READ THIS MANUAL CAREFULLY!
It contains important safety information.
OWNER'S MANUAL
YX70EPNG
2MB-F8199-70

Advertisement

Table of Contents
loading

Related Manuals for Yamaha wolverine YX70EPNG

Summary of Contents for Yamaha wolverine YX70EPNG

  • Page 1 READ THIS MANUAL CAREFULLY! It contains important safety information. OWNER’S MANUAL YX70EPNG 2MB-F8199-70...
  • Page 2 EBU33110 Read this manual carefully before operating this vehicle. This manual should stay with this ve- hicle if it is sold.
  • Page 3 Yamaha experience in the production of fine sporting, touring, and pace-setting racing vehicles. With the purchase of this Yamaha, you can now appreciate the high degree of crafts- manship and reliability that have made Yamaha a leader in these fields.
  • Page 4 EBU31080 IMPORTANT MANUAL INFORMATION EBU31070 FAILURE TO FOLLOW THE WARNINGS CONTAINED IN THIS MANUAL CAN RESULT IN SERI- OUS INJURY OR DEATH. Particularly important information is distinguished in this manual by the following notations: This is the safety alert symbol. It is used to alert you to poten- tial personal injury hazards.
  • Page 5  This vehicle complies with almost all provinces off-highway noise level and spark arrest- er laws and regulations. EBU33130 YX70EPNG OWNER’S MANUAL ©2014 by Yamaha Motor Co., Ltd. 1st edition, December 2014 All rights reserved. Any reprinting or unauthorized use without the written permission of Yamaha Motor Co., Ltd.

  • Page 6: Table Of Contents

    Drive select lever ........ 4-13 EBU31120 CONTENTS Fuel tank cap........4-14 Doors..........4-14 LOCATION OF THE WARNING AND Seats ..........4-15 SPECIFICATION LABELS ....... 1-1 Adjusting the driver seat position..4-16 Seat belts ........... 4-17 SAFETY INFORMATION ......2-1 Glove compartment ......4-17 Storage compartments ......
  • Page 7 Final gear oil ......... 5-6 LEARNING TO OPERATE YOUR Differential gear oil........ 5-7 VEHICLE ...........7-12 Accelerator pedal ......... 5-7 PERIODIC MAINTENANCE AND Seat belts ..........5-7 ADJUSTMENT .........8-1 Passenger handhold ......5-8 Owner’s manual and tool kit....8-2 Steering ..........5-8 Periodic maintenance chart for the Fittings and fasteners ......5-8 emission control system .....8-4...
  • Page 8 Brake pedal and accelerator pedal CONSUMER INFORMATION ....11-1 lubrication......... 8-42 Identification number records.....11-1 Checking the stabilizer bushes ..8-43 YAMAHA SIDE BY SIDE OFF-ROAD Rear knuckle upper and lower pivot VEHICLE WARRANTY POLICY ..11-4 lubrication (left and right)....8-43 Steering shaft lubrication ....8-44 INDEX ............12-1...

  • Page 9: Location Of The Warning And Specification Labels

    EBU31130 LOCATION OF THE WARNING AND SPECIFICATION LABELS 4,5,6 7 8 9 10 14 13...
  • Page 10 Read and understand all of the labels on your vehicle. They contain important information for safe and proper operation of your vehicle. Never remove any labels from your vehicle. If a label becomes difficult to read or comes off, a replacement label is available from your Yamaha dealer.
  • Page 11 Never hold cage. Do not try to stop a vehicle tipover using your arm or leg. YAMAHA 1XD-K7761-00...
  • Page 12 Ne pas dépasser le nombre de places disponibles : 1 passager. Inside the vehicle by holding the steering wheel or handhold. Lire le Manuel du propriétaire. YAMAHA 1XD-K8483-00 Lire le Guide de conseils à l’intention du conducteur du véhicule récréatif hors route.
  • Page 13 , trailer tongue, or vehicle. • Secure cargo so that it will not shift - a loose load YAMAHA MOTEUR DU CANADA LTÉE. could change handling unexpectedly or be thrown 480 Gordon Baker Road, Toronto (Ontario) M2H 3B4, forward and strike occupants.
  • Page 14 Ne jamais agripper l’arceau de protection. Ne jamais tenter d’empê cher un capotage à l’aide du bras ou de la jambe. YAMAHA 1XD-K7761-10...
  • Page 15 (if applicable) du passager, des accessoires, de l’équipement, et trailer tongue weight. (le cas échéant) du timon. YAMAHA 2MB-F1696-20 YAMAHA 2MB-F1696-10...
  • Page 16 YAMAHA certifies this ROV complies with the American YAMAHA certifie que ce véhicule hors route est conforme à la National Standard for Recreational Off-Highway Vehicles, norme ANSI/ROHVA-1-2011 de l’ANSI, intitulée American ANSI/ROHVA-1-2011 Standard. National Standard for Recreational Off-Highway Vehicles. Date of manufacture **/**...
  • Page 17 Aucun passager m=700Kg for ISO3471 dans la caisse de chargement YAMAHA MOTOR CANADA LTD. 480 Gordon Baker Road, Toronto, Ontario M2H 3B4, Canada 1XD-F4162-00 Le mauvais usage de la caisse de chargement ou de l’arceau de protection peut provoquer de graves blessures ou la mort par suite d’une perte de contrôle, d’un capotage ou d’un accident quelconque.
  • Page 18 Ne jamais tenter d’empê qu’au support de fixation using your arm or leg. cher un capotage à l’aide d’attelage. du bras ou de la jambe. YAMAHA 1XD-K7762-00 • Lire le manuel du propriétaire YAMAHA 1XD-K7762-10 avant de charger le véhicule et de remorquer ou tirer une charge.
  • Page 19 MAX 7.3 INCH accidents. • Secure load to prevent it (185MM) from shifting. YAMAHA 5UG-F151J-00 • Never load more than 490 N (50 kgf)/110 lbf tongue weight on towing bracket. • Do not tow more than...
  • Page 20 Feet On floor or footrests, ready to brace, and door closed. YAMAHA 1XD-F1558-00 WARNING Imp r op e r Us e o f O ff - Hi g hway Ve h i cl e Ca n C au se S eve re In j u r y o r D e a th...
  • Page 21 Pieds Sur le plancher ou les repose-pieds, prêts à encaisser le choc; portière fermée. YAMAHA 1XD-F1558-10 B e P r e p a r e d A d j u s t , l o ck a n d n eve r r e m o ve h a n d h o l d .

