Instruction Manual

Color LCD Monitor
Important
Please read this Instruction Manual, the Installation Manual and the
Setup Manual carefully to familiarize yourself with safe and effective
usage.
• For the latest product information including the User's Manual, refer
to our web site:
http://www.eizoglobal.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DuraVision FDF2304W-IP and is the answer not in the manual?

Questions and answers

Related Manuals for Eizo DuraVision FDF2304W-IP

Summary of Contents for Eizo DuraVision FDF2304W-IP

  • Page 1: Instruction Manual

    Instruction Manual Color LCD Monitor Important Please read this Instruction Manual, the Installation Manual and the Setup Manual carefully to familiarize yourself with safe and effective usage. • For the latest product information including the User’s Manual, refer to our web site: http://www.eizoglobal.com...

  • Page 2: About This Manual

    EIZO Corporation is under no obligation to hold any submitted material or information confidential unless prior arrangements are made pursuant to EIZO Corporation’s receipt of said information. Although every effort has been made to ensure that this manual provides up-to-date information, please note that EIZO monitor specifications are subject to change without notice.

  • Page 3: Notice For This Monitor

    Notice for this monitor Cleaning Attention • Chemicals such as alcohol and antiseptic solution may cause gloss variation, tarnishing, and fading of the cabinet or panel, and also quality deterioration of the image. • Never use any thinner, benzene, wax, and abrasive cleaner, which may damage the cabinet or panel. Note •...

  • Page 4: Table Of Contents

    CONTENTS Notice for this monitor ......... 3 Cleaning ..............3 To use the monitor comfortably ......3 CONTENTS ............. 4 Chapter 1 Product overview ......5 1-1. System Configuration ........5 Chapter 2 Turning On / Off the Power ....6 ●...

  • Page 5: Chapter 1 Product Overview

    Chapter 1 Product overview This color LCD monitor can display images from up to 16 network cameras *1 A type of camera which converts images into network signals and transmits the signals. 1-1. System Configuration FDF2304W-IP Ethernet Network camera HDMI Network hub HDMI device (Network video recorder etc.) *1 Up to 16 network cameras can be registered.

  • Page 6: Chapter 2 Turning On / Off The Power

    Chapter 2 Turning On / Off the Power ● To turn on the power Turn on the main power switch on the back of the monitor. The main power switch is turned on when factory default settings are configured. Press on the front of the monitor or on the remote control.

  • Page 7: Chapter 3 Operating The System

    Chapter 3 Operating the System Each menu is operated using the remote control or a USB mouse. This chapter describes operating the menus using the remote control. To operate menus when using a USB mouse, refer to each item. For details on connecting a USB mouse, refer to “Basic menu operations”...

  • Page 8: Live Image Screen

    3-2. Live Image Screen The live image screen is displayed when the monitor is turned on. There are two states to the live image screen. Live image screen menu can be shown or hidden by pressing Live image screen Live image screen (camera images and menu) (camera images only) Note...

  • Page 9: Basic Menu Operations

    ● Basic menu operations The menu is used for operation and setting of network cameras and the monitor. Live Image Screen 1. Display mode menu Current time 2. System setup menu / Camera control menu Message display area (Error messages such as on camera operations are displayed.) Network camera image display area - When no camera is registered, a “Not registered ”...
  • Page 10 Display mode menu Camera images displayed on the live screen can be operated. Remote control Display mode menu Description button Displays / hides the menu of the live image display screen. Changes the live image screen layout. Each time the button is pressed, the layout changes in the following order: 1 Screen →...

  • Page 11: Entering Characters

    Entering characters 1. Press The text field is highlighted in green. 2. Press the number buttons ( 0 to 9 ). Press a button consecutively to change over to the character next in order. For the order of character entry, refer to the table shown below.

  • Page 12: Changing Over Screen Layout And Displayed

    3-3. Changing Over Screen Layout and Displayed Pages ● To change over the screen layout Changes the number of camera images to display on the live image screen. Procedure 1. Press on the remote control. When using a USB mouse, the screen layout changes by selecting the display screen layout icon.

  • Page 13: To Change Over The Page Displayed On The Screen

    ● To change over the page displayed on the screen Except for when the screen layout is 16 Screens, camera images are displayed by changing over pages. Pages can be changed over either manually or automatically at a set interval (sequential display). Changing pages manually Procedure 1.

