7.5 Disassembly Tools
Table 7-6 List of Tools for Standard Disassembly
Tool name
Ratchet wrench
Adjustable wrench
Screwdriver
Screwdriver
Snap ring pliers external
Snap ring pliers internal
Eye bolt
Allen wrench key
Lock nut wrench
Torque wrench
for assembly
Compound 2-stage Screw Compressor
1612LSC Speed Increaser Type
size, etc.;
1/4"
250 mm
Phillips
Flat blade
for shaft ST-2N
for groove RT-4
M8 two-peace-set
Across flats 2 mm
3 mm
4 mm
5 mm
6 mm
8 mm
10 mm
12 mm
AN-05
AN-06
AN-8
AN-9
AN-12
AN-13
AN-14
AN-17
5-25 N･m
20-100 N･m
40-280 N･m
500-1500 N･m
7-12