  • Page 22: Safety Information

    EBU33431 Be a responsible owner As the vehicle’s owner, you are responsible for the safe and proper operation of your Yamaha Wolverine. While understanding all parts of this manual are important for vehicle ownership, be sure to read this chapter and the instructions in Chapter 7 before operating your Yamaha Wolverine.
  • Page 23 Before you operate your Yamaha Wolverine  Prepare yourself and your passenger: • This vehicle is intended for use only by an operator 16 or older with a valid motor vehicle li- cense. DRIVER UNDER • This vehicle is designed to carry the driver and one passenger. Never carry passengers in the cargo bed.
  • Page 24  Secure cargo so that it will not shift – a loose load could change handling unexpectedly or be thrown forward and strike occupants. While using your Yamaha Wolverine  Keep your body completely inside the vehicle at all times. Keep both hands on the steering wheel.
  • Page 25  Abrupt maneuvers or aggressive driving, even on flat, open areas, can cause loss of control, including rollovers. The Wolverine has higher ground clearance and other features to handle rugged terrain, and, as a result, can overturn in situations where some other vehicles may not. ...
  • Page 26  If you think or feel that the vehicle may tip or roll, keep your body completely inside the protec- tive structure of the vehicle: • Brace yourself by pressing your feet firmly on the floorboard and keep a firm grip on the steering wheel or passenger handhold.
  • Page 27 Many companies with no connection to Yamaha manufacture parts and accessories or offer oth- er modifications for Yamaha vehicles. Yamaha is not in a position to test the products that these aftermarket companies produce. Therefore, Yamaha can neither endorse nor recommend the use of accessories not sold by Yamaha or modifications not specifically recommended by Yamaha, even if sold and installed by a Yamaha dealer.
  • Page 28 Aftermarket parts, accessories, and modifications While you may find aftermarket products similar in design and quality to genuine Yamaha Acces- sories, recognize that some aftermarket accessories or modifications are not suitable because of potential safety hazards to you or others. Installing aftermarket products or having other mod- ifications performed to your Wolverine that change any of the vehicle’s design or operation char-...

  • Page 29: Description

    EBU31170 DESCRIPTION EBU31180 Left view 12 11 1. Front shock absorber assembly 11.Driver seat 2. Radiator cap 12.Door 3. Brake fluid reservoir 4. Air filter 5. Shoulder bolster 6. Driver seat belt 7. Cargo bed 8. Tail/brake light 9. Rear shock absorber assembly 10.Spark plug...

  • Page 30: Right View

    EBU31190 Right view 1. Spark arrester 2. Passenger seat belt 3. Engine oil dipstick 4. Storage compartment 5. Battery 6. Fuses 7. Headlight 8. Coolant reservoir 9. Passenger seat 10.Fuel tank cap 11.Oil filter cartridge...

  • Page 31: Controls And Instruments

    EBU31200 Controls and instruments 4 5,6 7 15 14 1. Light switch 9. Passenger handhold 2. On-Command drive knob 10.Glove compartment 3. Steering wheel 11.Storage compartment 4. Main switch 12.Drive select lever 5. Helmet indicator light 13.Parking brake lever 6. Seat belt indicator light 14.Accelerator pedal 7.

  • Page 32: Instrument And Control Functions

    EBU31211 EBU31230 INSTRUMENT AND CONTROL “ ” (on): FUNCTIONS All electrical circuits are supplied with power. The key cannot be removed. EBU31220 Main switch The helmet indicator light comes on and stays on while the key is turned to “ ”...

  • Page 33: Indicator Lights And Warning Lights

    EBU31260 Indicator lights and warning lights 1. Helmet indicator light “ ” 2. Seat belt indicator light “ ” 1. On-Command differential gear lock indicator light “DIFF. EBU31270 LOCK” Low-range indicator light “L” 2. Low-range indicator light “L” This indicator light comes on when the drive 3.
  • Page 34 The On-Command differential gear lock EBU31290 Neutral indicator light “N” indicator “ ” and the On-Command differen- This indicator light comes on when the drive tial gear lock indicator light “DIFF. LOCK” select lever is in the “N” position. come on when the On-Command drive knob “2WD/4WD/DIFF LOCK”...
  • Page 35 When this occurs, be checked by turning the key to “ ” (on). If have a Yamaha dealer check the self-diagno- the warning light does not come on initially sis system. (See page 4-10 for an explanation when the key is turned to “...
  • Page 36 If the steering load is too heavy (i.e., exces- the indicator light remains on after the driver sive steering use when the Wolverine is trav- seat belt is properly latched, have a Yamaha eling at a slow speed), the power assist is dealer check the electrical circuit.

  • Page 37: Multi-Function Meter Unit

     a clock EBU31380 Multi-function meter unit  an hour meter (which shows the total time the engine has been running)  a voltage display (which shows the battery voltage)  a fuel meter  a self-diagnosis device Odometer and tripmeter modes 1.
  • Page 38 Pushing the “SELECT” button switches the Clock, hour meter and voltage display display between the odometer mode “ODO” modes and the tripmeter modes “TRIP A” and “TRIP B” in the following order: ODO → TRIP A → TRIP B → ODO To reset a tripmeter, select it by pushing the “SELECT”...
  • Page 39 To set the clock Voltage display mode 1. Set the display to the clock mode. 2. Push the “SELECT” button and “RESET” button together for at least three sec- onds. 3. When the hour digits start flashing, push the “RESET” button to set the hours. 4.
  • Page 40 (empty) as the fuel level decreases. When the charging circuit or the battery may be “E” segment disappears and the fuel level faulty. If this occurs, have a Yamaha dealer warning indicator flashes, refuel as soon as check or repair the vehicle.

  • Page 41: Light Switch

    Set the switch to “ ” to turn on the low code, note the code number, and then have a beam and the taillights. Yamaha dealer check the vehicle. Set the switch to “ ” to turn on the high beam and the taillights.

  • Page 42: On-Command Drive Knob "2Wd/4Wd/Diff Lock

    Set the switch to “ ” to turn off the head- EBU31400 On-Command drive knob lights and taillights. “2WD/4WD/DIFF LOCK” ECB02060 NOTICE Do not use the headlights with the engine turned off for an extended period of time. The battery may discharge to the point that the starter motor will not operate properly.

  • Page 43: Accelerator Pedal

     “DIFF LOCK” (four-wheel drive with the dif- ferential gear locked): Power is supplied to the rear and front wheels with the differen- tial gear locked. Unlike the “4WD” mode, all wheels turn at the same speed regardless of traction. EBU31410 Accelerator pedal Press the accelerator pedal down to increase...

  • Page 44: Parking Brake Lever

    Spring tension helps return the lever to the re- leased position. 1. Brake pedal EBU33450 Parking brake lever 1. Release button 2. Parking brake lever The parking brake lever is located at the right side of the driver’s seat. Setting the parking EBU31440 Drive select lever brake lever will help keep the vehicle from...