  • Page 14: Turning Smart Functions On / Off

    3-4. Turning Smart Functions On / Off Enable or disable settings of Smart Functions. Using Smart Functions improves the camera image visibility. Procedure 1. Press on the remote control. Each time the button is pressed, Smart Functions are turned on or off. Note •...

  • Page 15: To Operate Network Cameras

    ● To Operate network cameras Procedure 1. Select the camera control menu. 1. Press 2. Select the camera control menu using , then press 2. Select the network camera to operate. 1. Check that “Camera” is selected and press 2. Select a network camera displayed in the live image screen using , then press .
  • Page 16 Brightness / Preset / Focus Function Detail Brightness Adjusts the brightness of the network camera. 1. Select the setting button and press Each time is pressed, the image becomes darker. Returns the brightness to the default setting.* Each time is pressed, the image becomes brighter. Preset Moves the camera orientation to the position registered in advance.

  • Page 17: Adjusting Screen Brightness

    3-6. Adjusting Screen Brightness Adjust the brightness of the monitor screen by changing the brightness of the backlight (light source at the back of the LCD panel). Adjustable range 0 to 100 Procedure 1. Press on the remote control. The brightness adjustment menu is displayed. 2.

  • Page 18: Chapter 4 Troubleshooting

    • Adjust the screen brightness (For details, refer to the Setup Manual). (The LCD monitor backlight has a limited life span. When the screen becomes dark or begins to flicker, contact your local EIZO representative.) 2. Afterimages appear • Afterimages are particular to LCD monitors. Avoid displaying the same image for a long time.

  • Page 19: Other Problems

    4-3. Other problems Problem Possible cause and remedy 1. Operation buttons on the front of the • Check whether the operation lock function is active monitor do not work (For information on how to release the lock, refer to the Installation Manual).

  • Page 20: Appendix

    AXIS is a registered trademark of Axis AB in Sweden and other countries. EIZO, the EIZO Logo, ColorEdge, DuraVision, FlexScan, FORIS, RadiCS, RadiForce, RadiNET, Raptor and ScreenManager are registered trademarks of EIZO Corporation in Japan and other countries. ColorEdge Tablet Controller, ColorNavigator, CuratOR, EcoView NET, EIZO EasyPIX, EIZO Monitor Configurator, EIZO ScreenSlicer, G-Ignition, i •...

  • Page 21: License / Copyright

    If the open source software contains a product for which usage us granted under a GPL (GNU GENERAL PUBLIC LICENSE) license, Eizo Corporation will, in line with the GPL usage license conditions, provide the source code for corresponding GPL software via a medium, such as CD-ROM, at a cost to individuals and organizations who make contact via the following contact information for a minimum period of three years after purchase of the product.

  • Page 22: Limited Warranty

    The period of this Warranty is two (2) years from the date of purchase of the Product (hereinafter referred to as the “Warranty Period”). EIZO and Distributors shall bear no liability or obligation with regard to the Product in relation to the Original Purchaser or any third parties other than as provided under this Warranty.

  • Page 23: Recycling Information

    Cuando desee deshacerse de este producto, póngase en contacto con un distribuidor o una fi lial de su país. Encontrará las direcciones de contacto en el sitio web de EIZO que se indica a continuación. http://www.eizoglobal.com Informazioni sul riciclaggio Per lo smaltimento e il riciclaggio del presente prodotto, attenersi alle normative vigenti nel proprio paese per ridurre l’impatto ambientale.
  • Page 24 Ten produkt po zużyciu powinien być zbierany i przetwarzany zgodnie z krajowymi przepisami dotyczącymi ochrony środowiska. Wyrzucając ten produkt, należy skontaktować się z lokalnym dystrybutorem lub partnerem. Adresy kontaktowe można znaleźć we wskazanej poniżej witrynie internetowej fi rmy EIZO. http://www.eizoglobal.com...
  • Page 25 Při likvidaci produktu musí být produkt vyzvednut a recyklován podle zákonů příslušné země, aby nedocházelo k zatěžování životního prostředí. Zbavujete-li se produktu, kontaktujte distributora nebo pobočku ve své zemi. Kontaktní adresy jsou uvedeny na následující webové stránce společnosti EIZO. http://www.eizoglobal.com Ringlussevõtu alane teave...
  • Page 26 2nd Edition-August, 2016 03V25779B1 Copyright © 2016 EIZO Corporation. All rights reserved. (UM-FDF2304WIP-3)
