 5
6
RH35‐en‐EU_v1.1 7/14
7
6
1
3
5