  • Page 45: Fuel Tank Cap

    To open Remove the fuel tank cap by turning it coun- terclockwise. To close Install the fuel tank cap by turning it clock- wise. EBU31460 Doors To open a door, pull the latch outward. To 1. Drive select lever close a door, push or pull the door inward un- EBU31450 til it is securely latched.

  • Page 46: Seats

    1. Door 1. Driver seat cushion 2. Latch 2. Passenger seat cushion To install a seat cushion, insert the projec- EBU33460 Seats tions on the rear of the seat cushion under the To remove a seat cushion, lift the front of the seat frame, and then insert the projection on cushion, and then pull the cushion off.

  • Page 47: Adjusting The Driver Seat Position

    Adjust the driver seat position as follows. 1. Remove the driver seat cushion. (See the previous section “Seats”.) 2. Remove the bolts. EBU31480 Adjusting the driver seat position The driver seat can be adjusted to one of three positions to suit the driver’s preference. 1.

  • Page 48: Seat Belts

    1. Seat belt 4. Install the bolts, and then tighten the bolts to the specified torque. EBU31501 Glove compartment This vehicle is equipped with a glove com- Tightening torque: partment. Driver seat bolt: 23 Nm (2.3 m·kgf, 17 ft·lbf) When storing any documents in the glove compartment, be sure to wrap them in a plas- 5.

  • Page 49: Storage Compartments

    ECB02071 EBU33521 NOTICE Storage compartments The storage compartments are located under To protect from damage, do not put metal the multi-function meter, between the driver items, like tools, or sharply edged items di- seat and the passenger seat, and under the rectly in the glove compartment.

  • Page 50: Cup Holders

    1. Storage compartment 1. Storage compartment Maximum load limit: Storage compartment between the driver seat and the passenger seat: 6.4 kg (13.5 lb) EBU31520 Cup holders Be sure to tightly close the cap of any plastic bottle before placing it in a cup holder. Some plastic bottles may not fit into the cup 1.

  • Page 51: Cargo Bed

    EWB03240 WARNING  Never ride with any open or glass con- tainers in the cup holders; otherwise, the contents may spill and the glass contain- ers may be thrown about and break, and possibly injure people in the vehicle dur- ing sudden braking or an accident.
  • Page 52 For additional loading information, see page 6-7. Removing and installing the tailgate To remove the tailgate Unhook the latches, and then pull up the tail- gate. 1. Cargo hook 1. Tailgate 2. Latch To install the tailgate 1. Cargo hook Place the tailgate in the original position, and then hook the latches.

  • Page 53: Adjusting The Front Shock Absorber Assemblies

    The tailgate can also be installed at the front (for fast compression damping), and a com- of the cargo bed. Install the tailgate and hook pression damping force adjusting screw (for the latches as shown. slow compression damping). EWB02492 WARNING ...
  • Page 54 Spring preload  A special wrench can be obtained at a 1. Loosen the locknut. Yamaha dealer to make this adjustment. 2. Turn the spring preload adjusting nut in  The spring preload setting is determined by direction (a) to increase the spring pre-...
  • Page 55 Spring preload setting: Tightening torque: Minimum (soft): Locknut: Distance A = 313.5 mm (12.34 in) 30 Nm (3.0 m·kgf, 22 ft·lbf) Standard: Distance A = 305.5 mm (12.03 in) Rebound damping force Maximum (hard): Turn the rebound damping force adjusting Distance A = 298.5 mm (11.75 in) screw in direction (a) to increase the rebound damping force and thereby harden the damp-...
  • Page 56 Rebound damping setting: Minimum (soft): 30 click(s) in direction (b)* Standard: 13 click(s) in direction (b)* Maximum (hard): 1 click(s) in direction (b)* * With the adjusting screw fully turned in di- rection (a) Compression damping force 1. Compression damping force adjusting bolt (for fast compression damping) Compression damping force (for fast com- Compression damping setting (for fast com-...
  • Page 57 Compression damping force (for slow com- Compression damping setting (for slow com- pression damping) pression damping): To increase the compression damping force Minimum (soft): 18 click(s) in direction (b)* and thereby harden the compression damp- Standard: ing, turn the compression damping force ad- 12 click(s) in direction (b)* justing screw in direction (a).

  • Page 58: Adjusting The Rear Shock Absorber Assemblies

    Take the shock absorber assembly to a semblies on the left and right side to the Yamaha dealer for any service. same setting. Uneven adjustment can cause poor handling and loss of stability, which could lead to an accident.
  • Page 59 3. Special wrench sion.  A special wrench can be obtained at a Yamaha dealer to make this adjustment.  The spring preload setting is determined by measuring distance A, shown in the illustra- tion. The shorter distance A is, the higher the spring preload;...
  • Page 60 Spring preload setting: Tightening torque: Minimum (soft): Locknut: Distance A = 386.0 mm (15.20 in) 30 Nm (3.0 m·kgf, 22 ft·lbf) Standard: Distance A = 378.0 mm (14.88 in) Rebound damping force Maximum (hard): Turn the rebound damping force adjusting Distance A = 372.0 mm (14.65 in) screw in direction (a) to increase the rebound damping force and thereby harden the damp-...
  • Page 61 Rebound damping setting: Minimum (soft): 30 click(s) in direction (b)* Standard: 14 click(s) in direction (b)* Maximum (hard): 1 click(s) in direction (b)* * With the adjusting screw fully turned in di- rection (a) Compression damping force 1. Compression damping force adjusting bolt (for fast compression damping) Compression damping force (for fast com- Compression damping setting (for fast com-...
  • Page 62 Compression damping force (for slow com- Compression damping setting (for slow com- pression damping) pression damping): To increase the compression damping force Minimum (soft): 18 click(s) in direction (b)* and thereby harden the compression damp- Standard: ing, turn the compression damping force ad- 12 click(s) in direction (b)* justing screw in direction (a).

  • Page 63: Trailer Hitch Bracket And Receiver

    5 cm (2 in) receiver for a stan- EBU32950 dard trailer hitch. Trailer towing equipment Auxiliary DC jack can be obtained at a Yamaha dealer. (See The auxiliary DC jack is located at the right page 6-7 for precaution information.) side of the storage compartment under the multi-function meter.
  • Page 64 ECB02250 NOTICE  Do not use accessories requiring more than the stated maximum capacity. Do- ing so may overload the circuit and cause the fuse to blow.  If accessories are used without the en- gine running, the battery may discharge. ...

  • Page 65: For Your Safety - Pre-Operation Checks

    Do not operate the vehicle if you find any problem. If a problem can- not be corrected by the procedures provided in this manual, have the vehicle inspected by a Yamaha dealer. Before using this vehicle, check the following points:...
  • Page 66 ITEM ROUTINE PAGE • Check coolant level in reservoir. Coolant 5-6, 8-24 • Fill with coolant if necessary. Final gear oil/Differen- • Check for leakage. 5-6, 5-7, 8-20, 8-22 tial gear oil Accelerator pedal • Check for proper accelerator pedal operation. Seat belts •...

  • Page 67: Front And Rear Brakes

    Apply the brakes firmly for one minute. If there  Check that there is no free play in the brake is any leakage, have the vehicle inspected by pedal. If there is free play, have a Yamaha a Yamaha dealer. dealer check the brake system. (See page 8-40.)
  • Page 68 Your Yamaha engine has been designed to lights of water heaters and clothes dry- use regular unleaded gasoline with a pump ers.

  • Page 69: Engine Oil

    If you carry a portable fuel container in the do not mix any chemical additives. Do bed of your Yamaha Wolverine, be sure to se- not use oils with a diesel specification of cure it with the cap tightened before driving “CD”...

  • Page 70: Coolant

     Make sure that no foreign material en- ECB02120 NOTICE ters the crankcase. Hard water or salt water is harmful to the engine. You may use soft water if you can- Recommended engine oil type and quantity: not get distilled water. See page 10-1.

  • Page 71: Differential Gear Oil

    To help make sure your restraint systems are spring back to the idle position fully when re- working properly after a crash, have them in- leased. Have a Yamaha dealer repair as nec- spected and any necessary replacements essary for proper operation.

  • Page 72: Passenger Handhold

    Take the vehicle Use the tire pressure gauge to check and ad- to a Yamaha dealer or refer to the Service just tire pressures when the tires are cold. Tire Manual for correct tightening torque.
  • Page 73 injury or death from loss of control or roll- Recommended tire pressure: over. Tire pressure below the minimum Vehicle load: specified could also cause the tire to dis- 0 - maximum Front: lodge from the rim under severe riding 75.0 kPa (0.750 kgf/cm², 11 psi) conditions.
  • Page 74 1. Tire pressure gauge 1. Tire wear limit Tire wear limit When the tire groove decreases to 3 mm (0.12 in) due to wear, replace the tire. 5-10...

  • Page 75: Operation

    If any abnormality is noticed EBU31890 during this period, consult a Yamaha dealer. Engine break-in There is never a more important period in the 0–10 hours:...

  • Page 76: Starting The Engine

    If the neutral indi- cator light does not come on, ask a After break-in: Yamaha dealer to inspect the electric The vehicle may now be operated normally. circuit.  The engine can be started in any gear if...

  • Page 77: Drive Select Lever Operation And Reverse Driving

    Do not turn the key to the “ ” (start) position 2. Apply the brake pedal, then shift by mov- with the engine running; otherwise, damage ing the drive select lever along the shift to the electric starter may result. guide.
  • Page 78 5. Check behind the vehicle for people or light should be on. If the light does not obstacles, and then release the brake come on, ask a Yamaha dealer to in- pedal. spect the reverse indicator light electri- 6. Press the accelerator pedal gradually and cal circuit.

  • Page 79: On-Command Drive Knob

    EBU31920 On-Command drive knob The vehicle handles differently in each of the drive modes (“2WD”, “4WD” and “DIFF LOCK”). For example, the vehicle requires more effort to turn in “DIFF LOCK” than in “2WD”. Always stop the vehicle before changing the position of the On-Command drive knob. The meter display changes according to the selected drive mode.
  • Page 80  When the knob is set to “DIFF LOCK” or “4WD”, the differential gear lock indicator and indica- tor light will flash until the differential gear is completely locked or unlocked.  When the indicator and indicator light are flashing, turning the steering wheel back and forth will help the differential gear lock to engage or disengage.

  • Page 81: Parking

     Do not exceed the Maximum Loading EBU31930 Parking Limits for the vehicle (see “MAXIMUM When parking, stop the engine and shift the LOADING LIMIT” in this section and ve- drive select lever into the neutral position. Ap- hicle labeling). ply the parking brake to help prevent the ve- ...
  • Page 82 Choose a trailer hitch drawbar designed for Operating when loaded with cargo or tow- use with a 5 cm (2 in) receiver. (See page 4-32 ing a trailer for more information.) Drive more slowly than you would without a load. The more weight you carry, the slower You can measure tongue weight with a bath- you should go.
  • Page 83 Pulling something other than a trailer Yamaha recommends that loads be trans- ported in the bed or in a trailer. If you need to move an object a short distance use a winch and follow the winch manufacturer’s instruc- tions.

  • Page 84: Basic Guide For Safe Use

    EBU31950 EBU33500 KNOW YOUR VEHICLE BASIC GUIDE FOR SAFE USE This off-road vehicle will handle and maneu- ver differently from cars, ATVs, go-carts, golf- EBU31960 cars and grounds-keeping vehicles. The As a Wolverine owner you are responsible for Wolverine has higher ground clearance and the safe and proper operation of this vehicle.
  • Page 85  The driver must be able to place both feet As the owner/operator, it is your responsibility to protect yourself and your passenger from flat on the floorboard while seated upright accidents, including rollovers. The Wolverine with his/her back against the backrest. ...
  • Page 86 Passenger requirements Occupant protection system This vehicle is designed for the operator and EWB03350 WARNING one passenger. Allowing passengers to ride Do not make changes to the occupant pro- improperly can lead to serious injury or death. tection system. If you install aftermarket As the operator, you are responsible for your products or have your vehicle modified, passenger.
  • Page 87 Protective structure The vehicle cage/frame provides a protective structure that helps limit intrusions by branch- es or other objects and may reduce your risk of injury in accidents. The protective structure will not protect occupants in all rollovers or accidents. Body parts outside of vehicle can be struck by passing objects or crushed during vehicle rollover.
  • Page 88 Seat belts A crash can damage the restraint systems in Seat belts should be worn by the driver and your vehicle. A damaged restraint system passenger. The driver must be sure that the may not properly protect the person using it, passenger is belted before driving.
  • Page 89 1. Hold the latch plate as you pull the belt 3. Push the latch plate into the buckle until it across your lap and chest. Make sure the clicks. Pull up on the latch plate to make belt is not twisted and is not caught on sure it is secure.
  • Page 90 5. Position the shoulder belt over your 7. To release the buckle, firmly press the re- shoulder and across your chest. The lease button. shoulder belt should fit against your Doors chest. If it is loose, pull the belt out all the The doors are designed to reduce the likeli- way and then let it retract.
  • Page 91 Passenger handhold Adjusting the handhold position The passenger handhold is provided to grip The handhold can be adjusted to one of three during operation to maintain proper position positions to suit the passenger’s preference. and balance. Holding onto the handhold helps to reduce the likelihood that the pas- senger puts a hand outside the vehicle if the vehicle begins to tip.
  • Page 92 Adjust the handhold position as follows. 1. Remove the locking pins. 1. Handhold support 2. Handhold bar 3. Insert the pins into the holes and secure 1. Passenger handhold 2. Locking pin them with the wire loops. Make sure that 2.
  • Page 93 1. Wire loop Floorboard Seat and shoulder bolsters The floorboard allows you to brace your feet, The seats and shoulder bolsters are designed which helps you keep your body in the vehicle to help keep you in the vehicle. Do not put in the event of an accident or rollover.
  • Page 94 briefly jerk in one direction or back and forth CORRECT GRIP EXAMPLE as the tires and vehicle respond to the obsta- cle. This quick motion could injure your thumbs or wrist if your thumbs or hand(s) are inside the steering wheel. Grip the steering wheel so that your thumbs will not be hit by the spokes.

  • Page 95: Learning To Operate Your Vehicle

     Eye protection (goggles, helmet face shield, EBU33540 LEARNING TO OPERATE YOUR VEHI- or protective eyewear)  Over-the-ankle boots, gloves, long-sleeved shirt or jacket, and long pants Personal protective equipment An approved helmet and other personal pro- tective equipment can help in a variety of ways, including: ...
  • Page 96 Practice for new Yamaha Wolverine users You should become familiar with the perfor- mance characteristics of the vehicle in a large, flat area that is free of obstacles and other vehicles. Practice controlling the accel- erator pedal, brakes, steering, and drive se- lect lever.
  • Page 97 Getting ready to ride If you think or feel that the vehicle may tip or Perform the Pre-Operation Checks on page roll, keep your body completely inside the 5-1. Follow the instructions starting on page protective structure of the vehicle: ...
  • Page 98 Avoid higher speeds and sudden or hard ac- the vehicle down after you take your foot off celeration until you are thoroughly familiar the accelerator. Engine braking is more no- with the operation of your vehicle. Avoid sud- ticeable in four-wheel drive. Application of ve- den or hard acceleration in any turn.
  • Page 99 Parking on a flat area 5. Block the front and rear wheels with When parking on a flat area, stop the engine rocks or other objects. and shift the drive select lever into the neutral Loading position. Apply the parking brake to help pre- The total weight of operator, passenger, ac- vent the vehicle from rolling.
  • Page 100 Your Yamaha Wolverine has higher ground to see far enough ahead of you. Use common clearance and other features to handle rug- sense and remember that some hills are too ged terrain, and as a result, can overturn in steep for you to climb or descend. Use proper situations where some vehicles may not.
  • Page 101 side of a hill, which increases your risk of roll- slow your descent. Release the brake and be- over. Practice first on gentle slopes before at- gin to coast down the hill. Use engine braking tempting steeper hills. Always check the as much as possible, gently applying the terrain carefully before attempting any hill.
  • Page 102 If you are sliding or skidding, try to steer in the Pavement direction the vehicle is sliding, to regain con- This vehicle is designed for off-road use only. trol. For example, if you feel the back of the Avoid paved surfaces. Turn gradually and go vehicle start to slide to your right, steer to the slowly if you must drive on pavement.
  • Page 103 Wet brakes may have reduced effectiveness. If you feel the vehicle begin to slide sideways After leaving the water, test your brakes. If or fishtail during a turn, steer into the direction necessary, apply the brakes several times to of the slide if possible, to regain directional let friction dry out the linings.
  • Page 104 muffler or exhaust pipe, or next to other hot If there is any question about your ability to parts. Check under the vehicle after operating maneuver safely over the obstacle, you in areas where combustible materials may should turn around if the ground is flat and have collected.

  • Page 105: Periodic Maintenance And Adjustment

    To avoid death during service or while using the ve- possible burns, let brake components cool hicle. If you are not familiar with vehicle before touching them. service, have a Yamaha dealer perform the service.

  • Page 106: Owner's Manual And Tool Kit

    EBU33560 Owner’s manual and tool kit You are recommended to put this owner’s manual in the vinyl bag and always carry it in the glove compartment as shown. Put the owner’s tool kit and tire pressure gauge under the passenger seat. 1.
  • Page 107 If you do not have a torque wrench available during a service operation requiring one, take your vehicle to a Yamaha dealer to check the torque settings and adjust them as neces- sary.

  • Page 108: Periodic Maintenance Chart For The Emission Control System

    However, keep in mind that if the vehicle isn’t used for a long period of time, the month maintenance intervals should still be followed.  Items marked with an asterisk should be performed by a Yamaha dealer as they require special tools, data and technical skills.
  • Page 109 INITIAL EVERY month Whichev- ITEM ROUTINE er comes 1200 2400 2400 4800 first (mi) (200) (750) (1500) (1500) (3000) hours • Check for leakage. √ √ √ Exhaust system • Tighten if necessary. • Replace gasket(s) if necessary. √ √ √...

  • Page 110: General Maintenance And Lubrication Chart

    EBU32110 General maintenance and lubrication chart INITIAL EVERY month Whichev- ITEM ROUTINE er comes 1200 2400 2400 4800 first (mi) (200) (750) (1500) (1500) (3000) hours • Check coolant leakage. √ √ √ √ √ • Repair if necessary. Cooling system •...
  • Page 111 INITIAL EVERY month Whichev- ITEM ROUTINE er comes 1200 2400 2400 4800 first (mi) (200) (750) (1500) (1500) (3000) hours √ √ √ √ √ Parking brake • Check operation and adjust if necessary. Brake fluid • Replace. Every 2 years √...
  • Page 112 INITIAL EVERY month Whichev- ITEM ROUTINE er comes 1200 2400 2400 4800 first (mi) (200) (750) (1500) (1500) (3000) hours Drive shaft uni- √ √ √ 18 * • Lubricate with lithium-soap-based grease. versal joint • Check for cracks or damage. √...
  • Page 113 • Replace the brake hoses every four years and if cracked or damaged.

  • Page 114: Hood

    EBU32340 Hood To remove 1. Pull the tab on each hood lock up, and then turn the hood locks 1/4 turn clock- wise. 1. Tab 2. Hood lock 2. Remove the hood. 1. Tab 1. Hood 8-10...

  • Page 115: Panels

    To install EBU33601 Panels 1. Insert the projections on the hood into the slots in the front grill, and then place the Left panel hood in the original position. To remove the left panel 1. Remove the bolts. 2. Turn the hood locks 1/4 turn counter- clockwise, and then push the tab on each 1.
  • Page 116 1. Quick fastener 1. Bolt 2. Right panel 3. Pull the panel outward. 2. Open the passenger door, and then re- 4. Close the driver door. move the quick fasteners. To install the left panel Open the driver door, place the panel in the original position, and then install the bolts and quick fasteners.
  • Page 117 Right rear panel To remove the right rear panel 1. Remove the right panel. 2. Remove the quick fasteners, and then take the panel off. 1. Quick fastener 3. Remove the fuel tank cap. (See page 4-14.) 4. Pull the panel outward. 5.

  • Page 118: Engine Oil And Oil Filter Cartridge

    EBU33702 Engine oil and oil filter cartridge Check engine oil level before each operation. In addition, change the oil and the oil filter car- tridge at the intervals specified in the periodic maintenance and lubrication chart. To check the engine oil level 1.
  • Page 119 6. With the arrow mark pointing in the direc- tion shown, insert the dipstick completely into the oil filler hole and then remove it again to check the oil level. 1. Engine oil dipstick 2. Maximum level mark 3. Minimum level mark The engine oil should be between the mini- 1.
  • Page 120 1. Engine oil dipstick 1. Rubber cover 2. Arrow mark 5. Remove the engine oil dipstick. 9. Install the rubber cover. 6. Place an oil pan under the engine to col- 10. Install the passenger seat cushion. lect the used oil. 7.
  • Page 121 An oil filter wrench is available from a Yamaha dealer. 1. Engine oil drain bolt 2. Gasket Skip steps 8–10 if the oil filter cartridge is not 1. Oil filter cartridge being replaced. 2. Oil filter wrench 8. Remove the oil filter cartridge with an oil 9.
  • Page 122 1. O-ring 1. Torque wrench 10. Install the new oil filter cartridge with an 11. Install the engine oil drain bolt and its new oil filter wrench, and then tighten it to the gasket, and then tighten the bolt to the specified torque with a torque wrench.
  • Page 123 Be sure to wipe off spilled oil on any parts af- ter the engine and exhaust system have cooled down. ECB00301 NOTICE  In order to prevent clutch slippage (since the engine oil also lubricates the clutch), do not mix any chemical additives. Do 1.

  • Page 124: Final Gear Oil

    15. Turn the engine off, wait at least 10 min- utes, and then check the oil level and cor- rect it if necessary. 16. Install the rubber cover. 17. Install the passenger seat cushion. EBU32370 Final gear oil Checking the final gear oil level 1.
  • Page 125 4. Install the drain bolt and its new gasket, Tightening torque: and then tighten the bolt to the specified Final gear oil filler bolt: torque. 23 Nm (2.3 m·kgf, 17 ft·lbf) Tightening torque: Changing the final gear oil Final gear oil drain bolt: 1.

  • Page 126: Differential Gear Oil

    Tightening torque: Final gear oil filler bolt: 23 Nm (2.3 m·kgf, 17 ft·lbf) 8. Check for oil leakage. If oil leakage is found, check for the cause. EBU32380 Differential gear oil Checking the differential gear oil level 1. Differential gear oil filler bolt 1.
  • Page 127 4. Install the differential gear oil drain bolt Tightening torque: and its new gasket, and then tighten the Differential gear oil filler bolt: bolt to the specified torque. 23 Nm (2.3 m·kgf, 17 ft·lbf) Tightening torque: Changing the differential gear oil Differential gear oil drain bolt: 1.

  • Page 128: Coolant

    Tightening torque: Differential gear oil filler bolt: 23 Nm (2.3 m·kgf, 17 ft·lbf) 8. Check for oil leakage. If oil leakage is found, check for the cause. EBU33660 Coolant The coolant level should be checked before each ride. In addition, the coolant must be 1.
  • Page 129 Changing the coolant EWB01891 WARNING Wait for the engine and radiator to cool be- fore removing the radiator cap. You could be burned by hot fluid and steam blown out under pressure. Always place a thick rag over the cap when opening. Allow any remaining pressure to escape before com- pletely removing the cap.
  • Page 130 1. Coolant drain bolt 1. Coolant reservoir cap 2. Gasket 2. Coolant reservoir hose 6. Place a container under the coolant res- 8. Disconnect the coolant reservoir hose, ervoir to collect the used coolant. and then drain the coolant from the cool- 7.
  • Page 131 Tightening torque: Antifreeze/water mixture ratio: Coolant drain bolt: 8 Nm (0.8 m·kgf, 5.8 ft·lbf) Recommended antifreeze: High-quality ethylene glycol antifreeze con- 11. Connect the coolant reservoir hose. taining corrosion inhibitors for aluminum engines 12. Pour the recommended coolant into the Coolant quantity: radiator until it is full.
  • Page 132 1. Water pump air bleed bolt 1. Cylinder head air bleed bolt 16. When coolant begins to flow out of the 18. When coolant begins to flow out of the bolt hole, tighten the water pump air bolt hole, tighten the cylinder head air bleed bolt to the specified torque.

  • Page 133: Axle Boots

    24. Start the engine, and then check for cool- 1. Front axle boot ant leakage. If any leakage is found, have a Yamaha dealer check the cooling system. 25. Install the panels and the hood. EBU32400 Axle boots Check the axle boots for holes or tears.

  • Page 134: Spark Plug Inspection

    EBU33570 Spark plug inspection Removal 1. Remove the spark plug cap. 1. Spark plug wrench Inspection The spark plug is an important engine com- ponent and is easy to inspect. The condition 1. Spark plug cap of the spark plug can indicate the condition of 2.
  • Page 135 and erode. If electrode erosion becomes ex- Spark plug gap: cessive, or if carbon and other deposits are 0.8–0.9 mm (0.031–0.035 in) excessive, you should replace the spark plug with the specified plug. Installation 1. Clean the surface of the spark plug gas- Specified spark plug: ket and its mating surface, and then wipe NGK/CPR7EA-9...

  • Page 136: Cleaning The Air Filter Element

    1. Remove the storage compartment locat- EBU33580 Cleaning the air filter element ed between the driver seat and the pas- The air filter element should be cleaned every senger seat as shown. 20–40 hours. It should be cleaned and lubri- cated more often if the vehicle is operated in extremely dusty areas.
  • Page 137 4. While pushing the projections on the air filter frame inward, remove the air filter el- ement holder. 1. Air filter case cover 2. Air filter case cover holder 3. Remove the air filter element. 1. Air filter element holder 2.
  • Page 138 1. Air filter element holder 8. Wash the sponge material in warm soapy 2. Sponge material water to remove remaining solvent, then 3. Air filter frame rinse thoroughly with plain warm water. 6. Wash the sponge material gently but 9. Squeeze excess water out of the sponge thoroughly in parts cleaning solvent.

  • Page 139: Cleaning The Air Filter Case/Air Duct Check Hose

    11. Thoroughly apply Yamaha foam air filter 16. Install the storage compartment as oil or other quality liquid foam air filter oil shown. (not spray type) to the sponge material. The sponge material should be wet but not dripping. 12. Pull the sponge material over its frame.

  • Page 140: V-Belt Case Drain Plug

    If water drains from the V-belt case after re- moving the drain plug, have a Yamaha dealer 1. Remove the tailpipe bolts. inspect the vehicle, as the water may affect other engine parts.
  • Page 141 1. Tailpipe bolt 1. Gasket 2. Spark arrester 2. Remove the tailpipe by pulling it out of 3. Tailpipe the muffler, and then remove the gasket. 4. Install the gasket, and then insert the tail- 3. Tap the tailpipe lightly, and then use a pipe into the muffler and align the bolt wire brush to remove any carbon depos- holes.

  • Page 142: Valve Clearance

    Yamaha service technician. pad has worn to the point that the wear indi- cator grooves have almost disappeared, have EBU32470 a Yamaha dealer replace the brake pads as a Brakes set. Replacement of brake components requires The wheels need to be removed to check the professional knowledge.

  • Page 143: Checking The Brake Fluid Level

    1. Brake pad wear indicator groove 1. Minimum level mark EBU32500 Specified brake fluid: DOT 4 Checking the brake fluid level Before riding, check that the brake fluid is EWB02721 WARNING above the minimum level mark. Check the Improper maintenance can result in loss of brake fluid level with the top of the reservoir braking ability.

  • Page 144: Brake Fluid Replacement

    Brake fluid may damage painted surfaces EBU32530 or plastic parts. Always clean up spilled Checking the brake pedal fluid immediately. Have a Yamaha dealer check the brakes at the intervals specified in the periodic mainte- nance and lubrication chart. There should be 8-40...

  • Page 145: Parking Brake

    In addition, have should operate smoothly and there should be a Yamaha dealer check and adjust the park- no brake drag. If the brakes feel soft or ing brake at the intervals specified in the peri- spongy, this could indicate air in the brake odic maintenance and lubrication chart.

  • Page 146: Cable Inspection And Lubrication

    Lubricate the cable ends. If the cables do not operate smoothly, ask a Yamaha dealer to re- place them. Recommended lubricant: Yamaha cable lubricant or other suitable cable lubricant EBU32570 Brake pedal and accelerator pedal lu- brication 1. Brake light switch Lubricate the pivoting parts.

  • Page 147: Checking The Stabilizer Bushes

    The stabilizer bushes must be checked for cracks or damage at the intervals specified in Lubricate the knuckle upper and lower pivots the periodic maintenance and lubrication with a grease gun. chart. Have a Yamaha dealer replace the stabilizer bushes if necessary. 8-43...

  • Page 148: Steering Shaft Lubrication

    EBU32610 Recommended lubricant: Wheel removal Lithium-soap-based grease 1. Loosen the wheel nuts. 2. Elevate the vehicle and place a suitable EBU32600 Steering shaft lubrication stand under the frame. Lubricate the pivot points. 3. Remove the nuts from the wheel. 4. Remove the wheel. Recommended lubricant: Lithium-soap-based grease 8-44...

  • Page 149: Tire Replacement

    Always use the same size and type of tires Size: recommended in this owner’s manual. The 26 x 8-12NHS tires that came with your Yamaha Wolverine Manufacturer/model: were designed to match the performance ca- MAXXIS/MU09 pabilities and to provide the best combination Rear tire: of handling, braking, and comfort.

  • Page 150: Wheel Installation

    Wheel installation WARNING 1. Install the wheel and the nuts. Do not reverse the rims on your Yamaha Wolverine to widen the track width. Install- ing wheels improperly increases the risk of Tapered nuts are used for both the front and wheel failure and accidents.
  • Page 151 EWB03410 EWB03420 WARNING WARNING Avoid battery contact with skin, eyes, or Batteries may produce explosive gases. clothing. Shield eyes when working near Ventilate when charging or using in a batteries. Keep out of reach of children. closed space. Keep batteries away from You could be poisoned or severely burned sparks, flames, cigarettes, or other sourc- by the sulfuric acid in battery electrolyte.
  • Page 152 To charge the battery ing their bolt. NOTICE: When removing Have a Yamaha dealer charge the battery as the battery, the main switch must be soon as possible if it seems to have dis- off, and the negative lead must be dis- charged.
  • Page 153 To install the battery ECB00932 NOTICE To charge a VRLA (Valve Regulated Lead Be sure the battery is fully charged. Acid) battery, a special (constant-voltage) battery charger is required. Using a con- 1. Place the battery in its compartment. ventional battery charger will damage the 2.

  • Page 154: Jump-Starting

    3. Hook the battery bands. 1. Turn the key to “ ” (off). 4. Install the air intake duct panel by install- 2. Remove the hood. (See page 8-10 for ing the quick fastener screws. hood removal and installation proce- 5.

  • Page 155: Fuse Replacement

    4. Connect the negative lead of the jumper disconnect the positive lead of the jump- cable to the negative terminal of the er cable from the charged battery and the charged battery and the other end of the battery in the vehicle. negative lead to an unpainted metal sur- 7.
  • Page 156 1 2 3 4 5 6 1. Fuse box 1. Backup fuse “BACK UP” (for clock) 2. Main fuse 2. Ignition fuse “IGNITION” 3. EPS fuse 3. Four-wheel-drive motor fuse “DIFF” 4. Fuel injection system fuse 4. Auxiliary DC jack fuse “TERMINAL” 5.
  • Page 157 ECB00641 Specified fuses: NOTICE Main fuse: To prevent accidental short-circuiting, 40.0 A turn off the main switch when checking or Fuel injection system fuse: replacing a fuse. 10.0 A Headlight fuse: 2. Remove the hood. (See page 8-10 for 15.0 A hood removal and installation proce- Ignition fuse: 10.0 A...

  • Page 158: Replacing A Headlight Bulb

    2. Remove the headlight bulb cover by pull- electrical circuit in question to check if ing it off. the device operates. If the fuse blows again immediately, have a Yamaha dealer check the electrical system. 5. Install the hood. EBU32670...
  • Page 159 5. Wait for the headlight bulb to cool before touching or removing it. Remove the burnt-out bulb by pulling it out. 6. Place a new headlight bulb into position, and then secure it with the bulb holder. NOTICE: Do not touch the glass part of the headlight bulb to keep it free from oil, otherwise the transparency of the glass, the luminosity of the bulb, and...

  • Page 160: Headlight Beam Adjustment

    EBU32680 Headlight beam adjustment ECB00691 NOTICE It is advisable to have a Yamaha dealer make this adjustment. To raise the beam, turn the headlight beam adjusting screw in direction (a). To lower the beam, turn the headlight beam adjusting screw in direction (b).

  • Page 161: Tail/Brake Light Bulb Replacement

    The troubleshooting chart describes a quick, easy procedure for making checks. If your vehicle requires any repair, take it to a Yamaha deal- The skilled technicians at a Yamaha dealer- ship have the tools, experience, and know- how to properly service your vehicle.
  • Page 162 EWB03450 WARNING When checking the fuel system, do not smoke and make sure there are no open flames or sparks in the area, including pilot lights from water heaters or furnaces. Gasoline or gasoline vapors can ignite or explode, causing severe injury or property damage.

  • Page 163: Troubleshooting Charts

    Remove the spark plug and check the electrodes. The engine does not start. Have a Yamaha dealer check the vehicle. Check the compression. 4. Compression The engine does not start. There is compression.
  • Page 164 Restart the engine. If the engine overheats again, ask a Level is OK. Yamaha dealer to inspect and/or repair the cooling system. If it is difficult to get the recommended coolant, tap water can be used temporarily, provided that it is changed to the recommended coolant as soon as possible.

  • Page 165: Cleaning And Storage

    brakes may have reduced stopping EBU32720 CLEANING AND STORAGE ability, increasing the chance of an ac- NOTICE: Excessive wa- cident. EBU33680 [EWB03470] Cleaning ter pressure may cause water seepage Frequent, thorough cleaning of your vehicle and deterioration of wheel bearings, will not only enhance its appearance but will brakes, transmission seals and electri- improve its general performance and extend...

  • Page 166: Storage

    1. Fill the fuel tank with fresh fuel and add 6. Clean the seats with a vinyl upholstery the specified amount of Yamaha Fuel cleaner to keep the covers pliable and Stabilizer and Conditioner or equivalent glossy.
  • Page 167 [less than 0 °C (30 °F) or more than 30 °C (90 °F)]. Use of fuel stabilizer and conditioner elimi- nates the need to drain the fuel system. Con- sult a Yamaha dealer if the fuel system needs to be drained.

  • Page 168: Specifications

    EBU32750 SPECIFICATIONS Dimensions: Starting system: Electric starter Overall length: Lubrication system: 2970 mm (116.9 in) Wet sump Overall width: Engine oil: 1540 mm (60.6 in) Overall height: Recommended brand: 1885 mm (74.2 in) YAMALUBE Wheelbase: Type: 2065 mm (81.3 in) SAE 5W-30, 10W-30, 10W-40, 15W-40, 20W-40 or 20W- Ground clearance: 290 mm (11.4 in)
  • Page 169 With oil filter cartridge replacement: Spark plug (s): 2.30 L (2.43 US qt, 2.02 Imp.qt) Manufacturer/model: Final gear oil: NGK/CPR7EA-9 Type: Spark plug gap: SAE 80 API GL-4 Hypoid gear oil 0.8–0.9 mm (0.031–0.035 in) Quantity: Clutch: 0.40 L (0.42 US qt, 0.35 Imp.qt) Clutch type: Differential gear oil: Wet, centrifugal automatic...
  • Page 170 Front tire: Front: 70.0 kPa (0.700 kgf/cm², 10 psi) Type: Rear: Tubeless 70.0 kPa (0.700 kgf/cm², 10 psi) Size: Front wheel: 26 x 8-12NHS Manufacturer/model: Wheel type: MAXXIS/MU09 Panel wheel Rear tire: Rim size: 12 x 6.0AT Type: Rear wheel: Tubeless Size: Wheel type:...
  • Page 171 Spring/shock absorber type: Reverse indicator light: Coil spring/gas-oil damper Wheel travel: Coolant temperature warning light: 246 mm (9.7 in) Rear suspension: Engine trouble warning light: Type: Parking brake indicator light: Double wishbone Spring/shock absorber type: On-Command four-wheel-drive/differential gear lock Coil spring/gas-oil damper indicator: Wheel travel: 269 mm (10.6 in)
  • Page 172 Ignition fuse: 10.0 A Auxiliary DC jack fuse: 10.0 A Backup fuse: 10.0 A Four-wheel-drive motor fuse: 10.0 A Radiator fan motor fuse: 25.0 A 10-5...

  • Page 173: Consumer Information

    This number can be used for ordering a new mation in the spaces provided for assistance key. when ordering spare parts from a Yamaha dealer or for reference, in case the vehicle is stolen. KEY IDENTIFICATION NUMBER: VEHICLE IDENTIFICATION NUMBER: 1.
  • Page 174 The model label is affixed to the frame under haust emissions as required by federal law, the driver seat. Record the information on this state law and Environment Canada. label in the space provided. This information will be needed to order spare parts from your Yamaha dealer. 11-2...
  • Page 175 1. Vehicle Emission Control Information label 11-3...

  • Page 176: Yamaha Side By Side Off-Road Vehicle Warranty Policy

    The subsequent owner has the responsibility for ensuring CUSTOMER provide record MOTOR COMPANY, LTD. (‘MANUFACTURER’) under the that a change of registration is sent to YAMAHA at the maintenance having been performed trade name of Yamaha, distributed by YAMAHA MOTOR time of such transfer of ownership.
  • Page 177 Brakes inspections; warranty of performance, merchantability or fitness for a • Clutch particular purpose on the part of YAMAHA, and any other pre-delivery inspection and assembly; • Fluid Levels obligation or liability on behalf of YAMAHA, and the above SSV’s...

  • Page 178: Index

    INDEX Differential gear oil, Pre-operation check ...... 5-7 Doors ................4-14 Driver seat position ............4-16 Drive select lever ............4-13 Accelerator pedal ............4-12 Drive select lever operation and reverse driving .... 6-3 Accelerator pedal, Pre-operation check ......5-7 Air filter case/air duct check hose, cleaning ....8-35 Engine break-in ..............
  • Page 179 Instruments, lights and switches, Pre-operation Passenger handhold, Pre-operation check ....5-8 check ................5-8 Rear knuckle upper and lower pivot, lubrication ..8-43 Jump-starting .............. 8-50 Reverse indicator light ........... 4-3 Key identification number ..........11-1 Safety information ............2-1 Seat belt indicator light ..........
  • Page 180 Vehicle Emission Control Information label ....11-2 Vehicle identification number ........11-1 Warranty ...............11-4 Wheel installation ............8-46 Wheel removal .............8-44 12-3...
  • Page 181 EBU32880 For your best ownership experience, think Genuine Yamaha! Genuine Yamaha Parts – Genuine Yamaha replacement parts are the exact same parts as the ones originally equipped on your vehicle, providing you with the performance and durability you have come to expect.

Table of Contents
